2.04 Torch Specifications

SL100™ 1Torch™ Ratings for C-70A
Torch Configuration
Torch Leads Length
Ambient
Temperature
Torch Duty Cycle
Maximum Current
Voltage (V )
peak
Arc Striking Voltage 7kV
Type of Cooling
Parts-in-Place:
Gas Requirement:
Input
Gas Pressure
Minimum Gas Flow
Plasma Power
Supply Used With:
Introduction
Torch Head at 75° to
Torch Handle
20 feet (6.1 m)
104° F
40° C
100% @ 100 Amps
@ 400 scfh
100 Amps, DC,
Straight Polarity
500V
Ambient air and gas
stream through torch
Built-in Switch
in Torch Head
Single Gas,
Compressed Air Only
75 psi (5.2 bar) (.52
MPa)-
125 psi (8.6 bar) (.86
MPa)
400 scfh 6.6 scfm
(188.7 lpm)
C-70A

2.05 System Contents

ITEMS
Power Source Model C-70A
Torch Set SL100™, 20' (6.1m)
Air Regulator
Work Cable
Added
Manual
Features
Torch Electrodes
Torch Tips
Input Power
Cable For 2 Meter 6 AWG SOW with
Systems 6 - 50 P molded plug
1-1670-1
Input Power
Cable For
Systems 2 Meter Cord With No Plug
1-1670-3
1-1670-4 (CE)
If you have questions or concerns regarding your sys-
tem, please contact:
Thermal Dynamics Technical Service Dept.
Tel: 1-800-752-7622 (1-800-PLASMA2)
Fax: 1-800-221-4401
e-mail address: tdc-tech@thermadyne.com

2.06 Transporting Methods

Lift unit with handle on top of case. Use handcart or
similar device of adequate capacity for transporting.
ELECTRIC SHOCK can kill. DO NOT
TOUCH live electrical parts. Disconnect input
power from supply before moving the power
source.
FALLING EQUIPMENT can cause serious per-
sonal injury and equipment damage.
2-2
Description Q'ty
1
1
1
1
1
2
3
1
1
WARNINGS
Manual 0-4699
