EXPOSURE
DC Lens Submenu
Mode: MANUAL: Set the lens mode to Normal or Deblur.
DC: Set the lens mode to Outdoor, Indoor, or Deblur.
Brightness: Adjust the camera's brightness from 0~20. The higher the
number, the brighter the image will appear.
Shutter: Set the shutter speed to AUTO, Manual, or FLC (Flicker-less mode).
Select FLC if the camera is experiencing some flickering in the image. If selected, the
shutter speed will automatically be set to 1/100 for NTSC, or 1/120 for PAL.
If Manual is selected, set the shutter speed from 1/60 to 1/60000.
Focus Adjustment: When on, the default level is set automatically by
controlling lens focus and based on the installation and environment
circumstances.
14
LENS
Manual mode supports the fixed board lens or the manual
Manual
iris lens.
DC mode supports the auto-iris varifocal lens.
DC
NOTE: Both MANUAL and DC mode have FOCUS ADJ. You can
adjust the focus by finding the highest number on the FOCUS SET.
MANUAL Lens Submenu
