Storage

Two Changeable 2.5" 7mm/9.5mm (h)
Hard Disk Drives (HDD) / Solid State
Drives (SSD) with SATA Interface (RAID
0/1)
Two M.2 2280 SSDs with SATA / PCIe
Gen x3/ x4 Interface (RAID 0/1) (Factory
Option)

BIOS

One 64Mb SPI Flash ROM
AMI BIOS

Audio

High Definition Audio
S/PDIF Digital Output
Built-In Array Microphone
2 Built-In 2W Speakers
Sound Blaster® X-Fi® MB5
External 7.1CH Audio Output Supported
By Headphone, Microphone, Line-In &
S/PDIF Jacks
ANSP™ 3D Sound Technology on
Headphone Output
For Model B Only:
One Built-in Subwoofer Speaker
Keyboard & Pointing Device
Full Size Color Illuminated Keyboard with
Numeric Keypad & Anti-Ghost Keys
Built-In TouchPad (with Multi Gesture &
Scrolling Functionality)
W/A/S/D Game Keys
Indicators
LED Indicators - Power/Suspend, Battery,
HDD, Airplane Mode, Num Lock, Caps
Lock, Scroll Lock, Camera
Interface
Three USB 3.0 Ports
One eSATA Port (SATA/ AC/DC powered
USB3.0 Combo Port)
One USB 3.1 Port (Type C) /
Thunderbolt™ 3 Port
Two Display Ports 1.2
One HDMI™ (High-Definition Multimedia
Interface) Out Port (with HDCP)
One Microphone-In Jack
One Headphone/Speaker-Out Jack
One S/PDIF Out Jack
One Line-In Jack
One RJ-45 LAN Jack
Specifications
One DC-In Jack
Card Reader
Embedded Multi-In-1 Push-Push Card
Reader
- MMC / RSMMC
- SD/ Mini SD / SDHC / SDXC (up to UHS-II)
Card Reader Note: Some cards require
adapters usually supplied with the cards.
Slots
Three M.2 Slots:
=======================================
Slot 1: for M.2 2230 WLAN Combo Module
Card with PCIe & USB Interfaces
Slot 2: for M.2 2280 SSD Card with SATA/
PCIe x3/ x4 Interface
Slot 3: for M.2 2280 SSD Card with SATA/
PCIe x3/ x4 Interface
OR (For Model A Only)
LTE/HSPA+ M.2 3042 3G or 4G Module
Card with USB Interface (Factory Option)
Note: LTE-1 / LTE-2 Antenna (Factory
Option)
Specifications D - 3
