Specifications; Warranty - Digital Watchdog MEGApix Ai DWC-XSDJ08Mi User Manual

Appendix -
Product Specifications
Image sensor
Total pixels
Active pixels
Minimum scene illumination
S/N ratio
Test monitor video output
LENS
Focal length
Lens type
Field of view (HFoV/ VFoV)
IR distance
Optical zoom / digital zoom
I/O
Audio in/out, compression
Alarm input/output
Event trigger
INTELLIGENT VIDEO ANALYTICS
Deep learning analytics
Analytics filters
OPERATIONAL
Shutter mode
Shutter speed
Slow shutter
Auto gain control
Day and night
3D Digital Noise Reduction
Wide Dynamic Range (WDR)
White balance
Privacy zones
Mirror and flip
Alarm notifications
Memory slot
NETWORK
LAN
Video compression type
Resolution
Frame rate
Video bitrate
Bitrate control
Streaming capability
IP
Protocol
Security
SIP/VoIP Suppor
ONVIF conformance
Web viewer
Video management software
ENVIRONMENTAL
Operating temperature
Operating humidity
IK rating / IP rating
Other certifications
ELECTRICAL
Power requirement
Power consumption
MECHANICAL
Material
Dimensions
Weight

Warranty

4K 1/2.8" Star-Light Plus™ sensor
3864(H) X 2228(V)
3840(H) x 2160(V)
0.09 lux (color) / 0 lux (B/W)
50dB
Local video output CVBS 1.0V p-p (75Ω), 16:9 aspect ratio
2.7~13.5mm, F1.4
Vari-focal p-iris lens with motorized zoom and auto-focus
Horizontal: 33.1°~90.3° / Vertical: 18.9°~49°
110ft range
5x optical zoom
1 microphone built-in, 1 line-in/1 output, G.711 ulaw
1 input/1 output
Motion, network loss, temperature anomaly, illegal login, schedule, sensor
Deep Learning object tracking
Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear,
disappear, stopped, enter, exit, direction, tailgating, dwell, logical rules
Auto, manual, anti-flicker, slow shutter
1/15 ~ 1/32000
1/2, 1/3, 1/5, 1/6, 1/7.5, 1/10
Auto
TDN, Auto, day (color), night (B/W)
Smart DNR™ 3D-DNR
True WDR, 120dB
Yes
16 programmable privacy masks
Yes
Notifications via email, FTP, alarm output and SD card recording
Micro SD/SDHC/SDXC class 10 card (not included)
RJ45, 1000Base-T (1Gbps)
H.265, H.264, MJPEG
H.265, H.264: 3840x2160, 2592x1944, 2560x1440, 1920x1080, 1280x720, 640x480, 640x360,
352x288, 352x240
MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360,
352x288, 352x240
Up to 30fps at all resolutions
100Kbps ~ 25Mbps, multi-rate for preview and recording
Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
Triple Streaming (3rd stream MJPEG only)
IPv4
TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP,
SMTP, ICMP, SNMPv1/v2/v3 (MIB-2), ONVIF
HTTPS (TLS), IP filtering, 802.1x, digest authentication
SIP VoIP
Yes
OS: Windows®, Mac® OS, Linux®
Browser: Microsoft Edge®, Google Chrome®, Mozilla Firefox®, Safari®
DW Spectrum® IPVMS
-40°F ~ 122°F (-40°C ~ 50°C)
10–90% RH (non–condensing)
IK10 impact-resistant / IP67-rated
CE, FCC, UL, NDAA, TAA
DC12V, PoE IEEE 802.3af Class3 (Adapter is not included)
DC: max 13.1W, 1.09A, PoE: max 15.0W, 312.5mA
Aluminum die-casting vandal housing, polycarbonate dome
5.74" x 5.11" (146 x 130mm)
3.13 lbs (1.42 kg)
5 year warranty
