Printer Inside Parts
1
2
3
4
5
6
7
8
9
Fig. 1
Inside of Printer with Ribbon Mechanism open in an upright position
-10-
1. Supply Loading Diagram
2. Label Supply Roll
3. Label Roll Mounts
4. Fixing Tabs
5. Tefl on Bar
(white)
6. Adjustable Label Guides
7. Media Sensor/Black Mark Sensor
8. Platen Roller
9. Printed Label Opening
(turquoise)
(black)
(turquoise)
