Specifications

Processors

Intel® Core™ i7-4500U processor
(22nm, 1.80GHz, DDR3L-1600MHz, 4MB
L3 cache, TDP: 15W)
Intel® Core™ i5-4200U processor
(22nm, 1.60GHz, DDR3L-1600MHz, 3MB
L3 cache, TDP: 15W)
Intel® Core™ i3-4010U processor
(22nm, 1.70GHz, DDR3L-1600MHz, 3MB
L3 cache, TDP: 15W)

Display

14.0" / 35.56cm HD (1366 * 768) / HD+
(1600 * 900) / FHD (1920 * 1080), 16:9
3.2mm thick Backlit Panel
Multi Touch Screen

Memory

Dual Channel DDR3L
Two 204 Pin SO-DIMM Sockets
Supporting DDR3L 1600 MHz Memory
D
Modules (real operational frequency
depends on the FSB of the processor)
Memory Expandable up to 16GB
Compatible with 2GB, 4GB or 8GB Modules
D - 2 Specifications

Video Adapter

Intel® HD Graphics
(GPU is Dependent on Processor):
Dynamic Frequency
Intel Dynamic Video Memory Technology
up to 1.7MB
Microsoft DirectX®11 Compatible
Intel HD Graphics 4400 (for i7-4500U,
i7-4200U & i3-4010U CPUs)

Storage

One Changeable 2.5" / 7.0mm (h) HDD/
SSD with SATA (Serial) Interface
mSATA SSD (Solid State Drive) with
SATA (Serial) Interface (Factory Option)

Audio

High Definition Audio Interface
Built-In Microphone
2 * Built-In Speakers
Keyboard & Pointing Device
Built-in Touchpad with Multi-Gesture
Functionality
Isolated A4 Size Keyboard

Interface

Two USB 3.0 Ports
One HDMI-Out (High-Definition
Multimedia Interface) Port (with HDCP)
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-In Jack

Card Reader

Embedded Push-Push Multi-In-1 Card
Reader
- MMC/ RS MMC
- SD/ Mini SD / SDHC/ SDXC
Note: Some of these cards require PC
adapters that are usually supplied with
the cards.
