3.8 a6x and a7x parts supplied

The following items are supplied with your a6x and
a7x variant MFD.
1 2
4 5
7
1 Front bezel
2
Multifunction display
3 Mounting gasket
4 Sun cover
5 Trunnion bracket kit
6 Documentation pack
7 Power cable
8 4x Nuts, bolts, spring washers and washers (can
be used for either surface or bracket mounting.)
28

3.9 a9x and a12x parts supplied

The following items are supplied with your a9x and
a12x variant MFD.
3
6
x4
8
D12583-2
10
11
1
2
3
4
5
6
7
8
9
10
11
1 2
4 5
7
9
Front bezel
Multifunction display (MFD)
Mounting gasket
Sun cover
Trunnion bracket kit
Documentation
SeaTalk ng® to DeviceNet adaptor cable
4x Nuts, bolts, spring washers and washers (can
be used for either surface or bracket mounting.)
1 m (3.3 ft.) SeaTalk
2 m (6.6 ft.) RayNet cable
1.5 m (4.9 ft.) Power and data cable
(Power/NMEA/Video)
a Series / c Series / e Series installation instructions
3
6
8
D13066-1
ng® spur cable
