MATRIX GX3000S
25 Watt VHF/FM
ITU Class D DSC Marine Transceiver
Owner's Manual
Waterproof construction
Commercial grade ITU Class D DSC VHF
Independent Channel 70 receiver built-in for continuous DSC watching
30 W Loud Hailer with listen back and 4 fog horns, Bells & Whistles
Capable of connecting 2 optional enhanced CMP25 RAM+ second sta-
tion remote microphone or VH-310 Handset
Intercom between radio and second station microphone
DSC position request and send functions with compatible STANDARD
HORIZON GPS Chart plotters
Versatile user-programmable scanning, priority scan and Dual Watch
One-button access to Channel 16 and 9
Oversized rotary channel knob, backlit display and keys.
Navigation information shown on display when optional GPS connected
Unique Receive Audio Tone Control
GX3000S
Page 1
