Standard Horizon 30143X3D Owner's Manual

25 watt vhf/fm itu class d dsc marine transceiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FCC ID: K6630143X3D/IC ID: 511B-30143X3D
MATRIX GX3000S
25 Watt VHF/FM
ITU Class D DSC Marine Transceiver
Owner's Manual
Waterproof construction
Commercial grade ITU Class D DSC VHF
Independent Channel 70 receiver built-in for continuous DSC watching
30 W Loud Hailer with listen back and 4 fog horns, Bells & Whistles
Capable of connecting 2 optional enhanced CMP25 RAM+ second sta-
tion remote microphone or VH-310 Handset
Intercom between radio and second station microphone
DSC position request and send functions with compatible STANDARD
HORIZON GPS Chart plotters
Versatile user-programmable scanning, priority scan and Dual Watch
One-button access to Channel 16 and 9
Oversized rotary channel knob, backlit display and keys.
Navigation information shown on display when optional GPS connected
GX3000S
Page 1
Vertex Standard Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 30143X3D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Standard Horizon 30143X3D

Summary of Contents for Standard Horizon 30143X3D

  • Page 1 FCC ID: K6630143X3D/IC ID: 511B-30143X3D MATRIX GX3000S 25 Watt VHF/FM ITU Class D DSC Marine Transceiver Owner's Manual Waterproof construction Commercial grade ITU Class D DSC VHF Independent Channel 70 receiver built-in for continuous DSC watching 30 W Loud Hailer with listen back and 4 fog horns, Bells & Whistles...

  • Page 2: Table Of Contents

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D TABLE OF CONTENTS GENERAL INFORMATION ..................... 4 PACKING LIST ........................4 OPTIONS ..........................4 SAFETY / WARNING INFORMATION ................... 5 FCC RADIO LICENSE INFORMATION ................. 6 FCC NOTICE .......................... 7 GETTING STARTED ....................... 8 ABOUT VHF RADIO ....................8 SELECTING AN ANTENNA ..................
  • Page 3 FCC ID: K6630143X3D/IC ID: 511B-30143X3D TABLE OF CONTENTS 11.5 INDIVIDUAL CALL ...................... 41 11.5.1 Setting up the Individual / Position Call Directory ......... 41 11.5.2 Setting up Individual Ringer ................42 11.5.3 Setting up Individual / Group Call Ringer ............43 11.5.4 Transmitting an Individual Call .................

  • Page 4: General Information

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 1 GENERAL INFORMATION The Vertex Standard GX3000S is a VHF/FM transceiver designed for use in the frequency range of 156.025 to 163.275 MHz. The GX3000S can be oper- ated from 11 to 16 VDC and has a switchable RF output power of 1 watt or 25 watts.

  • Page 5: Safety / Warning Information

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 4 SAFETY / WARNING INFORMATION This radio is restricted to occupational use, work related operations only where the radio operator must have the knowledge to control the exposure conditions of its passengers and bystanders by maintaining the minimum separation dis- tance of 0.6 m (2 feet).

  • Page 6: Fcc Radio License Information

    Type Acceptance ................FCC Part 80 Output Power ..........1 Watt (low) and 25 Watts (high) Emission ................16K0G3E, 16K0G2B Frequency Range ............156.025 to 163.275 MHz FCC Type Number ..............K6630143X3D Industry Canada Type Approval ..........511B-30143X3D Page 6 GX3000S Vertex Standard Co., Ltd.

  • Page 7: Fcc Notice

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 6 FCC NOTICE NOTICE Unauthorized changes or modifications to this equipment may void com- pliance with FCC Rules. Any change or modification must be approved in writing by Marine Division of Vertex Standard. NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 8: Getting Started

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 7 GETTING STARTED 7.1 ABOUT VHF RADIO The radio frequencies used in the VHF marine band lie between 156 and 158 MHz with some shore stations available between 161 and 163 MHz. The ma- rine VHF band provides communications over distances that are essentially “line of sight”...

  • Page 9: Coaxial Cable

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 7.3 COAXIAL CABLE VHF antennas are connected to the transceiver by means of a coaxial cable – a shielded transmission line. Coaxial cable is specified by it’s diameter and construction. For runs less than 20 feet, RG-58/U, about 1/4 inch in diameter is a good choice.

  • Page 10: Installation

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 8 INSTALLATION 8.1 LOCATION The radio can be mounted at any angle. Choose a mounting location that: • is far enough from any compass to avoid any deviation in compass read- ing due to the speaker magnet •...

  • Page 11: Accessory Cable

    The NMEA supported sentences are: Input: GLL, GGA, RMC and GNS (RMC sentence is recommended) Output: DSC and DSE (DSC sentences to Standard Horizon Plotter for Position Polling) If you have further inquires, please feel free to contact Product Support at: Phone: (800) 767-2450 Email: marinetech@vxstdusa.com...

  • Page 12: Checking Gps Connections

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 8.4 CHECKING GPS CONNECTIONS After connections have been made between the GX3000S and the GPS, a small satellite icon will appear on the top right corner of the LCD display. To see the additional GPS information, press and hold the [ H/L ( NAV )] key.

  • Page 13: Changing The Time Location

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 8.6 CHANGING THE TIME LOCATION Sets the radio to show UTC time or local time with the offset inputted in section 8.5 Changing the GPS Time. 1. Press and hold down the [ CALL ( MENU )] key until Radio Setup “...

  • Page 14: Receiver Audio Responce

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 8.8 RECEIVER AUDIO RESPONCE Allows you to select the receiver audio responce to allow the most comfortable and/or effective reception in noisy enviroments. The effect is similar to that provided by an “Equalizer” in a stereo.

  • Page 15: Optional Mmb-84 Flush Mount Installation

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 8.9 OPTIONAL MMB-84 FLUSH MOUNT INSTALLATION 1. To assist in flush mounting, a template has been included. Use this tem- plate to find the mounting location. 2. Use the template to mark the location where the rectangular hole is to be cut.

  • Page 16: Optional Enhanced Ram+ Second Station Mic And/Or Vh-310 Handset Installation

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 8.10 OPTIONAL ENHANCED RAM+ SECOND STATION MIC AND/OR VH-310 HANDSET INSTALLATION The GX3000S is capable of using up to 2 Enhanced RAM+ mics or VH-310 Handset to remotely control the Radio, DSC, and Distress functions. In addition the GX3000S can operate as a full function intercom system.
  • Page 17 FCC ID: K6630143X3D/IC ID: 511B-30143X3D Remote Mic or External Speaker Selection By default the RAM+ or VH-310 Handset internal speaker is turned on, how- ever using the RAM+ mic (or VH-310 Handset) this speaker can be turned off so the external speaker can be used.

  • Page 18: Controls And Indicators

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 9 CONTROLS AND INDICATORS NOTE This section defines each control of the transceiver. See Figures for lo- cation of controls. For detailed operating instructions refer to section “10 BASIC OPERATION.” POWER SWITCH / VOLUME CONTROL ( VOL/PWR ) Turns the transceiver on and off as well as adjusts the audio volume.
  • Page 19 FCC ID: K6630143X3D/IC ID: 511B-30143X3D [ WX ] Key Immediately recalls the previously selected NOAA weather channel from any channel. Secondary use Holding down the [ 16/9 ] key while pressing the [ WX ] key changes from USA, International and Canadian channel groups.
  • Page 20 FCC ID: K6630143X3D/IC ID: 511B-30143X3D [ H/L ( NAV )] Key Press this key to toggle the transmit output power between 25 W (High) and 1 W (Low) power. When the [ H/L ( NAV )] key is pressed while the transceiver is on channel 13 or 67, the power will temporarily switch from LO to HI power until the PTT is released.
  • Page 21 FCC ID: K6630143X3D/IC ID: 511B-30143X3D ANTENNA JACK Connects an antenna to the transceiver. Use a marine VHF antenna with an impedance of 50 ohms. REMOTE MIC CONNECTORS Connects the GX3000S to the enhanced RAM+ MIC (Remote Access Mi- crophone) or the VH-310 Handset. Refer to section “13 ENHANCED RAM+ MIC OPERATION”...
  • Page 22 FCC ID: K6630143X3D/IC ID: 511B-30143X3D PTT (Push-To-Talk) SWITCH Keys the transmitter when the transceiver is in radio mode. If the transceiver is in the intercom mode (between the CMP25 RAM+ or VH-310 Headset and the GX3000S), or PA mode, it activates the GX3000S microphone for voice communications.
  • Page 23 FCC ID: K6630143X3D/IC ID: 511B-30143X3D MEMO GX3000S Page 23 Vertex Standard Co., Ltd.

  • Page 24: Basic Operation

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 10 BASIC OPERATION 10.1 RECEPTION 1. After the transceiver has been installed, ensure that the power supply and antenna are properly connected. 2. Press and hold the VOL/PWR knob until the radio turns on. 3. Turn the SQL knob fully counterclockwise. This state is known as “squelch off”.

  • Page 25: Simplex/Duplex Channel Use

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 10.4 SIMPLEX/DUPLEX CHANNEL USE Refer to the VHF MARINE CHANNEL CHART (page 87) for instructions on use of simplex and duplex channels. NOTE All channels are factory-programmed in accordance with International, Industry Canada (Canada), and FCC (USA) regulations. Mode of opera- tion cannot be altered from simplex to duplex or vice-versa.

  • Page 26: Noaa Weather Alert Testing

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 3. The programmed NOAA weather channels will be scanned along with the regular-programmed channels. However, scanning will not stop on a nor- mal weather broadcast unless a NOAA alert is received. 4. When an alert is received on a NOAA weather channel, scanning will stop and the transceiver will emit a loud beep to alert the user of a NOAA broadcast.

  • Page 27: Calling Another Vessel (Channel 16 Or 9)

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 10.8 CALLING ANOTHER VESSEL ( CHANNEL 16 OR 9 ) Channel 16 may be used for initial contact (hailing) with another vessel. However, its most important use is for emergency messages. This channel must be monitored at all times except when actually using another channel.

  • Page 28: Operating On Channels 13 And 67

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D the marine operator and identify yourself by your vessel’s name, The marine operator will then ask you how you will pay for the call (telephone credit card, collect, etc.) and then link your radio transmission to the telephone lines.

  • Page 29: Scanning

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 10.12 SCANNING Allows the user to select the scan type from Memory scan or Priority scan. “Memory scan” scans the channels that were programmed into memory. “Pri- ority scan” scans the channels programmed in memory with the priority chan- nel.

  • Page 30: Priority Scanning P-Scan

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 10.12.3 Priority Scanning P-SCAN In the default setting, Channel 16 is set as the priority channel. You may change the priority channel to the desired channel from the Channel 16 by the Radio Setup Mode, refer to section “12.6 PRIORITY CHANNEL SET.”...

  • Page 31: Fog / Pa Operation

    10.13 PA/FOG OPERATION PA/FOG mode allows the transceiver to be used as a 30W hailer when an optional STANDARD HORIZON 220SW or 240SW PA horn speaker is installed. When in Hail mode the PA speaker Listen’s Back (acts as a microphone and sends sound to the front panel speaker) through the PA horn speaker which provides two-way communications through the PA horn speaker.

  • Page 32: Navigation Indication

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D switch to activate the tone through the HAIL/PA speaker. Rotate the CHANNEL selector knob to control the AF output level. The AF output level can be set from 0 to 30 watts. 6. To exit the FOG HORN mode, press the [ PA/FOG ] or [ CLR ] key.

  • Page 33: Communication

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 10.15.1 Communication 1. Press and hold the [ DW ( IC )] key, the mode is changed to “INTERCOM” mode. 2. If your GX3000S is equipped two CMP25 RAM+ Mic’s (or VH-310 Handset), select the companion you wish...

  • Page 34: Voice Scrambler

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 10.16 VOICE SCRAMBLER If privacy of communications is desired, a CVS2500 voice scrambler (VS) can be installed in the transceiver. Contact your Dealer to have a CVS2500 installed. Refer to the section 12.11 VOICE SCRAMBLER to program the voice scram- bler.

  • Page 35: Digital Selective Calling

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11 DIGITAL SELECTIVE CALLING 11.1 GENERAL WARNING This radio is designed to generate a digital maritime distress and safety call to facilitate search and rescue. To be effective as a safety device, this equipment must be used only within communication range of a shore- based VHF marine channel 70 distress and safety watch system.

  • Page 36: Maritime Mobile Service Identity (Mmsi)

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.2 MARITIME MOBILE SERVICE IDENTITY (MMSI) 11.2.1 What is an MMSI? An MMSI is a nine digit number used on Marine Transceivers capable of using Digital Selective Calling (DSC). This number is used like a telephone number to selectively call other vessels.

  • Page 37: Dsc Distress Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.3 DSC DISTRESS CALL The GX3000S is capable of transmitting and receiving DSC Distress messages to all DSC radios. The GX3000S may be connected to a GPS to also transmit the Latitude, Longitude of the vessel.
  • Page 38 FCC ID: K6630143X3D/IC ID: 511B-30143X3D Transmitting a DSC Distress Call with Nature of Distress The GX3000S is capable of transmitting a DSC Distress Call with the following “Nature of Distress” categories: Undesignated, Fire, Flooding, Collision, Grounding, Capsizing, Sinking, Adrift, Abandoning, Piracy, MOB 1.

  • Page 39: Receiving A Dsc Distress Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.3.2 Receiving a DSC Distress Call 1. When a DSC Distress call is received, an emergency alarm sounds. Then channel 16 is automatically selected. 2. Press any key to stop the alarm. 3. Turn the CHANNEL selector knob to change the dis- play to show the position of the vessel in distress.

  • Page 40: Transmitting An All Ships Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.4.1 Transmitting an All Ships Call 1. Press the [ CALL ( MENU )] key. The “DSC Operation” menu will appear. 2. Turn the CHANNEL selector knob to select “All Ships.” 3. Press the [ ENT ] key. (To cancel, turn the CHANNEL selector knob to select “Exit.”)

  • Page 41: Individual Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.5 INDIVIDUAL CALL This feature allows the GX3000S to contact another vessel with a DSC VHF radio and automatically switch the receiving radio to a desired communications channel. This feature is similar to calling a vessel on CH16 and requesting to go to another channel (switching to the channel is private between the two stations).

  • Page 42: Setting Up Individual Ringer

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11. If a mistake was made entering in the name or the MMSI number repeat pressing the [ H/L ( NAV )] key until the wrong character is selected, then move the channel knob to correct the entry.

  • Page 43: Setting Up Individual / Group Call Ringer

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.5.3 Setting up the Individual/Group Call Ringer When a Individual Call or Group Call is received the radio will produce a ringing tone for 3 minutes. This selection allows the Individual Call ringer time to be changed.

  • Page 44: Transmitting An Individual Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.5.4 Transmitting an Individual Call This feature allows the user to contact another vessel with a DSC radio. This feature is similar to calling a vessel on CH16 and requesting to go to another channel.
  • Page 45 FCC ID: K6630143X3D/IC ID: 511B-30143X3D Manual Calling You may enter an MMSI number manually to contact without the Setting up the Individual Directory. 1. Press the [ CALL ( MENU )] key. The “DSC Operation” menu will appear. 2. Turn the CHANNEL selector knob to select “Indi- vidual.”...

  • Page 46: Receiving An Individual Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 13. Press any key to listen to the channel to make sure it is not busy, then key the microphone and call the other vessel you desire to communicate with. 11.5.5 Receiving an Individual Call When receiving an individual call, an acknowledgment must be sent back to the calling station.

  • Page 47: Group Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.6 GROUP CALL This feature allows the user to contact a group of specific vessels (example members of a yacht club) using DSC radios with Group call function to auto- matically switch to a desired channel for voice communications.

  • Page 48: Transmitting A Group Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11. If a mistake was made entering in the name or the MMSI number repeat pressing the [ H/L ( NAV )] key until the wrong charac- ter is selected, then move the channel knob to cor- rect the entry.
  • Page 49 FCC ID: K6630143X3D/IC ID: 511B-30143X3D Manual Calling You may enter an MMSI number manually to contact without the Setting up the Group call number. 1. Press the [ CALL ( MENU )] key. The “ DSC Operation ” menu will appear.

  • Page 50: Receiving A Group Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.6.3 Receiving a Group Call 1. When a group call is received, the GX3000S will pro- duce a ringing alarm sound. 2. The radio automatically switches to the requested channel. 3. Press any key to stop the alarm.

  • Page 51: Position Request

    GX3000S. Standard Horizon has taken this feature one step further, if any Standard Hori- zon GPS is connected to the GX3000S, the polled position of the vessel is shown on the display of the GPS chart plotter making it easy to navigate to the location of the polled vessel.

  • Page 52: Transmitting A Position Request To Another Vessel

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D The GX3000S has the capability to turn off the Position Request ringer. 1. Press and hold down the [ CALL ( MENU )] key until “Radio Setup” menu appears. 2. Turn the CHANNEL selector knob to select “DSC Setup”...
  • Page 53 FCC ID: K6630143X3D/IC ID: 511B-30143X3D NOTE If the GX3000S does not receive position data from the polled vessel, the LCD will show “NO POSITION DATA.” Manual Request You may enter an MMSI number manually to contact without the Setting up the Individual / Position Call Directory.

  • Page 54: Receiving A Position Request

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.7.3 Receiving a Position Request When a position request call is received from another vessel, a ringing alarm will sound and POS REQUEST will be shown in the LCD. Operation and trans- ceiver function differs depending on “...

  • Page 55: Position Send

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.8 POSITION SEND The feature is similar to Position Request, however instead of requesting a position of another vessel this function allows you to send your position to an- other vessel. Your vessel must have an operating GPS receiver connected for the GX3000S to send the position.

  • Page 56: Transmitting A Dsc Position Send Call

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.8.2 Transmitting a DSC Position Send Call Pre-Programmable Calling 1. Press the [ CALL ( MENU )] key. The “ DSC Operation ” menu will appear in the display. 2. Turn the CHANNEL selector knob to select the “...

  • Page 57: Receiving A Dsc Position Send Call

    2. Press the [ 16/9 ] key to stop ringing 3. The position from the calling vessel will be shown on the display of the radio and also transferred to any Standard Horizon GPS Chart plotter if con- nected. GX3000S Page 57 Vertex Standard Co., Ltd.

  • Page 58: Manual Inputting Of The Gps Location (Lat/Lon)

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 11.9 MANUAL INPUTTING OF THE GPS LOCATION ( LAT/LON ) You may send the Latitude/Longitude of your vessel manually even if the GX3000S is not connected the GPS receiver unit. After the position is entered, transmitting a DSC Distress, Position Request, or Position Send will contain the manually entered position.

  • Page 59: Radio Setup Mode

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12 RADIO SETUP NOTE The optional CMP25 RAM+ mic and VH-310 Handset can also change the RADIO SETUP menu. Refer to page 72 (RAM+ mic) and page 80 (VH-310) for details. 12.1 LAMP ADJUSTING Allows setting up the backlight intensity or to turn it off.

  • Page 60: Time Offset

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12.3 TIME OFFSET This selection sets the time offset between local time and UTC (time GPS sends to radio). Time is displayed when GPS position (LAT/LON) is displayed by pressing the [ F ] key followed by the [ 6 ( NAV )] key.

  • Page 61: Time Location

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12.4 TIME LOCATION This selection selects the time display between local time and UTC (time GPS sends to radio). Time is displayed when GPS position (LAT/LON) is displayed by press and holding the [ H/L ( NAV )] key.

  • Page 62: Priority Channel Set

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12.6 PRIORITY CHANNEL SET Allows selection of the priority channel. 1. Press and hold down the [ CALL ( MENU )] key until “ Radio Setup ” menu appears. 2. Press the [ ENT ] key, then select “...

  • Page 63: Scan Resume Time

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12.8 SCAN RESUME TIME This selection is used to select the time the GX3000S waits after a transmis- sion ends before starting scanning. 1. Press and hold down the [ CALL ( MENU )] key until Radio Setup “...

  • Page 64: Wx Alert

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12.10 WX ALERT This selection allows the radios NOAA Weather alert to be turned off. Default setting is ON. 1. Press and hold down the [ CALL ( MENU )] key until Radio Setup “...

  • Page 65: Channel Name Change

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12.12 CHANNEL NAME CHANGE This selection allows you to customize the name of a channel from the default name. 1. Press and hold down the [ CALL ( MENU )] key until Radio Setup “...

  • Page 66: Naming The Radio Or Second Station Mic Or Handest

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12.13 NAMING THE RADIO OR SECOND STATION MIC OR HANDSET This selection allows you to provide the name to the radio and optional RAM+ Mic’s when connected. 1. Press and hold down the [ CALL ( MENU )] key until Radio Setup “...

  • Page 67: Fog Alert Tone Frequency

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 12.14 FOG ALERT TONE FREQUENCY This selection allows you to select the Alert Tone Frequency for the PA/FOG Operation. Available selections are “200 Hz” through “850 Hz” in 50 Hz steps. The default Alert Tone Frequency is 400 Hz.

  • Page 68: Enhanced Ram+ Mic Opertion

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 13 ENHANCED RAM+ MIC OPERATION When the RAM+ microphone is connected to the GX3000S, most VHF, DSC, and setup menus can be remotely operated. The RAM+ Mic is supplied with 23 feet (7 m) of routing cable and can be extended up to 70 feet (21 m) using three 23 feet extension cables model CT-100.
  • Page 69 FCC ID: K6630143X3D/IC ID: 511B-30143X3D POWER SWITCH ( PWR ) Press and hold down this key to turn to the transceiver and RAM+ Mic on and off. PTT ( Push-To-Talk ) SWITCH Activates transmission. [ H/L ] KEY Toggles between high and low power. When the [ H/L ] key is pressed while the transceiver is on channel 13 or 67, the power will temporarily switch from LO to HI power until the PTT is released.
  • Page 70 FCC ID: K6630143X3D/IC ID: 511B-30143X3D [ DW ] Key Watches for a transmission on CH16 and another selected channel until either signal is received. (Dual watch) Secondary use Press and hold [ DW ] key, intercom operation will operate between radio and RAM+ Mic.

  • Page 71: Intercom Opertion

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 13.2 INTERCOM OPERATION 13.2.1 Communication 1. Press and hold the [ DW ] key while in the “RADIO” mode, the mode is changed to “INTERCOM” mode. When the “INTERCOM” operation is activated, “IC” is displayed on the RAM+ Mic (and VH-310 Handset) and “INTERCOM”...

  • Page 72: Dsc/Radio Setup Mode

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 13.3 DSC/RADIO SETUP MODE The RAM+ can access the DSC / RADIO setup menu (refer to section “11 DIGITAL SELECTIVE CALLING” and section “12 RADIO SETUP MODE” for details). The LAMP CONTRAST , and KEY BEEP menu item accessed from the RAM+ only controls the RAM+’s display and speaker.
  • Page 73 FCC ID: K6630143X3D/IC ID: 511B-30143X3D MEMO GX3000S Page 73 Vertex Standard Co., Ltd.

  • Page 74: Handset Operation

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 14 VH-310 HANDSET OPERATION When the VH-310 HANDSET is connected to the GX3000S, most VHF, DSC, and setup menus can be remotely operated. The VH-310 HANDSET is supplied with 23 feet (7 m) of routing cable and can be extended up to 70 feet (21 m) using three 23 feet extension cables model CT-100.
  • Page 75 FCC ID: K6630143X3D/IC ID: 511B-30143X3D [ SQL ] key Activates the squelch adjusting mode. Press this key to activate the squelch adjusting mode. Press the [ ] or [ ] key to adjust the squelch. [ CALL ( MENU )] key The [ CALL ( MENU )] key functions as the enter key.
  • Page 76 FCC ID: K6630143X3D/IC ID: 511B-30143X3D KEYPAD [ 1 ( DIM )] key When in radio mode, this key is used to directly select channel digit “1” in a channel number. Secondary use Press the [ F ] key first then press the [ 1 ( DIM )] key to access the LCD Dimmer menu.
  • Page 77 FCC ID: K6630143X3D/IC ID: 511B-30143X3D [ 6 ( NAV )] Key When in radio mode, this key is used to directly select channel digit “6” in a channel number. Secondary use Press the [ F ] key first then press the [ 6 ( NAV )] key, the LCD will display...

  • Page 78: Intercom Opertion

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 14.2 INTERCOM OPERATION 14.2.1 Communication 1. Press the [ F ] key followed by the [ 5 ( IC )] key, the mode is changed to “IN- TERCOM” mode. 2. When the “INTERCOM” operation is activated, “IC” is dis- played on the VH-310 Handset (and RAM+ Mic, if used) and “INTERCOM”...

  • Page 79: Manual Inputting Of The Gps Location (Lat/Lon)

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 14.3 MANUAL INPUTTING OF THE GPS LOCATION ( LAT/LON ) You may send the Latitude/Longitude of your vessel manually from the VH-310 Handset even if the GX3000S is not connected the GPS receiver unit. After the position is entered, transmitting a DSC Distress, Position Request, or Position Send will contain the manually entered position.

  • Page 80: Dsc/Radio Setup Mode

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 14.4 DSC/RADIO SETUP MODE The VH-310 Handset can access the DSC / RADIO setup menu (refer to sec- tion “11 DIGITAL SELECTIVE CALLING” and section “12 RADIO SETUP MODE” for details). The CONTRAST NAV DISPLAY...

  • Page 81: Changing Gps Information To Vessel Position Or Cog

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 14.4.1 Changing GPS Information to Vessel position or COG Allows customizing the NAV data showing GPS Information. Factory default is “Your Vessel’s Current Position,” however, following the steps below the GPS Information can be changed to “Course Over Ground (COG).”...

  • Page 82: Maintenance

    Ensure that the supply voltage to the transceiver does not exceed 16 VDC or fall below 11 VDC. • Use only STANDARD HORIZON-approved accessories and replacement parts. In the unlikely event of serious problems, please contact your Dealer or our repair facility.

  • Page 83: Factory Service

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 15.2 FACTORY SERVICE In the unlikely event that the radio fails to perform or needs servicing, please contact the following: Standard Horizon Attention Marine Repair Department 10900 Walker Street, Cypress, CA 90630 Telephone (800) 366-4566 An “RA”...

  • Page 84: Troubleshooting Chart

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 15.3 TROUBLESHOOTING CHART SYMPTOM PROBABLE CAUSE REMEDY Transceiver fails to No DC voltage to the a. Check the 12VDC battery connections and power up. transceiver, or blown the fuse. fuse. b. The PWR key needs to be pressed and held to turn the radio on.
  • Page 85 FCC ID: K6630143X3D/IC ID: 511B-30143X3D MEMO GX3000S Page 85 Vertex Standard Co., Ltd.

  • Page 86: Channel Assignments

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 16 CHANNEL ASSIGNMENTS Tables on the following columns list the VHF Marine Channel assignments for U.S.A. and International use. Below are listed some data about the charts. 1. VTS. Where indicated, these channels are part of the U.S. Coast Guard’s Vessel Traffic System.
  • Page 87 FCC ID: K6630143X3D/IC ID: 511B-30143X3D 6. Marine vessels equipped with VHF radios are required to monitor Channel 16. VHF MARINE CHANNEL CHART CHANNEL USE D 156.050 160.650 Public Correspondence (Marine Operator) 156.050 Port Operation and Commercial. VTS in selected areas D 156.100 160.700 Public Correspondence (Marine Operator)
  • Page 88 FCC ID: K6630143X3D/IC ID: 511B-30143X3D VHF MARINE CHANNEL CHART CHANNEL USE D 157.150 161.750 Public Correspondence (Marine Operator) 157.150 U.S. Government Only D 157.200 161.800 Public Correspondence (Marine Operator) D 157.250 161.850 Public Correspondence (Marine Operator) D 157.300 161.900 Public Correspondence (Marine Operator) D 157.350 161.950 Public Correspondence (Marine Operator)
  • Page 89 FCC ID: K6630143X3D/IC ID: 511B-30143X3D VHF MARINE CHANNEL CHART CHANNEL USE 156.775 Port Operations (Inter-ship only) (1W) 156.825 Port Operations (Inter-ship only) (1W) 156.875 Port Operations (Inter-ship only) (1W) 156.875 Port Operations (Inter-ship only) D 156.925 161.525 Public Correspondence (Marine Operator), Port operation, ship-movement 156.925...
  • Page 90 FCC ID: K6630143X3D/IC ID: 511B-30143X3D Points of communica- Points of communica- Carrier frequency Carrier frequency tion Intership and be- tion Intership and be- Channel Channel tween coast and ship tween coast and ship designator designator Coast Coast Ship Ship u n l e s s o t h e r w i s e...
  • Page 91 FCC ID: K6630143X3D/IC ID: 511B-30143X3D 4: Use of 156.875 MHz is limited to communications with pilots regarding the movement and docking of ships. Normal output power must not exceed 1 watt. 5: 156.375 MHz and 156.650 MHz are available primarily for intership navigational commu- nications.

  • Page 92: Warranty

    In the event of a defect, malfunction or failure of the Product during the war- ranty period, STANDARD HORIZON’s liability for any breach of contract or any breach of express or implied warranties in connection with the sale of Products...
  • Page 93 This warranty only extends to Products sold within the 50 States of the United States of America and the District of Columbia. STANDARD HORIZON will pay all labor to repair the product and replacement parts charges incurred in providing the warranty service except where purchaser abuse or other qualifying exceptions exist.
  • Page 94 Product Support Inquiries If you have any questions or comments regarding the use of the GX3000S, you can visit the STANDARD HORIZON Web site to send an E-Mail or contact the Product Support team at (714) 827-7600 ext 6300 M-F 7:00- 5:00PST.

  • Page 95: Specifications

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 18 SPECIFICATIONS Performance specifications are nominal, unless otherwise indicated, and are subject to change without notice. 18.1 GENERAL Channels .............. All USA, International and Canadian Input Voltage ..................13.8 VDC ±20% Current Drain Standby ......................0.4 A Receive ......................

  • Page 96: Appendix

    FCC ID: K6630143X3D/IC ID: 511B-30143X3D 19 APPENDIX FOG HORN TIMING CHART The fog horn function sounds a horn repeatedly until the function is turned off. TYPE PATTERN USAGE UNDERWAY One 5-second blasts evey 120 seconds. Motor vessel underway and making way.
  • Page 97 FCC ID: K6630143X3D/IC ID: 511B-30143X3D MEMO GX3000S Page 97 Vertex Standard Co., Ltd.
  • Page 98 FCC ID: K6630143X3D/IC ID: 511B-30143X3D MEMO Page 98 GX3000S Vertex Standard Co., Ltd.
  • Page 99 FCC ID: K6630143X3D/IC ID: 511B-30143X3D MEMO GX3000S Page 99 Vertex Standard Co., Ltd.
  • Page 100 FCC ID: K6630143X3D/IC ID: 511B-30143X3D Copyright 2006 VERTEX STANDARD CO., LTD. Marine Division of VERTEX STANDARD All rights reserved. US Headquarters No portion of this manual 10900 Walker Street, Cypress, CA 90630, U.S.A. may be reproduced www.standardhorizon.com without the permission of VERTEX STANDARD CO., LTD.
