Summary of Contents for DuraLabel LabPRO
- Page 1 DuraLabel LabPRO ® QuickStart Guide Read Me Graphic Products, Inc. 1-800-788-5572 503-644-5572 First! Local: www.DuraLabel.com www.GraphicProducts.com info GraphicProducts.com E-mail:...
-
Page 2: Minimum System Requirements
8. Check through the list provided and click “Finish.” 9. Click “Restart.” The DuraLabel LabPRO printer driver may now be installed. Begin with page 7, ® Step 2 Connect Printer of the QuickStart Guide. © 2008, 2009 Graphic Products, Inc. -
Page 3: Table Of Contents
With this guide you will learn how to set up your printer, load supplies and print labels. The ribbon and various print media for the DuraLabel LabPRO have been ®... -
Page 4: What You Should Receive
WHAT YOU SHOULD RECEIVE 2 Ribbon Spindles, (1 with an empty paper core) DuraLabel LabPRO Installation CD & ® DuraLabel LabPRO QuickStart Guide ® USB Cable DuraLabel LabPRO Label Supply Spindle AC Adapter ® Thermal Transfer Printer & 2 Fixing Tabs... -
Page 5: Contents Of Package
Thermal Transfer Printer Label Supply Spindle & 2 Fixing Tabs AC Adapter 2 Ribbon Spindles, (1 with an empty paper core) Contents of Package: ▪ DuraLabel LabPRO Thermal Transfer Printer ® ▪ DuraLabel LabPRO Installation CD ® ▪ DuraLabel LabPRO QuickStart Guide ®... -
Page 6: Load Printer
1. LOAD PRINTER See the Load Printer section (pages 3-10) in the User's Guide for a more detailed explanation of supply loading. The ribbon and various print media for the DuraLabel LabPRO have been ® optimized for compatibility and print quality. Only authorized supplies from Graphic Products will print correctly in the DuraLabel LabPRO. - Page 7 2. Place Ribbon Supply onto the empty Ribbon Supply Spindle and insert the spindle into the Rear Hub. 3. Place the Ribbon Rewind Spindle, with the paper core, on the Front Hub. Note: Make sure the flanges on the end of the ribbon spindles are on the right side of the printer when viewing from the front.
-
Page 8: Load Vinyl Tape
Load Vinyl Tape **IMPORTANT** Always turn OFF the power first! 1. With the Ribbon Mechanism still in upright position, center the Label Stock on the Label Supply Roll Spindle using the Fixing Tabs. (See Figure 4) Figure 4 Fixing Tab Vinyl Tape Printing Side Face Up... -
Page 9: Connect Printer
These Steps need to be done in the order below! 1. Connect the power supply. 2. Connect the DuraLabel LabPRO to your PC using the USB or parallel cable. ® 3. Turn on the DuraLabel LabPRO. (Switch is in back of printer, See Figure 6) ®... -
Page 10: Install Using Parallel Cable
15. Select “No” to “Do you want to print a test page,” click “Next.” 16. Click “Finish” on the Add Printer Wizard dialog box. 17. When prompted to continue, click “Continue Anyway.” 18. Click “Finish” on the DuraLabel LabPRO Driver Setup dialog box to complete the installation. - -... -
Page 11: Set Up To Print
Continuous Label Stock The Default Printing Preferences on your DuraLabel LabPRO should be at the proper ® settings for printing on continuous vinyl and should require no adjustments. To change settings: 1. - Page 12 P.O. Box 4030 www.DuraLabel.com 1-800-788-5572 Beaverton, OR 97076 © 2008, 2009, Graphic Products, Inc. All Rights Reserved v. 1.0 - 9/8/09...
