Thermal Dynamics CUTSKILL C-35A Operator's Manual page 19

E. Typical Cutting Speeds
Cutting speeds vary according to torch output, the type of material being cut, and operator skill. Speeds
shown are typical for this cutting system using air plasma to cut mild steel, with output current at the
highest setting and the torch used in the Drag mode or standoff height indicated.
Unit Standoff
C-35A Drag
C-35A Drag
C-35A 1/8" (3mm)
C-35A 1/8" (3mm)
C-35A 1/8" (3mm)
Drag or Drag mode refers to the torch tip being in contact with the work piece at all times.
Manual 0-4678
Material Maximum Travel Speed
Thickness
(10GA) 0.135" ( 3mm)
(7GA) 0.179" (4.5mm)
1/4" (6mm)
3/8" (10mm)
1/2" (12mm)
NOTE:
Recommended Travel Speed
(ipm , mm/m)
94.7 2367
57.0 1425
36.3 908
15.3 383
9.7 242
4-3
(imp , mm/m)
75.7 1893
45.6 1140
29.1 727
12.3 307
7.7 193
Operation
