* Instructions differ depending on the devices you have.
For troubleshooting related to the smart computers or to Cateye Cycling™, see "Frequently
Asked Questions".
* For explanatory purposes, in this manual red text/icons on the smart computer screen
represent flashing items.
* The display screens and illustrations used in this manual are provided for instructional
purposes only. Actual screens and illustrations may differ depending on devices used.
* The online manual and YouTube videos for this product are subject to change without
notice.
Usage Instructions
Select the devices you have.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Strada Smart CC-RD500B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cateye Strada Smart CC-RD500B

Summary of Contents for Cateye Strada Smart CC-RD500B

  • Page 1 Select the devices you have. * Instructions differ depending on the devices you have. For troubleshooting related to the smart computers or to Cateye Cycling™, see "Frequently Asked Questions". * For explanatory purposes, in this manual red text/icons on the smart computer screen represent flashing items.
  • Page 2 Setup method...

  • Page 3: Optional Accessories

    Setup (first time only) Mounting the bracket  If you have not yet purchased smart computer Setup (first time only)  Optional accessories Mounting the speed (cadence) sensor (ISC-12) Wearing the heart rate sensor (HR-12) * Mount non-CatEye sensors as directed in relevant instruction manuals.

  • Page 4: Checking Package Contents

    Setup with smartphone Checking package contents Bracket Smart computer unit Bracket band Bracket rubber pad Dial * The Speed + Cadence Kit includes an integrated speed (cadence) sensor (ISC-12) in addition to the items above. * The Triple Wireless Kit includes an integrated speed (cadence) sensor (ISC-12) and a heart rate sensor (HR-12).
  • Page 5 * If characters are lit on the LCD screen, you can use the product as is. Padrone Smart Strada Smart Open Press Close Insulation Slide sheet Waterproof inner cap Insulation sheet    Smartphone Setup uses the Cateye Cycling™ smartphone app (free). 1. Install Cateye Cycling™. If using an iPhone If using an Android smartphone...
  • Page 6 Important When the smartphone's Bluetooth settings are turned on, it will search for devices, but do not configure settings at this stage. Switch to Cateye Cycling™ and follow the procedure below. Once basic settings are complete the Trip screen appears.
  • Page 7 * If smart computer switches to the measurement screen without the whole screen turning on, it has not been formatted. Redo the procedure. * The appearance of the smart computer screen depends on the state of Cateye Cycling™. Smartphone When Cateye Cycling™...

  • Page 8: Mounting The Bracket

    Tap [Pair]. The synchronized sensor is displayed on the [Device] screen and pairing is completed. * When pairing a sensor with Cateye Cycling™, an "A" is displayed after the sensor name. * If you have paired a sensor capable of speed measurement, proceed to step 2.
  • Page 9 Setup Switching to Sensor Direct Mode Smartphone 1. Close Cateye Cycling™ or from (MENU), turn off [Connect]. Smart computer 2. Switch smart computer to Sensor Direct Mode. (1 second) Smartphone search Measurement screen screen (Sensor Direct Mode) * Smart computer will search for a sensor instead of your smartphone. In this mode, the sensor icon flashes to indicate sensor reception status.
  • Page 10 Setup Switching to Sensor Direct Mode Pairing (Sensor ID synchronization) Pair a sensor that you want to use with smart computer. Important • Pairing (sensor ID synchronization) must be performed in order to use a sensor. • Do not pair sensors at a race venue or in similar locations where there are many other users.
  • Page 11 • SP : Speed sensor • ISC : Speed/cadence sensor • CD : Cadence sensor • HR : Heart rate sensor • PW : Power sensor * When pairing a sensor with a smart computer, a "C" is displayed after the sensor name. Important When smart computer displays [FULL] on the screen and returns to the menu: Up to 9 separate sensor IDs can be paired with smart computer.
  • Page 12 Setup Switching to Sensor Direct Mode Pairing (Sensor ID synchronization) Tire circumference setting Set the tire circumference for a sensor capable of speed measurement. Important • Pairing (sensor ID synchronization) must be performed first. Pairing (Sensor ID synchronization) • Set tire circumference for each sensor. The default value is 2,096 mm (700x23c). 1.
  • Page 13 Increase numbers Move to next digit (2 seconds) * Sensors that can be selected are those that have been paired with Cateye Cycling™ or a smart computer. The letter that appears after the sensor name indicates how the sensor was paired.
  • Page 14 Setup with smartphone Checking package contents Setup Mounting the bracket The bracket can be mounted on either the stem or the handlebar. Watch video See illustrations • When mounting on the stem • When mounting on the handlebar • Mounting and removing the smart computer unit !When mounting on the stem 1.
  • Page 15 Dial Caution • Always tighten the dial by hand. Using a tool or other object to tighten the dial may crush the screw thread. • Trim bracket band carefully so the cut end will not cause injury (see step 3 above). !When mounting on the handlebar 1.
  • Page 16 Mounting Removing While holding smart computer Click Push out Caution To remove smart computer, push out while holding the unit with the other hand to ensure that it does not fall.
  • Page 17 Important When the smartphone's Bluetooth settings are turned on, it will search for devices, but do not configure settings at this stage. Switch to Cateye Cycling™ and follow the procedure below. Once basic settings are complete the Trip screen appears.
  • Page 18 Tap [Pair]. The verified sensor is displayed on the [Device] screen and pairing is completed. * When pairing a sensor with Cateye Cycling™, an "A" is displayed after the sensor name. * If you have paired a sensor capable of speed measurement, proceed to step 3.
  • Page 19 Setup with smartphone Mounting the speed (cadence) sensor (ISC-12) The speed (cadence) sensor can be mounted either on the top or bottom of the chain stay. Caution If the speed (cadence) sensor is mounted on the bottom of the chain stay rather than on the top, the adjustment range between the sensor and the magnet will be narrower.
  • Page 20 Sensor screw Sensor arm (2) Attach the sensor rubber pad to the sensor. Sensor rubber pad (3) Refer to the illustration and temporarily attach the sensor to the left chain stay with nylon ties. left chain stay Nylon tie Caution Do not fully tighten the nylon ties.
  • Page 21 the speed sensor zone. * If the sensor cannot is not positioned so that both magnets (speed and cadence) pass through their respective sensor zones, reposition the sensor and the magnets so that each magnet passes through its sensor zone. 3.
  • Page 22 Setup with smartphone Wearing the heart rate sensor (HR-12) Heart rate measurement is performed by wearing a heart rate sensor around the chest. Before wearing the heart rate sensor Warning Never use this device if you use a pacemaker. • To eliminate measurement errors, it is recommended to moisten the electrode pads with water or apply electrolyte cream to the pads.
  • Page 23 * Wear the heart rate sensor so that TOP faces up. * Ensure that the electrode pads are in close contact with your body. * If you have dry skin or are wearing the sensor over a shirt, measurement errors may result.
  • Page 24 Setup without smartphone  Setup without smartphone Checking package contents Setup (first time only) Mounting the bracket  Optional accessories Mounting the speed (cadence) sensor (ISC-12) Wearing the heart rate sensor (HR-12) * Mount non-CatEye sensors as directed in relevant instruction manuals.
  • Page 25 Setup without smartphone Checking package contents Bracket Smart computer unit Bracket band Bracket rubber pad Dial * The Speed + Cadence Kit includes an integrated speed (cadence) sensor (ISC-12) in addition to the items above. * The Triple Wireless Kit includes an integrated speed (cadence) sensor (ISC-12) and a heart rate sensor (HR-12).
  • Page 26 Setup without smartphone Checking package contents Setup Set up smart computer according to the procedure below when using it for the first time. Button operation Check button locations before starting set up. Padrone Smart Back Strada Smart Back Pull free the smart computer's insulation sheet. After you pull free the insulation sheet, return the battery cover to its previous location.
  • Page 27 The whole display turns on and then switches to the smartphone search screen. Whole display Smartphone search turns on screen Press MENU to proceed to the next step. * If smart computer switches to the measurement screen without the whole screen turning on, it has not been formatted.
  • Page 28 Ready for Sensor Synchronization synchronization activated complete The synchronized sensor is displayed on the top of the screen and pairing is completed. • SP : Speed sensor • ISC : Speed/cadence sensor • CD : Cadence sensor • HR : Heart rate sensor •...
  • Page 29 5. Set the time display mode and the time. Time display mode Select 24 h Select 12 h (2 seconds) (2 seconds) AM/PM (2 seconds) Hours Increase number (2 seconds) (2 seconds) Minutes Increase number Pressing MENU switches to the measurement screen. Setup is now complete.
  • Page 30 Setup without smartphone Checking package contents Setup Mounting the bracket The bracket can be mounted on either the stem or the handlebar. Watch video See illustrations • When mounting on the stem • When mounting on the handlebar • Mounting and removing the smart computer unit !When mounting on the stem 1.
  • Page 31 Dial Caution • Always tighten the dial by hand. Using a tool or other object to tighten the dial may crush the screw thread. • Trim bracket band carefully so the cut end will not cause injury (see step 3 above). !When mounting on the handlebar 1.
  • Page 32 Mounting Removing While holding smart computer Click Push out Caution To remove smart computer, push out while holding the unit with the other hand to ensure that it does not fall.
  • Page 33 Setup without smartphone Mounting the speed (cadence) sensor (ISC-12) The speed (cadence) sensor can be mounted either on the top or bottom of the chain stay. Caution If the speed (cadence) sensor is mounted on the bottom of the chain stay rather than on the top, the adjustment range between the sensor and the magnet will be narrower.
  • Page 34 Sensor screw Sensor arm (2) Attach the sensor rubber pad to the sensor. Sensor rubber pad (3) Refer to the illustration and temporarily attach the sensor to the left chain stay with nylon ties. left chain stay Nylon tie Caution Do not fully tighten the nylon ties.
  • Page 35 the speed sensor zone. * If the sensor cannot is not positioned so that both magnets (speed and cadence) pass through their respective sensor zones, reposition the sensor and the magnets so that each magnet passes through its sensor zone. 3.
  • Page 36 Setup without smartphone Wearing the heart rate sensor (HR-12) Heart rate measurement is performed by wearing a heart rate sensor around the chest. Before wearing the heart rate sensor Warning Never use this device if you use a pacemaker. • To eliminate measurement errors, it is recommended to moisten the electrode pads with water or apply electrolyte cream to the pads.
  • Page 37 * Wear the heart rate sensor so that TOP faces up. * Ensure that the electrode pads are in close contact with your body. * If you have dry skin or are wearing the sensor over a shirt, measurement errors may result.
  • Page 38 The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 39 All Activity Summary Activity List Upload Changing settings Cateye Cycling™ can be used to configure all settings for smart computer and connected devices. Important Sensor information on the smart computer is overwritten with data from Cateye Cycling™ when the smart computer connects to the smartphone.
  • Page 40 Measured values change every time MODE is pressed. • Speed/cadence/heart rate flash: If using a CATEYE sensor, the values related to the sensor's battery replacement period start flashing to indicate that it is time to replace the battery. Battery replacement : Optional sensors •...
  • Page 41 After the icon turns on, the oldest summary data is deleted to create space to record new data. * Memory is used to record summary data in Sensor Direct Mode. * Memory can be cleared by importing summary data into Cateye Cycling™. Importing summary data (Pace arrows)
  • Page 42 • • • (Measurement unit) Displays the currently selected measurement unit. • On Measurement stopped • Flashing Measurement in progress (Average) Indicates that the currently displayed value is an average value. (Maximum) Indicates that the currently displayed value is a maximum value. Current function Indicates the currently displayed function.
  • Page 43 Smartphone and smart computer Cateye Cycling™ [Trip] screen This is the Cateye Cycling™ home screen. From this screen you can start, pause, and finish measurement. * Starting, pausing, and finishing measurement can be done remotely from the smart computer unit.
  • Page 44 * Speed (cadence) sensors (ISC) display both Quick Set The Quick Set function allows various measurement functions to be turned ON/OFF quickly. GPS icon Indicates GPS signal reception status. Calibration button Performs power sensor calibration. Power sensor calibration Switch display mode Swiping the screen switches to the map display, graph display, and lap display, letting you check the process of the trip.
  • Page 45 Lap display * “A” (for auto lap) will appear after the lap number. Start measurement button Starts measurement. * Not available if speed signal or GPS signal cannot be received. Pause button Pauses measurement. Flag button Finishes measurement. Switches to the trip upload screen. Saving and uploading trips Number of temporarily saved trips Displays the number of temporarily saved trips.

  • Page 46: Preparation Before Measurement

    Smartphone search Measurement screen standby * If the connection is made when Cateye Cycling™ is already measuring, [PAUSE] and measured values are displayed. * The appearance of the smart computer screen depends on the state of Cateye Cycling™. Smartphone connection is now complete.
  • Page 47 Smartphone and smart computer Connecting smart computer and smartphone Preparation before measurement To use the automatic lap function, it must be turned on before starting measurement. This section also explains the quick set feature for quickly configuring settings from the Trip screen.

  • Page 48: Starting Measurement

    Important • Smartphone use When measuring, turn the smartphone display off, and with Cateye Cycling™ running, store the smartphone in a safe place such as a bag or pocket. As measurement start/pause/resume and reset operations (finish trip) can be performed remotely from smart computer, there is no need to take out your smartphone until you want to save or upload trips.
  • Page 49 Saving and uploading trips !Functions during measurement Switching measurement data display Smart computer You can switch the display of data being measured in Cateye Cycling™ by pressing MODE. * The data displayed changes depending on the state of the sensor connection.
  • Page 50 * Heart rate and cadence data will not be displayed unless each sensor is paired. Auto lap function Smartphone Cateye Cycling™ makes it possible to record laps automatically without any button operation.
  • Page 51 Set the method—distance, time, or location—to be used for the automatic lap function. Recorded laps can be viewed on Cateye Cycling™ or the Cateye Atlas™ website. General : Auto Lap Auto pause function Smart computer This function automatically pauses measurement when the connection between the smartphone and smart computer is broken.
  • Page 52 If you have power sensors When a signal is received from a paired power sensor, power is displayed as one of the current functions. Smart computer Power Smartphone Power * When the power value exceeds 999, the last three digits are displayed. * To increase precision, it is recommended to perform calibration before power measurement.
  • Page 53 * You must have an account with the relevant site to upload data. Account * Cateye Cycling™ only allows you to post links of trips uploaded to CATEYE Atlas™ on Facebook™ and Twitter™. Links to other service sites cannot be posted.

  • Page 54: Activity List

    Smartphone and smart computer All Activity Summary Smartphone 1. Tap (MENU) and then [All Activity Summary]. * It is possible to check total values for all activities saved with Cateye Cycling™ and maximum values for individual trips. Activity List Upload...
  • Page 55 Smartphone and smart computer All Activity Summary Activity List You can check activities (the collective term for trip data and summary data) from the Activity List. Smartphone 1. Tap (MENU) and then [Activity List]. * The Activity List can be displayed in graph, list, or calendar format. * Tapping (Select to Delete) moves to the activity deletion screen.
  • Page 56 Smartphone and smart computer All Activity Summary Activity List Upload All activities can be uploaded to service sites in one action. Smartphone 1. Tap (MENU) and then [Upload]. * Activities already uploaded to service sites are not displayed. 2. Select the activities you want to upload and tap (Upload) to upload them to the specified sites.
  • Page 57 Smartphone and smart computer General This section explains how to configure various measurement settings. Smartphone 1. Tap (MENU) and then [General]. • Recording Interval Selects the interval at which the log is recorded. • Units Selects the measurement unit. Important When the unit is changed when smart computer is not connected to your smartphone, you will be prompted to select a unit the next time you connect.
  • Page 58 Smartphone and smart computer General Device The following section explains how to pair a smart computer with a sensor and how to configure various settings. Important • Device settings are shared when smart computer is connected to your smartphone. If settings differ, you will be prompted to select which settings to sync. •...
  • Page 59 • Nickname Changes the name of the smart computer. • Notification Setting Configures settings for incoming phone, email, and SMS (Text) notifications and smartphone remaining battery notification. * The SMS (Text) notification feature is only available on Padrone Smart. • Auto Pause This function automatically pauses measurement when the connection between smart computer and your smartphone is interrupted if you move away from the bicycle with your smartphone during measurement.
  • Page 60 Determining tire circumference * See the following for pairing with a smart computer or a sensor. Pairing Account...
  • Page 61 * You must have an account with the relevant site to upload data. Service sites ・ CATEYE Atlas™ ・ STRAVA™ ・ TRAINING PEAKS™ ・ Facebook™ ・ Twitter™ * When using an SNS, links to activities uploaded to Cateye Atlas™ are posted.
  • Page 62 (speed, cadence, heart rate, and power). The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 63 Upload Importing summary data measured in Sensor Direct Mode Changing settings Cateye Cycling™ can be used to configure all settings for smart computer and connected devices. Important • Sensor information on the smart computer is overwritten with data from Cateye Cycling™...
  • Page 64 * If the values flash on and off, it is time to replace the sensor battery. • Speed/cadence/heart rate flash: If using a CATEYE sensor, the values related to the sensor's battery replacement period start flashing to indicate that it is time to replace the battery.
  • Page 65 After the icon turns on, the oldest summary data is deleted to create space to record new data. * Memory is used to record summary data in Sensor Direct Mode. * Memory can be cleared by importing summary data into Cateye Cycling™. Importing summary data (Pace arrows)
  • Page 66 • (Trip Distance 2) • (Current Speed) • (Cadence) • (Power) • (Clock)

  • Page 67: Starting/Stopping Measurement

    Smartphone and smart computer Switching to Sensor Direct Mode Smartphone 1. Close Cateye Cycling™ or from (MENU), check that [Connect] is turned off. Smart computer 2. From the smartphone search screen, press MODE for 1 second to switch to Sensor Direct Mode.
  • Page 68 Smartphone and smart computer Switching to Sensor Direct Mode Starting/stopping measurement  Starting/stopping measurement Smart computer Measurement starts automatically when the bicycle moves. During measurement the measurement unit flashes. * The pause function is not available in Sensor Direct Mode.  Saving measurement data (reset operation) Smart computer Pressing and holding MODE when on the measurement screen generates Reset...
  • Page 69 Smart computer Pressing MODE switches the measurement data displayed at the bottom of the screen. * The data displayed changes depending on the state of the sensor connection.
  • Page 70 * Heart rate and cadence data will not be displayed unless each sensor is paired. *Average values are displayed as .E instead of the measurement value when Elapsed Time exceeds approximately 27 hours. Average speed is also displayed as .E instead of the measurement value when Trip Distance exceeds 1,000 km [620 mile].
  • Page 71 * When the power value exceeds 999, the last three digits are displayed. * To increase precision, it is recommended to perform calibration before power measurement. Power sensor calibration...

  • Page 72: Activity List

    All Activity Summary Smartphone 1. Tap (MENU) and then [All Activity Summary]. * It is possible to check total values for all activities saved with Cateye Cycling™ and maximum values for individual trips. Activity List Upload Importing summary data measured...
  • Page 73 Smartphone and smart computer All Activity Summary Activity List You can check activities (the collective term for trip data and summary data) from the Activity List. Smartphone 1. Tap (MENU) and then [Activity List]. * The Activity List can be displayed in graph, list, or calendar format. * Tapping (Select to Delete) moves to the activity deletion screen.
  • Page 74 Upload Importing summary data measured in Sensor Direct Mode...
  • Page 75 Smartphone and smart computer All Activity Summary Activity List Upload All activities can be uploaded to service sites in one action. Smartphone 1. Tap (MENU) and then [Upload]. * Activities already uploaded to service sites are not displayed. 2. Select the activities you want to upload and tap (Upload) to upload them to the specified sites.
  • Page 76 You cannot import data for which measurement has not finished. Reset operation Smartphone 1. Launch Cateye Cycling™, and from (MENU) turn on [Connect]. Smart computer 2. On the measurement screen, press MODE for 1 second to display the smartphone search screen and connect with your smartphone.
  • Page 77 * The appearance of the smart computer screen depends on the state of Cateye Cycling™. * It is not possible to import data while measuring with Cateye Cycling™. Smartphone 3. Tap (MENU) and then [Activity List]. If there is summary data in smart computer, the (Import from CC) is displayed.
  • Page 78 Smartphone and smart computer General This section explains how to configure various measurement settings. Smartphone 1. Tap (MENU) and then [General]. • Recording Interval Selects the interval at which the log is recorded. • Units Selects the measurement unit. Important When the unit is changed when smart computer is not connected to your smartphone, you will be prompted to select a unit the next time you connect.
  • Page 79 Smartphone and smart computer General Device The following section explains how to pair a smart computer with a sensor and how to configure various settings. Important • Device settings are shared when smart computer is connected to your smartphone. If settings differ, you will be prompted to select which settings to sync. •...
  • Page 80 • Nickname Changes the name of the smart computer. • Notification Setting Configures settings for incoming phone, email, and SMS (Text) notifications and smartphone remaining battery notification. * The SMS (Text) notification feature is only available on Padrone Smart. • Auto Pause This function automatically pauses measurement when the connection between smart computer and your smartphone is interrupted if you move away from the bicycle with your smartphone during measurement.
  • Page 81 Determining tire circumference * See the following for pairing with a smart computer or a sensor. Pairing Account...
  • Page 82 * You must have an account with the relevant site to upload data. Service sites ・ CATEYE Atlas™ ・ STRAVA™ ・ TRAINING PEAKS™ ・ Facebook™ ・ Twitter™ * When using an SNS, links to activities uploaded to Cateye Atlas™ are posted.
  • Page 83 Smartphone and smart computer Pairing (Sensor ID synchronization) Pair a sensor that you want to use with smart computer. Important • Pairing (sensor ID synchronization) must be performed in order to use a sensor. • Do not pair sensors at a race venue or in similar locations where there are many other users.
  • Page 84 Important When smart computer displays [FULL] on the screen and returns to the menu: Up to 9 separate sensor IDs can be paired with smart computer. If the maximum number of sensors have been paired, with the computer in pairing standby state, press MENU for 4 seconds to clear all pairings.
  • Page 85 Smartphone and smart computer Pairing (Sensor ID synchronization) Tire circumference setting Set the tire circumference for a sensor capable of speed measurement. Important • Pairing (sensor ID synchronization) must be performed first. Pairing (Sensor ID synchronization) • Set tire circumference for each sensor. The default value is 2,096 mm (700x23c). 1.
  • Page 86 Sensor selection (2 seconds) (2 seconds) Tire circumference value Increase numbers Move to next digit (2 seconds) * Only paired sensors can be selected. * Error is displayed if values outside the setting range are entered. 4. Press MENU to confirm settings. Pressing MENU again returns to the measurement screen.
  • Page 87 (speed, cadence, heart rate, and power). The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 88 * If the values flash on and off, it is time to replace the sensor battery. • Speed/cadence/heart rate flash: If using a CATEYE sensor, the values related to the sensor's battery replacement period start flashing to indicate that it is time to replace the battery.
  • Page 89 (Memory alarm) This information is required when syncing with a smartphone. Measurement is not affected if this icon turns on. (Pace arrows) Indicate whether the current speed is faster ( ) or slower ( ) than the average speed. (Sensor signal icon) Indicates the Bluetooth®...
  • Page 90 • (Power) • (Clock)

  • Page 91: Starting/Stopping Measurement

    Smart computer Starting/stopping measurement  Starting/stopping measurement Measurement starts automatically when the bicycle moves. During measurement the measurement unit flashes.  Reset operation Reset Pressing and holding MODE when on the measurement screen resets measurement data to 0. * When MODE has been pressed for 1 second, a smartphone search screen appears, but you should continue to hold down the button.
  • Page 92 * Heart rate and cadence data will not be displayed unless each sensor is paired. *Average values are displayed as .E instead of the measurement value when Elapsed Time exceeds approximately 27 hours. Average speed is also displayed as .E instead of the measurement value when Trip Distance exceeds 1,000 km [620 mile].

  • Page 93: Power Saving Mode

    Reset operation  Power-saving mode If there is no sensor signal or button operation for 10 minutes, the power-saving screen is activated. If such a state continues for a further hour, the sleep display is activated. The power-saving screen returns to the measurement screen when the bicycle starts moving.

  • Page 94: Clock Setting

    Smart computer Clock setting 1. From the measurement screen, press MENU to switch to the menu screen. Measurement Menu screen screen (Clock setting) * When the menu screen is left on for 1 minute, smart computer returns to the measurement screen. 2.
  • Page 95 Time display mode Select 24 h Select 12 h (2 seconds) (2 seconds) AM/PM (2 seconds) Hours Increase number (2 seconds) (2 seconds) Minutes Increase number 4. Press MENU to confirm settings. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to confirm changes.
  • Page 96 Smart computer Clock setting Tire circumference setting Set the tire circumference for a sensor capable of speed measurement. Important • Pairing (sensor ID synchronization) must be performed first. Pairing (Sensor ID synchronization) • Set tire circumference for each sensor. The default value is 2,096 mm (700x23c). 1.

  • Page 97: Function Setting

    Increase numbers Move to next digit (2 seconds) * Sensors that can be selected are those that have been paired with Cateye Cycling™ or a smart computer. The letter that appears after the sensor name indicates how the sensor was paired.
  • Page 98 Smart computer Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Pair a sensor that you want to use with smart computer. Important • Pairing (sensor ID synchronization) must be performed in order to use a sensor. • Do not pair sensors at a race venue or in similar locations where there are many other users.
  • Page 99 The synchronized sensor is displayed on the top of the screen and pairing is completed. • SP : Speed sensor • ISC : Speed/cadence sensor • CD : Cadence sensor • HR : Heart rate sensor • PW : Power sensor * When pairing a sensor with a smart computer, a "C"...
  • Page 100 Smart computer Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Switch top of screen display You can choose to display current speed, cadence, or heart rate at the top of the screen. Important Measurement items that require a sensor that is not paired cannot be selected. 1.
  • Page 101 Current speed Cadence Heart rate Cadence Current speed Heart rate Heart rate Cadence Current speed 4. Press MENU to confirm settings. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to confirm changes. Function setting Total distance manual input Measurement unit setting...
  • Page 102 Smart computer Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Switch top of screen display Function setting It is possible to skip certain functions displayed at the bottom of the screen. 1. From the measurement screen, press MENU to switch to the menu screen.
  • Page 103 (2 seconds) * Current speed, elapsed time, heart rate, cadence, and power cannot be skipped. 4. Press MENU to confirm settings. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to confirm changes. Total distance manual input Measurement unit setting...
  • Page 104 Smart computer Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Switch top of screen display Function setting Total distance manual input If you enter a desired value for total distance, you can start your next trip from that value. * This function is useful when you want to continue from the same distance after purchasing a new smart computer or when resetting smart computer.
  • Page 105 Increase number Move to next digit (2 seconds) 4. Press MENU to confirm settings. Pressing MENU again returns to the measurement screen. *If you have changed settings, always press MENU to confirm changes. Measurement unit setting...
  • Page 106 Smart computer Clock setting Tire circumference setting Pairing (Sensor ID synchronization) Switch top of screen display Function setting Total distance manual input Measurement unit setting You can select the measurement unit (km or miles). 1. From the measurement screen, press MENU to switch to the menu screen.
  • Page 107 4. Press MENU to confirm settings. Pressing MENU again returns to the measurement screen. * If you have changed settings, always press MENU to confirm changes. * When the measurement unit is changed, existing measurement data is automatically converted to the new unit.
  • Page 108 Battery replacement ! Smart computer Padrone Smart When (battery icon) turns on, it is time to replace the battery. Install a new lithium battery (CR2032) with the (+) side facing upward. Close Open * After replacing the battery, press AC on the back of the computer. (Restart operation) Strada Smart When...
  • Page 109 Speed (cadence) sensor (ISC-12) Important If using a CATEYE sensor, the values related to the sensor's battery replacement period start flashing to indicate that it is time to replace the battery. If smart computer's current speed or cadence display starts flashing, it is time to replace the battery.

  • Page 110: Activating The Sensor

    Activating the sensor Activate the sensor via the following method: • Speed sensor / Speed (cadence) sensor (ISC) / Cadence sensor Move the magnet through the sensor zone several times. (Within 3 mm) Sensor zone Magnet • Heart rate sensor Rub both electrode pads with thumbs to transmit heart rate signal.
  • Page 111 Determining tire circumference Determine tire circumference (L) by referring to the tire size chart or by measuring the actual circumference of your bicycle tire. Tire circumference reference table * The tire size or ETRTO code is indicated on the side of the tire.
  • Page 112 Measure actual tire circumference With tire air pressure adjusted appropriately, apply a load to the bicycle. Using the valve, etc., as a marker, rotate the tire once and measure the distance traveled along the ground. When using front When using rear wheel for speed wheel for speed measurement...
  • Page 113 Power sensor calibration When the power sensor is used continuously, slight variation may occur in its unloaded state. Correct this by calibrating it periodically. When making a particularly important measurement, it is recommended that you calibrate the sensor in advance. Caution •...
  • Page 114 Power sensor calibration When the power sensor is used continuously, slight variation may occur in its unloaded state. Correct this by calibrating it periodically. When making a particularly important measurement, it is recommended that you calibrate the sensor in advance. Caution •...

  • Page 115: Frequently Asked Questions

    In the Event PADRONE SMART Becomes Unstable after Updating Cateye Cycling™ (iPhone Only) After updating Cateye Cycling™ for iPhone, if the PADRONE SMART does not easily connect to the iPhone, or if the PADRONE SMART or data display does not operate properly, follow the procedure below to change the iPhone’s notification settings.
  • Page 116 What does "completing measurement" mean? • "Completing measurement" refers to saving and uploading a trip or a series of trips from the save & upload screen in Cateye Cycling™. You can do this by tapping (flag) on the trips screen in Cateye Cycling™.
  • Page 117 Continue measurement as normal. Why are measurement values flashing on and off? If using a CATEYE sensor, measurement values start flashing to indicate that there is little remaining battery power in the relevant sensor. Replace the battery for the relevant sensor.
  • Page 118 Frequently Asked Questions Abnormal display : Heart rate Why are heart rate readings still displayed even after I take off the sensor? When using a sensor made by another company, heart rate may continue to be displayed for a long time after the sensor has been removed. Heart rate display is unstable.
  • Page 119 Frequently Asked Questions Abnormal display : Power Power display is not accurate. How can I fix it? Calibrate the power sensor. When measuring in Mirror Mode When measuring in Sensor Direct Mode or using smart computer by itself...
  • Page 120 Frequently Asked Questions Abnormal display : Altitude Why is there variation in measurement values for ascending altitude? As altitude measurement relies on the smartphone's GPS function, it may be different from the actual altitude.
  • Page 121 * See Cateye Cycling Recommended Devices for the latest information about smartphones recommended for use with Cateye Cycling™. Have you paired your smartphone with smart computer? • If you do not pair smart computer via Cateye Cycling™, smart computer cannot perform Mirror Mode measurement. Smartphone : Pairing with smart computer Is [Connect] set to [ON] in the Cateye Cycling™...
  • Page 122 GPS when measuring speed.) Why is the sensor signal not being received? Have you paired the sensor? • You must pair smart computer with your smartphone via Cateye Cycling™. Smartphone : Pairing with a sensor Are you using a Bluetooth Smart sensor?
  • Page 123 Press the reset button on the sensor. If this does not resolve the issue, restart your smartphone. If you cannot reconnect to the smart computer Cateye Cycling™ may have terminated abnormally. • Start Cateye Cycling™. If this does not resolve the issue, try the procedure below: •...
  • Page 124 If this does not resolve the issue, press the AC button on the back of smart computer. (Restart operation)
  • Page 125 Why is the sensor signal not being received? (When using Cateye Cycling™) Is [Connect] set to [ON] in the Cateye Cycling™ menu on your smartphone? • Set [Connect] to [OFF] or close Cateye Cycling™. Have you paired smart computer with the sensor? •...
  • Page 126 Smart computer : Pairing with a sensor Are you using a Bluetooth Smart sensor? • Smart computer can only receive signals from Bluetooth Smart sensors. The sensor battery may be flat. • Replace the battery with a new one. Battery replacement : Optional sensors The magnet may not be in the correct position relative to the speed sensor or speed (cadence) sensor (ISC).
  • Page 127 Why isn't the [H] icon flashing? Have you paired the sensor? • The sensor must be paired with Cateye Cycling™ or with smart computer. When measuring in Mirror Mode When measuring in Sensor Direct Mode or using smart computer by itself The electrode pad may have slipped out of position.
  • Page 128 Why isn't the [P] icon flashing? Have you paired the sensor? • The sensor must be paired with Cateye Cycling™ or with smart computer. When measuring in Mirror Mode When measuring in Sensor Direct Mode or using smart computer by itself The power sensor may not be attached correctly.
  • Page 129 Smartphone search Measurement screen standby * If the connection is made when Cateye Cycling™ is already measuring, [PAUSE] and measured values are displayed. * The appearance of the smart computer screen depends on the state of Cateye Cycling™. Smartphone connection is now complete.
  • Page 130 Smartphone search screen Smartphone When Cateye Cycling™ detects smart computer, a message is displayed on the smartphone. Tap [Pair] to complete pairing. After pairing is completed, from (MENU) at the top left of the screen, tap [Trip] to...
  • Page 131 Tap [Pair]. The synchronized sensor is displayed on the [Device] screen and pairing is completed. * When pairing a sensor with Cateye Cycling™, an "A" is displayed after the sensor name. * If you have paired a sensor capable of speed measurement, proceed to step 2.
  • Page 132 Pairing (Sensor ID synchronization) Pair a sensor that you want to use with smart computer. Important • Pairing (sensor ID synchronization) must be performed in order to use a sensor. • Do not pair sensors at a race venue or in similar locations where there are many other users.
  • Page 133 • HR : Heart rate sensor • PW : Power sensor * When pairing a sensor with a smart computer, a "C" is displayed after the sensor name. Important When smart computer displays [FULL] on the screen and returns to the menu: Up to 9 separate sensor IDs can be paired with smart computer.
  • Page 134 Tire circumference setting Set the tire circumference for a sensor capable of speed measurement. Important • Pairing (sensor ID synchronization) must be performed first. Pairing (Sensor ID synchronization) • Set tire circumference for each sensor. The default value is 2096 mm (700x23c). 1.
  • Page 135 Increase numbers Move to next digit (2 seconds) * Sensors that can be selected are those that have been paired with Cateye Cycling™ or a smart computer. The letter that appears after the sensor name indicates how the sensor was paired.
  • Page 136 Mounting the speed (cadence) sensor (ISC-12) The speed (cadence) sensor can be mounted either on the top or bottom of the chain stay. Caution If the speed (cadence) sensor is mounted on the bottom of the chain stay rather than on the top, the adjustment range between the sensor and the magnet will be narrower.
  • Page 137 Sensor screw Sensor arm (2) Attach the sensor rubber pad to the sensor. Sensor rubber pad (3) Refer to the illustration and temporarily attach the sensor to the left chain stay with nylon ties. left chain stay Nylon tie Caution Do not fully tighten the nylon ties.
  • Page 138 the speed sensor zone. * If the sensor cannot is not positioned so that both magnets (speed and cadence) pass through their respective sensor zones, reposition the sensor and the magnets so that each magnet passes through its sensor zone. 3.
  • Page 139 Wearing the heart rate sensor (HR-12) Heart rate measurement is performed by wearing a heart rate sensor around the chest. Before wearing the heart rate sensor Warning Never use this device if you use a pacemaker. • To eliminate measurement errors, it is recommended to moisten the electrode pads with water or apply electrolyte cream to the pads.
  • Page 140 * Ensure that the electrode pads are in close contact with your body. * If you have dry skin or are wearing the sensor over a shirt, measurement errors may result. In such cases, moisten the electrode pads with water.
  • Page 141 • The LCD screen may be distorted when viewed through sunglasses with polarized lens. Cateye Cycling™ Smart computer can be used with the Cateye Cycling™ smartphone app for measurement and settings. Downloading and using applications involves communication charges. It is therefore recommended to use Wi-Fi.
  • Page 142 Lithium battery (CR2032) Optional accessories The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by CATEYE Co., Ltd. is under license. Other trademarks and trade names are those of their respective owners.
  • Page 143 (When ISC-12 and HR-12 are paired and used for one hour a day.) • Strada Smart unit: Lithium battery (CR2032) x1 / Approximately 5 months (When ISC-12 and HR-12 are paired and used for one hour a day.) ! Optional sensors •...
  • Page 144 If the product fails to work due to normal use, CatEye will repair or replace the defect at no charge. Service must be performed by CatEye or an authorized retailer. To return the product, pack it carefully and enclose the warranty certificate (proof of purchase) with instruction for repair.
  • Page 145 Legal Notices Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

This manual is also suitable for:

Padrone smart cc-pa500b

Table of Contents
