APPENDIX
Appendix 2: Torch Connection
Disconnect power and air. Lay unit
on its side. Remove access plate.
DETAIL
Negative / Plasma Lead
Black
Orange
Green
White
Pilot
Torch Leads
Negative / Plasma Lead
Power Supply
Adapter
Pilot
Work Cable
Pilot
A-2
To Power
Supply Adapter
Manual 0-4678
