2.04 Torch Specifications

SL60™ 1Torch™ Ratings for C-35A
Torch Configuration
Torch Leads Length 20 feet ( 6.1 m)
Ambient
Temperature
Torch Duty Cycle
Maximum Current
Voltage (V )
peak
Arc Striking Voltage 7kV
Type of Cooling
Parts-in-Place:
Gas Requirement:
Input
Gas Pressure
Minimum Gas Flow
Plasma Power
Supply Used With:
Introduction
Torch Head at 75° to
Torch Handle
104° F
40° C
100% @ 60 Amps
@ 400 scfh
60 Amps, DC,
Straight Polarity
500V
Ambient air and gas
stream through torch
Built-in Switch
in Torch Head
Single Gas, Compressed
Air Only
75 psi (5.2 bar) (.52MPa) -
125 psi (8.6 bar) (.86MPA)
400 scfh / 6.6 scfm
(188.7 lpm)
C-35A

2.05 System Contents

ITEMS
Power Source Model C-35A
SL60™, with 20' leads
Torch Set
(6.1m)
Air Regulator
Work Cable
Accessories &
Manual
Consumables
Torch Electrodes
Torch Tips
Input Power
3 Meter NEMA 10 AWG /
Cable For
4.8 mm
Systems
molded plug
1-1635-1
Input Power
Cable For 2 Meter Cord With No
Systems Plug
1-1635-4 (CE)
If you have questions or concerns regarding your sys-
tem, please contact:
Thermal Dynamics Technical Service Dept.
Tel: 1-800-752-7622 (1-800-PLASMA2)
Fax: 1-800-221-4401
e-mail address: tdc-tech@thermadyne.com

2.06 Transporting Methods

Lift unit with handle on top of case. Use handcart or
similar device of adequate capacity for transporting.
ELECTRIC SHOCK can kill. DO NOT
TOUCH live electrical parts. Disconnect input
power from supply before moving the power
source.
FALLING EQUIPMENT can cause serious per-
sonal injury and equipment damage.
2-2
Description Q'ty
1
1
1
1
1
2
3
2
with 6 - 50 P
1
1
WARNINGS
Manual 0-4678
