Martin MAC III Profile User Manual page 50

Basic 16-bit
16-bit Extended
Mode Mode DMX Value
22 25
23 26
24 27
25 28
80 - 139
140 - 144
145 - 149
26 29
150 - 154
155 - 159
160 - 164
165 - 169
170 - 174
175 - 199
200 - 204
205 - 209
210 - 214
215 - 219
220 - 224
225 - 239
240 - 244
245 - 249
250 - 255
50
Percent Function
Pan (MSB)
Left → right (128 = neutral)
0 - 255 0 - 100
0 - 255 0 - 100 Pan, fine (LSB)
Tilt (MSB)
Left → right (128 = neutral)
0 - 255 0 - 100
0 - 255 0 - 100 Tilt, fine (LSB)
Fixture control/settings
0 - 9 0 - 1 No function
10 - 14 2 - 3 Reset entire fixture
15 - 19 4 - 5 Reset dimmer and shutter only
20 - 24 6 - 7 Reset CMYC and color wheel only
25 - 29 8 - 9 Reset effects module (gobo wheels 1 & 2, gobo animation, iris, prism) only
30 - 34 10 - 11 Reset zoom and focus only
35 - 39 12 - 13 Reset pan and tilt only
40 - 44 14 - 15 No function
45 - 49 16 - 17 Lamp on
50 - 54 18 - 19 Lamp off
55 - 59 20 - 21 No function (Note: this value is used for setting calibration values on ch.
27/30)
60 - 64 22 - 23 Dimmer curve = Optical linear
(menu override, setting unaffected by power off/on)
65 - 69 24 - 25 Dimmer curve = Square law
(menu override, factory default setting, setting unaffected by power off/on)
70 - 74 26 - 27 Dimmer curve = Inverse square law
(menu override, setting unaffected by power off/on)
75 - 79 28 - 29 Dimmer curve = S-curve
(menu override, setting unaffected by power off/on)
30 - 53 No function
54 - 55 Parameter shortcuts = ON
(menu override, setting stays at factory default ON at power off/on)
56 - 57 Parameter shortcuts = OFF
(menu override, setting returns to factory default ON at power off/on)
58 - 59 No function
60 - 61 Disable zoom/focus linking
62 - 63 Enable zoom/focus linking, near distance
64 - 65 Enable zoom/focus linking, medium distance (factory default setting)
66 - 67 Enable zoom/focus linking, far distance
68 - 77 No function
78 - 79 Ballast output full, set to 1500 W
80 - 81 Ballast output reduced, output set to 1200 W
82 - 83 Ballast output reduced, output set to 1100 W
84 - 85 Ballast output reduced, output set to 1000 W
86 - 87 Ballast output reduced, output set to 900 W
88 - 93 No function
94 - 95 Illuminate display on fixture
96 - 97 No function
98 - 100 Trigger event log (inserts new dynamic content into current report)
(1)
(2)
MAC III Profile user manual
(1)
(1)
(1)
(1)
(1, 2)
(2)
(2)
If DMX Reset or DMX Lamp Off are disabled in the control menus, a full or
partial reset command or a lamp off command can be executed only if:
Slot 1 is selected on the color wheel (DMX value 20 on channel 7
in16-bit or 8 in 16-bit ext.)
The prism is on (DMX value 80-89 on channel 17 in 16-bit or 18 in 16-bit
ext.), and
Open gobo is selected on both gobo wheels (DMX value 0 on channels
8 and 9 in 16-bit or 11 and 12 in 16-bit ext.)
Value must be held for 5 seconds to activate
(1)
(2)
(2)
(2)
(2)
(2)
(1)
(2)
(2)
(2)
(2)
