Keyboard & Pointing Device
Full Size Isolated Winkey Keyboard with
Numeric Keypad
Built-In TouchPad (with Multi Gesture
Functionality)
GPU Mode Button (UMA/Optimus Mode)
Model A:
One Instant Button for Airplane Mode
Model B:
Three Instant Buttons for Airplane Mode,
Mute & Camera On/Off
Interface
One USB 2.0 Port
Three USB 3.0 Ports
One eSATA Port (SATA/USB 3.0 Combo)
One External Monitor Port
One HDMI™-Out (High-Definition
Multimedia Interface) Port (with HDCP)
One Microphone-In Jack
One Headphone/Speaker-Out Jack
One S/PDIF Out Jack
One RJ-45 LAN Jack
One DC-In Jack
Card Reader
Embedded Multi-In-1 Push-Push Card
Reader
- MMC / RSMMC
- SD / Mini SD / SDHC / SDXC
- MS / MS Pro / MS Duo
Note: Some of these cards require PC
adapters that are usually supplied with
the cards.
Slots
Two Mini-Card Slots:
Slot 1 for Half Size Mini-Card WLAN
Combo Module with PCIe & USB
Interfaces:
Slot 2 for Full Size Mini-Card mSATA
SSD (Solid State Drive) with SATA
Interface (Factory Option)
OR
For Model A Only
Full Size Mini-Card 3G Module with USB
Interface (Factory Option)
Specifications
Communication
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
Intel® Centrino Advanced-N 6235 2*2
(802.11 a/g/n) Half Mini-Card PCIe WLAN +
Bluetooth V4.0+HS Combo Module (Facto-
ry Option)
Intel® Centrino® Wireless-N 2230 2*2
(802.11 b/g/n) Half Mini-Card PCIe WLAN +
Bluetooth V4.0+HS Combo Module (Facto-
ry Option)
(802.11b/g/n) Half Mini-Card PCIe WLAN
+ Bluetooth V4.0+LE Combo Module
(Factory Option)
(802.11a/c) Half Mini-Card PCIe WLAN +
Bluetooth V4.0+LE Combo Module
(Factory Option)
802.11b/g/n Half Mini-Card PCIe WLAN
Module with PCIe Interface (Factory
Option)
2.0M HD PC Video Camera Module
See Over
Specifications D - 3
