Quick Start Guide
1
Figure 1 - 3
LCD Panel Open -
Model B
1. Built-In PC Camera
(Optional)
2. PC Camera LED
3. LCD
4. Power Button
5. GPU Button
6. Speakers
7. Top Case LED
Indicators
8. Hot Key Buttons
9. Keyboard
10. Built-In Microphone
11. Touchpad & Buttons

1 - 8 System Map: LCD Panel Open - Model B

System Map: LCD Panel Open - Model B
2
6
4
8
11
1
3
6 5
7
9
10
5
4
7
8
11
Note that the Touchpad and
Buttons valid operational
area is that indicated within
the red dotted lines above.
