MODULE OSD MENU*

EXPOSURE
LENS
MANUAL / DC
BACKLIGHT
OFF / HME / BLC / WDR
DRC
OFF / LOW / MIDDLE / HIGH
DEFOG
OFF / ON
AGC
0 ~ 20
STARLIGHT
OFF / x2 ~ x64
3D DNR
OFF / LOW / MID / HIGH
EXIT JUMP
SAVE & EXIT / EXIT
MOTION
MOTION
OFF / ON
ALARM
SHAKING - OFF / ON
SHAKE SCALE - 0~20
BRIGHT CHG. - OFF / ON
BRIGHT SCL. - 0~20
QUICK ZOOM
OFF / ON
EXIT JUMP
SAVE & EXIT / EXIT
COLOR
WB BAL.
ATW / AWB / PUSH /
MANUAL
COLOR GAIN
0 ~ 20
EXIT JUMP
SAVE & EXIT / EXIT
PRIVACY
ZONE NUM.
0 ~ 15
ZONE DISP.
OFF / ON
H-POS.
0 ~ 39
V-POS.
0 ~ 30
H-SIZE
0 ~ 40
V-SIZE
0 ~ 31
Y LEVEL
0 ~ 20
CR LEVEL
0 ~ 20
CB LEVEL
0 ~ 20
EXIT JUMP
SAVE & EXIT / EXIT
DAY & NIGHT
D&N MODE
AUTO / COLOR / B&W
CONTROL
AUTO / EXT.
EXT LED
AUTO / OFF
DELAY
LOW / MIDDLE / HIGH
B&W BURST
OFF / ON
SMART IR
0 ~ 20
EXIT JUMP
SAVE & EXIT / EXIT
SETUP
COMMUNICA.
CAM ID (0 ~ 255)
BAUDRATE (2400 / 4800 / 9600 /
57600 / 115200)
V EW ANGLE
NORMAL / 4 3 / 16 9
LANGUAGE
ENGLISH / CHINESE / CHINESE (S) /
JAPANESE / KOREAN
SPECIAL
DEFECT DET. / TV MODE / O.L.P.F
NITIAL
ON
EXIT JUMP
SAVE & EXIT / EXIT
FUNCTION
SHARPNESS
0 ~ 10
GAMMA
0.45 ~ 0.65
M RROR
OFF / ON
FL P
OFF / ON
D-ZOOM
x1.0 ~ x8.0
EXIT JUMP
SAVE & EXIT / EXIT
EXIT
SAVE & EXIT
EXIT
