6.20 Simulator mode

The Simulator mode enables you to practice
operating your display without data from a GPS
antenna, radar scanner, AIS unit, or fishfinder.
The simulator mode is switched on / off in the
System Setup Menu.
Note: Raymarine recommends that you do NOT
use the simulator mode whilst navigating.
Note: The simulator will NOT display any real
data, including any safety messages (such as
those received from AIS units).
Note: Any system settings made whilst in
Simulator mode are NOT transmitted to other
equipment.
Enabling and disabling simulator mode
You can enable and disable simulator mode by
following the steps below.
With the homescreen displayed:
1. Select Set-Up .
2. Select System Settings.
3. Select Simulator:.
4. Select On to turn simulator mode on, or
5. Select Off to turn simulator mode off.
Note: The Demo movie option is for retail
demonstration purposes only.
Getting started

6.21 Pairing the keypad

The keypad can control 1 or more multifunction
displays. Multiple keypads can be connected to a
system. Each keypad can be paired with up to 4
multifunction displays.
With the keypad connected to the multifunction
display:
1. Select External Keypad from the External
Devices menu: homescreen > Set-up > System
Settings > External Devices > External
Keypad.
2. Select Pair Keypad.
3. Press any button on the external keypad.
4. From the pop-up message select the orientation
of the keypad.
Either landscape or portrait orientations are
available.
The keypad is now paired.
Unpairing the keypad
The keypad can be unpaired from an individual
display.
1. Select External Keypad from the External
Devices menu: homescreen > Set-up > System
Settings > External Devices > External
Keypad.
2. Select Clear Pairings.
3. Select Yes to unpair the keypad with the display.
91
