Network cable connector types

There are 2 types of network cable connector —
SeaTalk hs and RayNet.
SeaTalk
connecting SeaTalk
a Raymarine network switch via
SeaTalk
RayNet connector — used for
connecting Raymarine network
switches and SeaTalk
the multifunction display via RayNet
cables. Also required for connecting a
crossover coupler if only one device
is being connected to the display's
Network connector.
146
hs connector — used for
hs devices to
hs cables.
hs devices to
