SETUP
COMMUNICATION
Use this setup menu to adjust the camera's ID and Baudrate.
The camera's default Protocol is Pelco-D.
- CAM ID: Provide an ID number for the camera ( 0 ~ 255 ).
- BAUDRATE: 9600bps is default. Select the baudrate from the
following options: 2400/4800/9600/57600/115200 bps.
VIEW ANGLE
4:3 / 16:9 / Adjust the camera's aspect ratio. By default, the camera is set to
NORMAL 4:3. If applicable, set it to 16:9.
LANGUAGE
The Camera supports the following languages: English (Default), Chinese,
Chinese (S), Japanese, and Koran.
SPECIAL
DEFECT DET.: The camera can detect and correct dead pixels in the
image. To do so, press the select button and set the threshold level.
The camera will detect and adjust the pixels automatically.
TV MODE: Set the camera to NTSC (Default) or PAL.
OLPF: Select the filter that you use from RED and PASS, then
reboot the camera to use.
INITIAL
Reset the camera to its factory default settings. To do so, press and hold he select button for five
(5) seconds.
24
