- Page 1 START Click the button and follow the instructions. CATEYE STRADA DIGITAL WIRELESS CC-RD410DW Quick Start...
- Page 2 Thank you for purchasing our cyclocomputer CATEYE STRADA DIGITAL WIRELESS. This Quick Start Manual explains how to set up the computer and how to install the unit on your bicycle. Please set up the unit according to the specified procedure, then it will be ready for use as a cyclocomputer.
- Page 3 This PDF contains a movie file. When you click on the movie screen, a message regarding security appears. Click the “Trust in the text” or “Play” button to close the message. Click the screen again to play the movie. Next...
- Page 4 CATEYE STRADA DIGITAL WIRELESS Return to a Cover Quick Start Manual Contents Click the item you wish to view. Setting up the computer How to install the bracket (movie) How to install the speed sensor (movie) Registering a new sensor...
- Page 5 Operation of buttons Set up the computer by operating the buttons as follows. Check the button position before you start setting up. Back MENU MODE Press the MENU button and the MODE button on the back of the computer. Next...
- Page 6 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Setting up the computer Formatting operation Clear all data (initialization) MENU Press the MENU button on the back of the computer and the AC button simultaneously. Setting the speed unit * Press and hold the MENU button for 3 seconds after you release the AC button.
- Page 7 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the speed unit Clear all data (initialization) When the MODE button is pressed, either “km/h” or “mph” is selected for the speed unit display. Select the display of Setting the speed unit your choice.
- Page 8 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Setting up the computer Entering the tire circumference Clear all data (initialization) Enter the tire circumference (mm) of your bicycle with 4 digits using the tire circumference reference table. Setting the speed unit...
- Page 9 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the clock display Clear all data (initialization) When the MODE button is pressed, either “12h” or “24h” is selected for the clock display. Select the display of your Setting the speed unit choice.
- Page 10 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the hour Clear all data (initialization) Pressing the MODE button increases the value flashing (“Hour” of the clock). Enter any value. Setting the speed unit After entering, press and hold the MODE button to pro- ceed to the next step “Setting the minute”.
- Page 11 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the minute Clear all data (initialization) Pressing the MODE button increases the value flashing (“Minute” of the clock). Enter any value (Pressing and Setting the speed unit holding MODE rapidly increases the value).
- Page 12 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Setting up the computer Now, setup of the computer is completed. Clear all data (initialization) If the bracket and speed sensor are not installed on your Setting the speed unit...
- Page 13 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual How to install the bracket If the video does not play, please click here. (YouTube movie)
- Page 14 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual How to install the speed sensor If the video does not play, please click here. (YouTube movie)
- Page 15 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Setting up the computer Tire circumference reference table * Generally, the tire size or ETRTO is indicated on the side of the tire. ETRTO Tire size L (mm) ETRTO Tire size...
- Page 16 Registering a new sensor IDs of sensors supplied with this device are synchronized. For any other sensors, synchronize the sensor ID according to the following procedure. * The Q series, 2.4GHz digital sensor can also be used. * Heart rate can be measured with HR-10 or the Q series heart rate sensor (sold separately) when the ID is synchronized.
- Page 17 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Registering a new sensor Switching to the “Searching for sensor ID” screen To “Searching for sensor ID” From the measurement screen, press the MENU button to switch to the Menu screen.
- Page 18 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Registering a new sensor Sensor selection To “Searching for sensor ID” Pressing the MODE button switches the display to “SP1”, “SP2”, and “HR” in this order. Sensor selection • In case of speed sensor Select “SP1”...
- Page 19 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Registering a new sensor Start of searching for sensor ID To “Searching for sensor ID” Pressing the MENU button switches to the “Standby for the sen- sor ID” screen. Then, press the RESET button on the sensor.
- Page 20 CATEYE STRADA DIGITAL WIRELESS Return to Contents Quick Start Manual Registering a new sensor Completion of searching for sensor ID Completion of searching To “Searching for sensor ID” for sensor ID When the computer correctly receives the sensor ID sig- nal, the current speed or heart rate appears.
