Page 1 CATEYE STRADA SMART CYCLOCOMPUTER CC-RD500B Online Manual Select the devices you have. * Instructions differ depending on the devices you have. * For explanatory purposes, in this manual red text/icons on the Strada Smart screen represent ﬂashing items. * The display screens and illustrations used in this manual may differ from the actual product.
Page 2 Setup method...
Page 3: Setup With Smartphone
Setup (ﬁrst time only) Mounting the bracket If you have not yet purchased Strada Smart Setup (ﬁrst time only) Optional accessories Mounting the speed (cadence) sensor (ISC-12) Wearing the heart rate sensor (HR-12) * Mount non-CatEye sensors as directed in relevant instruction manuals.
Page 4: Checking Package Contents
Setup with smartphone Checking package contents Bracket Strada Smart unit Bracket band Bracket rubber pad Dial * The Speed + Cadence Kit includes an integrated speed (cadence) sensor (ISC-12) in addition to the items above. * The Triple Wireless Kit includes an integrated speed (cadence) sensor (ISC-12) and a heart rate sensor (HR-12).
Page 5 Access the App Store, search for "Cateye Cycling", and install the app. If using an Android smartphone Access Google Play, search for "Cateye Cycling", and install the app. * See the product page for information about model recommended for use with Cateye Cycling™. 2. Launch Cateye Cycling™.
Page 6 * If Strada Smart switches to the measurement screen without the whole screen turning on, it has not been formatted. Redo the procedure. * The appearance of the Strada Smart screen depends on the state of Cateye Cycling™. Smartphone When Cateye Cycling™...
Page 7 3. Tire circumference setting 1. Activate the sensor. Activating the sensor When Cateye Cycling™ detects the sensor signal, a message is displayed on the smartphone. Tap [Pair]. The synchronized sensor is displayed on the [Device] screen and pairing is completed.
Page 8: Mounting The Bracket
* You can also change sensor names and cancel pairing from this screen. Determining tire circumference Sensor pairing is now complete. * Pair all sensors that you intend to use. If you want to pair another sensor, repeat the same procedure again. Mounting the bracket...
Page 9: Switching To Sensor Direct Mode
Setup Switching to Sensor Direct Mode Smartphone 1. Close Cateye Cycling™ or from (MENU), turn off [Connect]. Strada Smart 2. Switch Strada Smart to Sensor Direct Mode. (1 second) Smartphone Measurement search screen screen (Sensor Direct Mode) * Strada Smart will search for a sensor instead of your smartphone. In this mode, the icon for the currently connected sensor ﬂashes.
Page 10 Setup Switching to Sensor Direct Mode Pairing (Sensor ID synchronization) Pair a sensor that you want to use with Strada Smart. Important • Pairing (sensor ID synchronization) must be performed in order to use a sensor. • Do not pair sensors at a race venue or in similar locations where there are many other users.
Page 11 Important When Strada Smart displays [FULL] on the screen and returns to the menu: Up to 9 separate sensor IDs can be paired with Strada Smart. If the maximum number of sensors have been paired, with the computer in pairing standby state, press MENU for 4 seconds to clear all pairings.
Page 12 Setup Switching to Sensor Direct Mode Pairing (Sensor ID synchronization) Tire circumference setting Set the tire circumference for a sensor capable of speed measurement. Important • Pairing (sensor ID synchronization) must be performed ﬁrst. Pairing (Sensor ID synchronization) • Set tire circumference for each sensor. The default value is 2,096 mm (700x23c). 1.
Page 13 Sensor selection (2 seconds) (2 seconds) Tire circumference value Increase numbers Move to next digit (2 seconds) * Only paired sensors can be selected. * Error is displayed if values outside the setting range are entered. 4. Press MENU to conﬁrm settings. Pressing MENU again returns to the measurement screen.
Page 14 Setup with smartphone Checking package contents Setup Mounting the bracket The bracket can be mounted on either the stem or the handlebar. Watch video See illustrations • When mounting on the stem • When mounting on the handlebar • Mounting and removing the Strada Smart unit !When mounting on the stem 1.
Page 15 Dial Caution • Always tighten the dial by hand. Using a tool or other object to tighten the dial may crush the screw thread. • Trim bracket band carefully so the cut end will not cause injury (see step 3 above). !When mounting on the handlebar 1.
Page 16 !Mounting and removing the Strada Smart unit Mounting Removing While holding Strada Smart Click Push out Caution To remove Strada Smart, push out while holding the unit with the other hand to ensure that it does not fall.
Page 17 Access the App Store, search for "Cateye Cycling", and install the app. If using an Android smartphone Access Google Play, search for "Cateye Cycling", and install the app. * See the product page for information about model recommended for use with Cateye Cycling™. 2. Launch Cateye Cycling™.
Page 18 Tap [Device Pairing] to start pairing. 2. Activate the sensor. Activating the sensor When Cateye Cycling™ detects the sensor signal, a message is displayed on the smartphone. Tap [Pair]. The veriﬁed sensor is displayed on the [Device] screen and pairing is completed.
Page 19: Mounting The Speed (Cadence) Sensor (Isc-12)
Setup with smartphone Mounting the speed (cadence) sensor (ISC-12) The speed (cadence) sensor can be mounted either on the top or bottom of the chain stay. Caution If the speed (cadence) sensor is mounted on the bottom of the chain stay rather than on the top, the adjustment range between the sensor and the magnet will be narrower.
Page 20 Sensor screw Sensor arm (2) Attach the sensor rubber pad to the sensor. Sensor rubber pad (3) Refer to the illustration and temporarily attach the sensor to the left chain stay with nylon ties. left chain stay Nylon tie Caution Do not fully tighten the nylon ties.
Page 21 the speed sensor zone. * If the sensor cannot is not positioned so that both magnets (speed and cadence) pass through their respective sensor zones, reposition the sensor and the magnets so that each magnet passes through its sensor zone. 3.
Page 22: Wearing The Heart Rate Sensor (Hr-12)
Setup with smartphone Wearing the heart rate sensor (HR-12) Heart rate measurement is performed by wearing a heart rate sensor around the chest. Before wearing the heart rate sensor Warning Never use this device if you use a pacemaker. • To eliminate measurement errors, it is recommended to moisten the electrode pads with water or apply electrolyte cream to the pads.
Page 23 * Wear the heart rate sensor so that TOP faces up. * Ensure that the electrode pads are in close contact with your body. * If you have dry skin or are wearing the sensor over a shirt, measurement errors may result.
Page 24: Setup Without Smartphone
Setup without smartphone Setup without smartphone Checking package contents Setup (ﬁrst time only) Mounting the bracket Optional accessories Mounting the speed (cadence) sensor (ISC-12) Wearing the heart rate sensor (HR-12) * Mount non-CatEye sensors as directed in relevant instruction manuals.
Page 25 Setup without smartphone Checking package contents Bracket Strada Smart unit Bracket band Bracket rubber pad Dial * The Speed + Cadence Kit includes an integrated speed (cadence) sensor (ISC-12) in addition to the items above. * The Triple Wireless Kit includes an integrated speed (cadence) sensor (ISC-12) and a heart rate sensor (HR-12).
Page 26 Setup without smartphone Checking package contents Setup Set up Strada Smart according to the procedure below when using it for the ﬁrst time. Button operation Check button locations before starting set up. Back 1. Format (initialize) Strada Smart. Caution All data will be deleted and Strada Smart will be reset to factory default settings. While holding down the MENU button on Strada Smart, press the AC button.
Page 27 * If Strada Smart switches to the measurement screen without the whole screen turning on, it has not been formatted. Redo the procedure. 2. Display the desired measurement unit. Press MENU to proceed to the next step. 3. Pair a sensor. Strada Smart can be used with sensors compatible with Bluetooth 4.0.
Page 28 4. Enter the tire circumference. Important If Strada Smart is not paired with a sensor capable of measuring speed, tire circumference entry is skipped. Enter the circumference in mm of the tire (the length of the outer circumference of the tire) on which the sensor is installed.
Page 29 Time display mode Select 24 h Select 12 h (2 seconds) (2 seconds) AM/PM (2 seconds) Hours Increase number (2 seconds) (2 seconds) Minutes Increase number Pressing MENU switches to the measurement screen. Setup is now complete. Mounting the bracket...
Page 30 Setup without smartphone Checking package contents Setup Mounting the bracket The bracket can be mounted on either the stem or the handlebar. Watch video See illustrations • When mounting on the stem • When mounting on the handlebar • Mounting and removing the Strada Smart unit !When mounting on the stem 1.
Page 31 Dial Caution • Always tighten the dial by hand. Using a tool or other object to tighten the dial may crush the screw thread. • Trim bracket band carefully so the cut end will not cause injury (see step 3 above). !When mounting on the handlebar 1.
Page 32 !Mounting and removing the Strada Smart unit Mounting Removing While holding Strada Smart Click Push out Caution To remove Strada Smart, push out while holding the unit with the other hand to ensure that it does not fall.
Page 33: Mounting The Speed (Cadence) Sensor (Isc-12)
Setup without smartphone Mounting the speed (cadence) sensor (ISC-12) The speed (cadence) sensor can be mounted either on the top or bottom of the chain stay. Caution If the speed (cadence) sensor is mounted on the bottom of the chain stay rather than on the top, the adjustment range between the sensor and the magnet will be narrower.
Page 34 Sensor screw Sensor arm (2) Attach the sensor rubber pad to the sensor. Sensor rubber pad (3) Refer to the illustration and temporarily attach the sensor to the left chain stay with nylon ties. left chain stay Nylon tie Caution Do not fully tighten the nylon ties.
Page 35 the speed sensor zone. * If the sensor cannot is not positioned so that both magnets (speed and cadence) pass through their respective sensor zones, reposition the sensor and the magnets so that each magnet passes through its sensor zone. 3.
Page 36: Wearing The Heart Rate Sensor (Hr-12)
Setup without smartphone Wearing the heart rate sensor (HR-12) Heart rate measurement is performed by wearing a heart rate sensor around the chest. Before wearing the heart rate sensor Warning Never use this device if you use a pacemaker. • To eliminate measurement errors, it is recommended to moisten the electrode pads with water or apply electrolyte cream to the pads.
Page 37 * Wear the heart rate sensor so that TOP faces up. * Ensure that the electrode pads are in close contact with your body. * If you have dry skin or are wearing the sensor over a shirt, measurement errors may result.
Page 38 The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
Page 39 Checking activities Uploading all activities Changing settings Cateye Cycling™ can be used to conﬁgure all settings for Strada Smart and connected devices. * When a smartphone is connected, if Cateye Cycling™ and Strada Smart settings differ, you must choose which settings to sync.
Page 40: Strada Smart Screen
* If the values ﬂash on and off, it is time to replace the sensor battery. • Speed/cadence/heart rate ﬂash: If using a CATEYE sensor, the values related to the sensor's battery replacement period start ﬂashing to indicate that it is time to replace the battery.
Page 41 After the icon turns on, the oldest summary data is deleted to create space to record new data. * Memory is used to record summary data in Sensor Direct Mode. * Memory can be cleared by importing summary data into Cateye Cycling™. Importing summary data (Pace arrows)
Page 42 • On Measurement stopped • Flashing Measurement in progress (Average) Indicates that the currently displayed value is an average value. (Maximum) Indicates that the currently displayed value is a maximum value. Current function Indicates the currently displayed function. • (Total Distance) •...
Page 43: Cateye Cycling™ [Trip] Screen
Smartphone and Strada Smart Cateye Cycling™ [Trip] screen This is the Cateye Cycling™ home screen. From this screen you can start, pause, and ﬁnish measurement. Swiping the screen switches to map display/graph display, letting you check where you have been.
Page 44 Important The maximum number of trips that can be saved temporarily is 30. If this number is exceeded, the icon changes to and it is not possible to temporarily save any more trips. It is recommended that trip data is saved and uploaded regularly. GPS icon Indicates GPS signal reception status.
Page 45: Connecting Smartphone And Strada Smart
* If the connection is made when Cateye Cycling™ is already measuring, measured values are displayed. * The appearance of the Strada Smart screen depends on the state of Cateye Cycling™. Smartphone connection is now complete. Measurement Saving and uploading trips...
Page 46 Important • Smartphone use When measuring, turn the smartphone display off, and with Cateye Cycling™ running, store the smartphone in a safe place such as a bag or pocket. As measurement start/pause/resume and reset operations (ﬁnish trip) can be performed remotely from Strada Smart, there is no need to take out your smartphone until you want to save or upload trips.
Page 47 Saving and uploading trips !Functions during measurement Switching measurement data display Strada Smart You can switch the display of data being measured in Cateye Cycling™ by pressing MODE. * The data displayed changes depending on the state of the sensor connection.
Page 48 * Heart rate and cadence data will not be displayed unless each sensor is paired. Auto pause function Strada Smart This function automatically pauses measurement when the connection between the smartphone and Strada Smart is broken. Measurement resumes automatically when the connection is reestablished. General : Auto pause Power-saving mode...
Page 49 Strada Smart When Strada Smart is left on the [ready] (measurement standby) screen, [PAUSE] screen, or smartphone search screen for approximately 20 minutes, the sleep display is activated. When MODE is pressed, Strada Smart returns to the smartphone search screen and returns to the original screen when the connection is reestablished.
Page 50 Power sensor calibration Saving and uploading trips...
Page 51 * You must have an account with the relevant site to upload data. Account * Cateye Cycling™ only allows you to post links of trips uploaded to CATEYE Atlas™ on Facebook™ and Twitter™. Links to other service sites cannot be posted.
Page 52: Checking Activity Totals
Smartphone and Strada Smart Checking activity totals Smartphone 1. Tap (MENU) and then [All Activity Summary]. * It is possible to check total values for all activities saved with Cateye Cycling™ and maximum values for individual trips. Checking activities Uploading all activities...
Page 53: Uploading All Activities
Smartphone and Strada Smart Checking activity totals Checking activities You can check activities (the collective term for trip data and summary data) from the Activity List. Smartphone 1. Tap (MENU) and then [Activity List]. * The Activity List can be displayed in graph, list, or calendar format. * Tapping (Select to Delete) moves to the activity deletion screen.
Page 54 Smartphone and Strada Smart Checking activity totals Checking activities Uploading all activities All activities can be uploaded to service sites in one action. Smartphone 1. Tap (MENU) and then [Upload]. * Activities already uploaded to service sites are not displayed. 2.
Page 55 Smartphone and Strada Smart General Adjust various settings related to Mirror Mode. Smartphone 1. Tap (MENU) and then [General]. • Recording Interval Selects the interval at which the log is recorded. • Notiﬁcation Settings Conﬁgures settings for incoming call notiﬁcation (phone/email) and smartphone remaining battery notiﬁcation.
Page 56 Smartphone and Strada Smart General Device Conﬁgure settings for connected devices (Strada Smart and sensors). Important Device settings are shared when Strada Smart is connected to your smartphone. If settings differ, you will be prompted to select which settings to sync. Using an iPhone with a commercial sensor Settings of commercial sensors are not shared.
Page 57 • Odometer Lets you manually set total distance traveled. * Use this function when you want to continue from the same distance after purchasing a new Strada Smart or when resetting Strada Smart. • Clock Lets you switch between 12-hour and 24-hour time display. Important These settings can be conﬁgured even when your smartphone is not connected to Strada Smart.
Page 58 Adjust settings for the service sites below. * You must have an account with the relevant site to upload data. Service sites CATEYE Atlas™ STRAVA™ TRAINING PEAKS™ Facebook™ Twitter™ * When using an SNS, links to activities uploaded to Cateye Atlas™ are posted.
Page 59 (speed, cadence, heart rate, and power). The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
Page 60 Importing summary data measured in Sensor Direct Mode Changing settings Cateye Cycling™ can be used to conﬁgure all settings for Strada Smart and connected devices. * When a smartphone is connected, if Cateye Cylcling™ and Strada Smart settings differ, you must choose which settings to sync.
Page 61: Strada Smart Screen
* If the values ﬂash on and off, it is time to replace the sensor battery. • Speed/cadence/heart rate ﬂash: If using a CATEYE sensor, the values related to the sensor's battery replacement period start ﬂashing to indicate that it is time to replace the battery.
Page 62 After the icon turns on, the oldest summary data is deleted to create space to record new data. * Memory is used to record summary data in Sensor Direct Mode. * Memory can be cleared by importing summary data into Cateye Cycling™. Importing summary data (Pace arrows)
Page 63 • (Trip Distance 2) • (Current Speed) • (Cadence) • (Power) • (Clock)
Page 64: Switching To Sensor Direct Mode
Smartphone and Strada Smart Switching to Sensor Direct Mode Smartphone 1. Close Cateye Cycling™ or from (MENU), turn off [Connect]. Strada Smart 2. Switch Strada Smart to Sensor Direct Mode. (1 second) Smartphone Measurement search screen screen (Sensor Direct Mode) * Strada Smart will search for a sensor instead of your smartphone.
Page 65 Smartphone and Strada Smart Switching to Sensor Direct Mode Starting/stopping measurement Starting/stopping measurement Strada Smart Measurement starts automatically when the bicycle moves. During measurement the measurement unit ﬂashes. * The pause function is not available in Sensor Direct Mode. Saving measurement data (reset operation) Strada Smart Pressing and holding MODE when on the measurement screen generates Reset...
Page 66 Strada Smart Pressing MODE switches the measurement data displayed at the bottom of the screen. * The data displayed changes depending on the state of the sensor connection.
Page 67 * Heart rate and cadence data will not be displayed unless each sensor is paired. *Average values are displayed as .E instead of the measurement value when Elapsed Time exceeds approximately 27 hours. Average speed is also displayed as .E instead of the measurement value when Trip Distance exceeds 1,000 km [620 mile].
Page 68 * When the power value exceeds 999, the last three digits are displayed. * To increase precision, it is recommended to perform calibration before power measurement. Power sensor calibration...
Page 69: Checking Activity Totals
Checking activity totals Smartphone 1. Tap (MENU) and then [All Activity Summary]. * It is possible to check total values for all activities saved with Cateye Cycling™ and maximum values for individual trips. Checking activities Uploading all activities Importing summary data measured...
Page 70 Smartphone and Strada Smart Checking activity totals Checking activities You can check activities (the collective term for trip data and summary data) from the Activity List. Smartphone 1. Tap (MENU) and then [Activity List]. * The Activity List can be displayed in graph, list, or calendar format. * Tapping (Select to Delete) moves to the activity deletion screen.
Page 71 Smartphone and Strada Smart Checking activity totals Checking activities Uploading all activities All activities can be uploaded to service sites in one action. Smartphone 1. Tap (MENU) and then [Upload]. * Activities already uploaded to service sites are not displayed. 2.
Page 72: Importing Summary Data
Before importing summary data, always ﬁnish Strada Smart measurement (reset operation). You cannot import data for which measurement has not ﬁnished. Reset operation Smartphone 1. Launch Cateye Cycling™, and from (MENU) turn on [Connect]. Strada Smart 2. Press MODE to display the smartphone search screen and connect with your smartphone.
Page 73 * The appearance of the Strada Smart screen depends on the state of Cateye Cycling™. * It is not possible to import data while measuring with Cateye Cycling™. Smartphone 3. Tap (MENU) and then [Activity List]. If there is summary data in Strada Smart, the (Import from CC) is displayed.
Page 74 Smartphone and Strada Smart General Adjust various settings related to Mirror Mode. Smartphone 1. Tap (MENU) and then [General]. • Recording Interval Selects the interval at which the log is recorded. • Notiﬁcation Settings Conﬁgures settings for incoming call notiﬁcation (phone/email) and smartphone remaining battery notiﬁcation.
Page 75 Smartphone and Strada Smart General Device Conﬁgure settings for connected devices (Strada Smart and sensors). Important Device settings are shared when Strada Smart is connected to your smartphone. If settings differ, you will be prompted to select which settings to sync. Using an iPhone with a commercial sensor Settings of commercial sensors are not shared.
Page 76 • Odometer Lets you manually set total distance traveled. * Use this function when you want to continue from the same distance after purchasing a new Strada Smart or when resetting Strada Smart. • Clock Lets you switch between 12-hour and 24-hour time display. Important These settings can be conﬁgured even when your smartphone is not connected to Strada Smart.
Page 77 Adjust settings for the service sites below. * You must have an account with the relevant site to upload data. Service sites CATEYE Atlas™ STRAVA™ TRAINING PEAKS™ Facebook™ Twitter™ * When using an SNS, links to activities uploaded to Cateye Atlas™ are posted.
Page 78 Smartphone and Strada Smart Pairing (Sensor ID synchronization) Pair a sensor that you want to use with Strada Smart. Important • Pairing (sensor ID synchronization) must be performed in order to use a sensor. • Do not pair sensors at a race venue or in similar locations where there are many other users.
Page 79: Tire Circumference Setting
Important When Strada Smart displays [FULL] on the screen and returns to the menu: Up to 9 separate sensor IDs can be paired with Strada Smart. If the maximum number of sensors have been paired, with the computer in pairing standby state, press MENU for 4 seconds to clear all pairings.
Page 80 Smartphone and Strada Smart Pairing (Sensor ID synchronization) Tire circumference setting Set the tire circumference for a sensor capable of speed measurement. Important • Pairing (sensor ID synchronization) must be performed ﬁrst. Pairing (Sensor ID synchronization) • Set tire circumference for each sensor. The default value is 2,096 mm (700x23c). 1.
Page 81 Sensor selection (2 seconds) (2 seconds) Tire circumference value Increase numbers Move to next digit (2 seconds) * Only paired sensors can be selected. * Error is displayed if values outside the setting range are entered. 4. Press MENU to conﬁrm settings. Pressing MENU again returns to the measurement screen.
Page 82 (speed, cadence, heart rate, and power). The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
Page 83 * If the values ﬂash on and off, it is time to replace the sensor battery. • Speed/cadence/heart rate ﬂash: If using a CATEYE sensor, the values related to the sensor's battery replacement period start ﬂashing to indicate that it is time to replace the battery.
Page 84 (Memory alarm) This information is required when syncing with a smartphone. Measurement is not affected if this icon turns on. (Pace arrows) Indicate whether the current speed is faster ( ) or slower ( ) than the average speed. (Sensor signal icon) Indicates the Bluetooth®...
Page 85: Starting/Stopping Measurement
Strada Smart Starting/stopping measurement Starting/stopping measurement Measurement starts automatically when the bicycle moves. During measurement the measurement unit ﬂashes. Reset operation Reset Pressing and holding MODE when on the measurement screen resets measurement data to 0. * When MODE has been pressed for 1 second, a smartphone search screen appears, but you should continue to hold down the button.
Page 86 * Heart rate and cadence data will not be displayed unless each sensor is paired. *Average values are displayed as .E instead of the measurement value when Elapsed Time exceeds approximately 27 hours. Average speed is also displayed as .E instead of the measurement value when Trip Distance exceeds 1,000 km [620 mile].
Page 87: Power Saving Mode
Power-saving mode If there is no sensor signal or button operation for 10 minutes, the power-saving screen is activated. If such a state continues for a further hour, the sleep display is activated. The power-saving screen returns to the measurement screen when the bicycle starts moving.
Page 88: Clock Setting
Strada Smart Clock setting 1. From the measurement screen, press MENU to switch to the menu screen. Measurement Menu screen screen (Clock setting) * When the menu screen is left on for 1 minute, Strada Smart returns to the measurement screen.
Page 89 Time display mode Select 24 h Select 12 h (2 seconds) (2 seconds) AM/PM (2 seconds) Hours Increase number (2 seconds) (2 seconds) Minutes Increase number 4. Press MENU to conﬁrm settings. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to conﬁrm changes.
Page 90 Strada Smart Clock setting Tire circumference setting Set the tire circumference for a sensor capable of speed measurement. Important • Pairing (sensor ID synchronization) must be performed ﬁrst. Pairing (Sensor ID synchronization) • Set tire circumference for each sensor. The default value is 2,096 mm (700x23c). 1.
Page 91 Sensor selection (2 seconds) (2 seconds) Tire circumference value Increase numbers Move to next digit (2 seconds) * Only paired sensors can be selected. * Error is displayed if values outside the setting range are entered. 4. Press MENU to conﬁrm settings. Pressing MENU again returns to the measurement screen.
Page 92 Strada Smart Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Pair a sensor that you want to use with Strada Smart. Important • Pairing (sensor ID synchronization) must be performed in order to use a sensor. • Do not pair sensors at a race venue or in similar locations where there are many other users.
Page 93 The synchronized sensor is displayed on the top of the screen and pairing is completed. Important When Strada Smart displays [FULL] on the screen and returns to the menu: Up to 9 separate sensor IDs can be paired with Strada Smart. If the maximum number of sensors have been paired, with the computer in pairing standby state, press MENU for 4 seconds to clear all pairings.
Page 94 Strada Smart Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Switch top of screen display You can choose to display current speed, cadence, or heart rate at the top of the screen. Important Measurement items that require a sensor that is not paired cannot be selected. 1.
Page 95 Current speed Cadence Heart rate Cadence Current speed Heart rate Heart rate Cadence Current speed 4. Press MENU to conﬁrm settings. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to conﬁrm changes. Function setting Total distance manual input Measurement unit setting...
Page 96 Strada Smart Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Switch top of screen display Function setting It is possible to skip certain functions displayed at the bottom of the screen. 1. From the measurement screen, press MENU to switch to the menu screen.
Page 97 (2 seconds) * Current speed, elapsed time, heart rate, cadence, and power cannot be skipped. 4. Press MENU to conﬁrm settings. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to conﬁrm changes. Total distance manual input Measurement unit setting...
Page 98 Strada Smart Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Switch top of screen display Function setting Total distance manual input If you enter a desired value for total distance, you can start your next trip from that value. * This function is useful when you want to continue from the same distance after purchasing a new Strada Smart or when resetting Strada Smart.
Page 99 Increase number Move to next digit (2 seconds) 4. Press MENU to conﬁrm settings. Pressing MENU again returns to the measurement screen. *If you have changed settings, always press MENU to conﬁrm changes. Measurement unit setting...
Page 100 Strada Smart Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Switch top of screen display Function setting Total distance manual input Measurement unit setting You can select the measurement unit (km or miles). 1. From the measurement screen, press MENU to switch to the menu screen.
Page 101 4. Press MENU to conﬁrm settings. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to conﬁrm changes. * When the measurement unit is changed, existing measurement data is automatically converted to the new unit.
Page 102 Smartphone (App Only)
Page 103 Smartphone (App Only)
Page 104 Smartphone (App Only)
Page 105: Battery Replacement
(Restart operation) Optional sensors Important If using a CATEYE sensor, the values related to the sensor's battery replacement period start ﬂashing to indicate that it is time to replace the battery. Speed (cadence) sensor (ISC-12) If Strada Smart's current speed or cadence display starts ﬂashing, it is time to replace the battery.
Page 106 * After replacing the battery, always press RESET and check the position of the sensor relative to the magnet. Heart rate sensor (HR-12) If Strada Smart's heart rate display starts ﬂashing, it is time to replace the battery. Install a new lithium battery (CR2032) so that the (+) side is visible and close the battery cover securely.
Page 107: Activating The Sensor
Activating the sensor Activate the sensor via the following method: • Speed sensor / Speed (cadence) sensor (ISC) / Cadence sensor Move the magnet through the sensor zone several times. (Within 3 mm) Sensor zone Magnet • Heart rate sensor Rub both electrode pads with thumbs to transmit heart rate signal.
Page 108: Determining Tire Circumference
Determining tire circumference Determine tire circumference (L) by referring to the tire size chart or by measuring the actual circumference of your bicycle tire. Tire circumference reference table * The tire size or ETRTO code is indicated on the side of the tire.
Page 109 Measure actual tire circumference With tire air pressure adjusted appropriately, apply a load to the bicycle. Using the valve, etc., as a marker, rotate the tire once and measure the distance traveled along the ground. When using front When using rear wheel for speed wheel for speed measurement...
Page 110 To determine tire circumference (L) with more accuracy, measure the tire using the method below. * When using Cateye Cycling™, you can simply select the size indicated on the tire. Measure actual tire circumference (L) With tire air pressure adjusted appropriately, apply a load to the bicycle.
Page 111: Power Sensor Calibration
Power sensor calibration When the power sensor is used continuously, slight variation may occur in its unloaded state. Correct this by calibrating it periodically. When making a particularly important measurement, it is recommended that you calibrate the sensor in advance. Caution •...
Page 112 Power sensor calibration When the power sensor is used continuously, slight variation may occur in its unloaded state. Correct this by calibrating it periodically. When making a particularly important measurement, it is recommended that you calibrate the sensor in advance. Caution •...
Page 113: Frequently Asked Questions
What does "completing measurement" mean? • "Completing measurement" refers to saving and uploading a trip or a series of trips from the save & upload screen in Cateye Cycling™. You can do this by tapping (ﬂag) on the trips screen in Cateye Cycling™.
Page 114 Why can't I upload activities to a service site? • Have you completed login settings for each service site? From Cateye Cycling™, tap (Menu) - [Account], and then complete login settings by entering account information for each site. Why does my smartphone battery drain so quickly? Have you been leaving [Connect] turned on in Cateye Cycling™...
Page 115: Abnormal Display : General
Strada Smart memory is full. If you are using Strada Smart with a smartphone, connect to Cateye Cycling™ and import data. This will clear the memory and the icon will turn off. If you are using Strada Smart by itself, this icon will have no affect on measurement.
Page 116: Abnormal Display : Altitude
Frequently Asked Questions Abnormal display : Altitude Why is there variation in measurement values for ascending altitude? As altitude measurement relies on the smartphone's GPS function, it may be different from the actual altitude.
Page 117: Abnormal Display : Heart Rate
Frequently Asked Questions Abnormal display : Heart rate Why are heart rate readings still displayed even after I take off the sensor? When using a sensor made by another company, heart rate may continue to be displayed for a long time after the sensor has been removed. Heart rate display is unstable.
Page 118: Abnormal Display : Power
Frequently Asked Questions Abnormal display : Power Power display is not accurate. How can I ﬁx it? Calibrate the power sensor. When measuring in Mirror Mode When measuring in Sensor Direct Mode or using Strada Smart by itself...
Page 119 * See the product page for information about model recommended for use with Cateye Cycling™. Have you paired your smartphone with Strada Smart? • If you do not pair Strada Smart via Cateye Cycling™, Strada Smart cannot perform Mirror Mode measurement. Smartphone : Pairing with Strada Smart Is [Connect] set to [ON] in the Cateye Cycling™...
Page 120 GPS when measuring speed.) Why is the sensor signal not being received? Have you paired the sensor? • You must pair Strada Smart with your smartphone via Cateye Cycling™. Smartphone : Pairing with a sensor Are you using a Bluetooth Smart sensor? •...
Page 121 When the smartphone moves away from the bicycle even for a short time, Strada Smart may automatically enter sleep mode. Clicking Strada Smart will make it enter smartphone search mode, allowing you to reconnect to your smartphone. Sleep Strada Smart operation is abnormal. What should I do? Restart your smartphone.
Page 122 Why is the sensor signal not being received? (When using Cateye Cycling™) Is [Connect] set to [ON] in the Cateye Cycling™ menu on your smartphone? • Set [Connect] to [OFF] or close Cateye Cycling™. Have you paired Strada Smart with the sensor? •...
Page 123 • The sensor must be paired with Strada Smart. Strada Smart : Pairing with a sensor Are you using a Bluetooth Smart sensor? • Strada Smart can only receive signals from Bluetooth Smart sensors. The sensor battery may be ﬂat. •...
Page 124 Why isn't the [H] icon ﬂashing? Have you paired the sensor? • The sensor must be paired with Cateye Cycling™ or with Strada Smart. When measuring in Mirror Mode When measuring in Sensor Direct Mode or using Strada Smart by itself The electrode pad may have slipped out of position.
Page 125 Why isn't the [P] icon ﬂashing? Have you paired the sensor? • The sensor must be paired with Cateye Cycling™ or with Strada Smart. When measuring in Mirror Mode When measuring in Sensor Direct Mode or using Strada Smart by itself The power sensor may not be attached correctly.
Page 126 Smartphone search screen Smartphone When Cateye Cycling™ detects Strada Smart, a message is displayed on the smartphone. Tap [Pair] to complete pairing. After pairing is completed, from (MENU) at the top left of the screen, tap [Trip] to...
Page 127 3. Tire circumference setting 1. Activate the sensor. Activating the sensor When Cateye Cycling™ detects the sensor signal, a message is displayed on the smartphone. Tap [Pair]. The synchronized sensor is displayed on the [Device] screen and pairing is completed.
Page 128 Pairing (Sensor ID synchronization) Pair a sensor that you want to use with Strada Smart. Important • Pairing (sensor ID synchronization) must be performed in order to use a sensor. • Do not pair sensors at a race venue or in similar locations where there are many other users.
Page 129 * Pairing standby time is 5 minutes. Activate the sensor within this time. 4. Press MENU to conﬁrm pairing. If you want to continue pairing another sensor, repeat the same operations again. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to conﬁrm changes.
Page 130 Mounting the speed (cadence) sensor (ISC-12) The speed (cadence) sensor can be mounted either on the top or bottom of the chain stay. Caution If the speed (cadence) sensor is mounted on the bottom of the chain stay rather than on the top, the adjustment range between the sensor and the magnet will be narrower.
Page 131 Sensor screw Sensor arm (2) Attach the sensor rubber pad to the sensor. Sensor rubber pad (3) Refer to the illustration and temporarily attach the sensor to the left chain stay with nylon ties. left chain stay Nylon tie Caution Do not fully tighten the nylon ties.
Page 132 the speed sensor zone. * If the sensor cannot is not positioned so that both magnets (speed and cadence) pass through their respective sensor zones, reposition the sensor and the magnets so that each magnet passes through its sensor zone. 3.
Page 133 Wearing the heart rate sensor (HR-12) Heart rate measurement is performed by wearing a heart rate sensor around the chest. Before wearing the heart rate sensor Warning Never use this device if you use a pacemaker. • To eliminate measurement errors, it is recommended to moisten the electrode pads with water or apply electrolyte cream to the pads.
Page 134 * Ensure that the electrode pads are in close contact with your body. * If you have dry skin or are wearing the sensor over a shirt, measurement errors may result. In such cases, moisten the electrode pads with water.
Page 135 Measurement search standby screen * If the connection is made when Cateye Cycling™ is already measuring, measured values are displayed. * The appearance of the Strada Smart screen depends on the state of Cateye Cycling™. Smartphone connection is now complete.
Page 136: Tire Circumference Setting
Tire circumference setting Set the tire circumference for a sensor capable of speed measurement. Important • Pairing (sensor ID synchronization) must be performed ﬁrst. Pairing (Sensor ID synchronization) • Set tire circumference for each sensor. The default value is 2,096 mm (700x23c). 1.
Page 137 • The LCD screen may be distorted when viewed through sunglasses with polarized lens. Cateye Cycling™ Strada Smart can be used with the Cateye Cycling™ smartphone app for measurement and settings. Downloading and using applications involves communication charges. It is therefore recommended to use Wi-Fi.
Page 138: Optional Accessories
Optional accessories The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners. 1603970...
Page 139 If the product fails to work due to normal use, CatEye will repair or replace the defect at no charge. Service must be performed by CatEye or an authorized retailer. To return the product, pack it carefully and...
Page 140 Insurance, handling and transportation charges to CatEye shall be borne by person desiring service. For UK and REPUBLIC OF IRELAND consumers, please return to the place of purchase. This does not affect your statutory rights.
Page 141 Legal Notices Changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
