Service and display messages

The MAC III Profile gives service and maintenance information by displaying a large 3- or 4-character short
code and a smaller full-text message in the display. The short code is visible at a distance, allowing error
identification with the fixture still in the rig, for example, while the full-text message gives more detailed
information about the error.

Service warnings

If the MAC III Profile requires service, it displays a warning indicating the service required. The most
important short codes and messages are given in Table 3 below
Short code
AFSW

Error messages

The MAC III Profile monitors its own operation. If it detects an error, it displays an error warning. The most
important short codes and messages are given in Table 4 below:
Short code
APER
ARER
BANK
BATM
BEER
BOTV
BRER
BT W
BTCO
BTER
C1ER
CCDE
CDCM
CDEF
Full-text message
LLW LAMP LIFE WARNING
Lamp life is within 10% of its limit.
AIRS AIR FILTER SERVICE WARNING (s/w versions from ver. 1.3)
The timer available in the SERVICE menu has reached the point for which the alarm was set.
AIR FILTER SERVICE WARNING (s/w versions prior to ver. 1.3)
The timer available in the SERVICE menu has reached the point for which the alarm was set.
Full-text message
ANIMATION WHEEL POSITION ERROR
ANIMATION WHEEL ROTATION ERROR
UNABLE TO UNPACK BANK
Error unpacking firmware during/after software reload
BATTERY MODE
Switched to battery power source with limited functionality. Plug in power cable to restore full
function operation.
BEAM SHAPER ERROR
BOOTLOADER(S) VERSION NOT VALID
Decentralized firmware in module cannot be replaced / does not match bank. Module or module
bootloader replacement required.
BEAM SHAPER ROTATION ERROR
BASE TEMPERATURE TOO HIGH
At least one base PCB temperature >75°C
BASE TEMPERATURE CUTOFF
At least one base PCB temperature >85°C
BASE TEMP HIGH
The temperature on a PCB in the base is high. A fan might be defective or the ambient temperature
may be too high.
COLOR WHEEL 1 ERROR
CMY CALIBRATE DATA PCB (s/w versions prior to ver. 1.3)
Unable to read/write data to external EEPROM board (calibrate date) on CMY module
CALIBRATE DATA CMY
Unable to read/write data to external EEPROM board (Calibrate Data) on CMY module. The PCB
needs to be replaced.
CALIBRATE DATA EFFECT
Unable to read/write data to external EEPROM board (Calibrate Data) on Effect module. The PCB
needs to be replaced.
Table 3: Service warning messages
Table 4: Error messages
:
