Cateye Strada Smart CC-RD500B Online Manual page 98

Pair a sensor that you want to use with smart computer.
• Pairing (sensor ID synchronization) must be performed in order to use a sensor.
• Do not pair sensors at a race venue or in similar locations where there are many other
users. Doing so may cause smart computer to be paired with another sensor.
• Pair all sensors that you intend to use.
1. From the measurement screen, press MENU to switch to the menu
screen.
* When the menu screen is left on for 1 minute, smart computer returns to the
measurement screen.
2. Press MODE to display the screen shown below, and then press MODE
for 2 seconds.
3. Activate the sensor that you want to pair.
Activating the sensor
Smart computer
Clock setting
Tire circumference setting
Pairing (Sensor ID synchronization)
Important
Measurement
screen
Ready for
synchronization
Menu screen
(Clock setting)
(2 seconds)
Sensor Synchronization
activated complete
