Appendix -
Product Specifications
Image sensor 1/2.8" 5.17MP Star-Light Plus™ sensor
Total pixels 2608(H) X 1984(V)
Active pixels 2592(H) X 1944(V)
0.08 lux (color)
Minimum scene illumination
0 lux (B/W)
S/N ratio 50dB
LENS
Focal length 2.8mm, F2.2
Lens type Fixed lens
Field of view (HFoV/ VFoV) 97.7°/ 73°
IR distance 90ft range
I/O
Audio input/output 1 microphone built-in/1 line output
Audio compression G.711 ulaw
Alarm input/output 1 input/1 output
Event trigger Motion, network loss, temperature anomaly, illegal login, schedule, sensor detection
INTELLIGENT VIDEO ANALYTICS
Deep learning analytics Deep Learning object tracking
Zones and lines, tamper, metadata, intrusion, line crossing, counting, counting lines, appear, disappear,
Analytics filters
stopped, enter, exit, direction, tailgating, dwell, logical rules.
OPERATIONAL
Shutter mode Auto, manual, anti-flicker, slow shutter
Shutter speed 1/15 ~ 1/32000
Slow shutter 1/2,1/3,1/5,1/6,1/7.5, 1/10
Auto gain control Auto
Day and night Auto, day (color), night (B/W)
3D Digital Noise Reduction Smart DNR™ 3D-DNR
Wide Dynamic Range
True WD, 120dB
(WDR)
White balance Yes
Privacy zones 16 programmable privacy masks
Mirror and flip Yes
Alarm notifications Notifications via email, FTP, alarm output and SD card recording
Memory slot Micro SD/SDHC/SDXC class 10 card (not included)
NETWORK
LAN RJ45 (10/100Base-T)
Video compression type H.265, H.264, MJPEG
H.265, H.264: 2592x1944, 2560x1440, 1920x1080, 1280x720, 800x600, 704x576, 704x480, 640x480,
640x360, 352x288, 352x240
Resolution
MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288,
352x240
Frame rate Up to 30fps at all resolutions
Video bitrate 100Kbps ~ 25Mbps, multi-rate for preview and recording
Bitrate control Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
Streaming capability Triple Streaming (3rd stream MJPEG only)
IP IPv4
TCP/IP, UDP, Auto IP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP,
Protocol
ICMP, SNMPv1/v2/v3 (MIB-2), ONVIF
Security HTTPS (TLS), IP filtering, 802.1x, digest authentication
ONVIF conformance Yes
OS: Windows®, Mac® OS, Linux®
Web viewer
Browser: Microsoft Edge®, Google Chrome®, Mozilla Firefox®, Safari®
Video management software DW Spectrum® IPVMS
ENVIRONMENTAL
Operating temperature -4°F ~ 122°F (-20°C ~ 50°C)
Operating humidity 10–90% RH (non–condensing)
IK/IP rating IK10 impact-resistant/ IP67-rated
Other certifications CE, FCC, UL, NDAA, TAA
ELECTRICAL
Power requirement DC12V, PoE, adapter not included
12V DC: 10.4W, 866mA
Power consumption
PoE: 12.5W, 260mA
MECHANICAL
Material Aluminum die-casting vandal housing, polycarbonate dome
Dimensions 4.13" x 2.83" (105 x 72mm)
Weight 0.97 lbs (0.44 kg)
Warranty 5 year warranty
