Audio

High Definition Audio
S/PDIF Digital Output
Built-In Array Microphone
2 Built-In 2W Speakers
Sound Blaster™ Cinema 2
ANSP™ 3D Sound Technology on
Headphone Output
Keyboard & Pointing Device
Full Size Isolated White LED Illuminated
Keyboard with Numeric Pad
Built-In TouchPad (with Multi Gesture &
Scrolling Functionality)
Indicators
LED Indicators - Power/Suspend, Battery,
HDD, Airplane Mode, Num Lock, Caps
Lock, Scroll Lock, Camera
Interface
Four USB 3.0 Ports
One Mini Display Port 1.2
One HDMI™ (High-Definition Multimedia
Interface) Out Port (with HDCP)
One External Monitor Port
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One S/PDIF Out Jack
One RJ-45 LAN Jack
One DC-In Jack
Card Reader
Embedded Multi-In-1 Push-Push Card
Reader
- MMC / RSMMC
- SD / Mini SD / SDHC / SDXC
Card Reader Note: Some of the cards
require PC adapters that are usually
supplied with the cards.
Slots
Models A & B - Three M.2 Slots:
=======================================
Slot 1: for M.2 2230 WLAN Combo Module
Card with PCIe & USB Interfaces
Slot 2: for M.2 2280 SSD Card with SATA/
PCIe Gen x3/x4 Interface
Slot 3: for LTE/HSPA+ M.2 3042 3G or 4G
Module Card with USB Interface (Factory
Option)
Specifications
Model C - Two M.2 Slots:
=======================================
Slot 1: for M.2 2230 WLAN Combo Module
Card with PCIe & USB Interfaces
Slot 2: for M.2 2280 SSD Card with SATA/
PCIe Gen x3/x4 Interface
Communication
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
2.0M FHD PC Video Camera Module
Intel® Dual Band Wireless-AC 8260 (2*2
802.11 a/c) M.2 WLAN + Bluetooth Combo
M.2 2230 Module (Factory Option)
Intel® Dual Band Wireless-AC 7265 (2*2
802.11 a/c) M.2 WLAN + Bluetooth Combo
M.2 2230 Module (Factory Option)
Intel® Dual Band Wireless-N 7265 (2*2
802.11 b/g/n) M.2 WLAN + Bluetooth Com-
bo M.2 2230 Module (Factory Option)
Intel® Dual Band Wireless-AC 3165 (1*1
+
802.11 ac) WLAN Bluetooth Combo M.2
2230 Module (Factory Option)
See over
Specifications D - 3
