Martin MAC III Profile User Manual page 48

Basic 16-bit
16-bit Extended
Mode Mode DMX Value
9 10
127 - 129
130 - 253
254 - 255
10 11
11 12
90 - 119
120 - 149
150 - 179
180 - 209
210 - 232
233 - 255
12 13
127 - 129
130 - 253
254 - 255
13 14
48
Percent Function
Gobo wheel 1: indexing, direction, speed (MSB)
If indexed gobo is selected on channel 8 (16-bit) or 9 (16-bit ext.)
Rotating gobo indexing, 0 → 395°
0 - 255 0 - 100
If continuous gobo rotation is selected on channel 8 (16-bit) or 9 (16-bit ext.)
0 - 2 0 No rotation
CW, fast → slow
3 - 126 1 - 50
51 No rotation
CCW, slow → fast
52 - 99
100 No rotation
Gobo wheel 1: rotating gobo fine indexing or rotation speed (LSB)
If indexed gobo is selected on channel 8 (16-bit) or 9 (16-bit ext.)
0 - 255 0 - 100 Rotating gobo indexing, fine
If continuous gobo rotation is selected on channel 8 (16-bit) or 9 (16-bit ext.)
0 - 255 0 - 100 Rotating gobo rotation speed, fine
Gobo wheel 2: gobo selection, indexing, shake, rotation
Indexed gobo: set indexed angle on channel 12 (16-bit) or 13 (16-bit ext.)
0 - 9 0 - 4 Open
10 - 14 4 - 5 Gobo 1 - Lasercone single
15 - 19 5 - 8 Gobo 2 - Mikado
20 - 24 8 - 10 Gobo 3 - Limbo/Crystal
25 - 29 10 - 12 Gobo 4 - Cloud flames
30 - 34 12 - 14 Gobo 5 - Gridlock
Continuous gobo rotation: set gobo rotation speed on channel 12 (16-bit) or
13 (16-bit ext.)
35 - 39 14 - 16 Gobo 1 - Lasercone single
40 - 44 16 - 18 Gobo 2 - Mikado
45 - 49 18 - 20 Gobo 3 - Limbo/Crystal
50 - 54 20 - 22 Gobo 4 - Cloud flames
55 - 59 22 - 24 Gobo 5 - Gridlock
Gobo shake centered on indexed position: set indexed angle on channel 9
(16-bit) or 10 (16-bit ext.). Shake angle increments in following steps:
10°, 15°, 30°, 45°, 60°, 90°, 135°, 180°, 270° and 360°
Gobo 1 - Lasercone single, 360° slow → 10° fast
60 - 89 24 - 34
Gobo 2 - Mikado, 360° slow → 10° fast
35 - 45
Gobo 3 - Limbo/Crystal, 360° slow → 10° fast
46 - 56
Gobo 4 - Cloud flames, 360° slow → 10° fast
57 - 67
Gobo 5 - Gridlock, 360° slow → 10° fast
68 - 78
Continuous gobo wheel scroll with continuous gobo rotation: set gobo rotation
speed on channel 9 (16-bit) or 10 (16-bit ext.)
CW scroll, fast → slow
79 - 89
CCW scroll, slow → fast
90 - 100
Gobo wheel 2: indexing, direction, speed (MSB)
The default value for this channel = 128
If indexed gobo is selected on channel 11 (16-bit) or 12 (16-bit ext.)
Rotating gobo indexing, 0 → 395°
0 - 255 0 - 100
If continuous gobo rotation is selected on channel 11 (16-bit) or 12 (16-bit
ext.)
0 - 2 0 No rotation
CW, fast → slow
3 - 126 1 - 50
51 No rotation
CCW, slow → fast
52 - 99
100 No rotation
Gobo wheel 2: rotating gobo fine indexing or rotation speed (LSB)
If indexed gobo is selected on channel 11 (16-bit) or 12 (16-bit ext.)
0 - 255 0 - 100 Rotating gobo indexing, fine
If continuous gobo rotation is selected on channel 11 (16-bit) or 12 (16-bit
ext.)
0 - 255 0 - 100 Rotating gobo rotation speed, fine
MAC III Profile user manual
