Martin MAC III Profile User Manual page 51

Basic 16-bit
16-bit Extended
Mode Mode DMX Value
100-104
105-109
110-114
115-124
125-129
130-134
135-139
140-144
145-149
150-154
155-159
160-164
165-169
27 30 170-174
175-179
180-184
185-189
190-194
195-199
200-204
205-209
210-214
215-219
220-224
225-229
230-234
235-239
240-244
245-249
250-255
MSB = Most significant byte
LSB = Least significant byte
Percent Function
Fixture adjustments/calibration
0-39 0 -13 No function: reserved for future use
40-44 14 - 15 Enable pan/tilt limits
45-49 16 - 17 No function: reserved for future use
50-54 18 - 19 Disable pan/tilt limits
55-59 20 - 21 No function: reserved for future use
60-64 22 - 23 Set pan/tilt limit: head must stay inside defined limits (create safe zone)
65-69 24 - 25 No function: reserved for future use
70-74 26 - 27 Set pan/tilt limit: head must stay outside defined limits (create no-go zone)
75-79 28 - 29 No function: reserved for future use
80-84 30 - 31 Store current pan position as lower pan limit
85-89 32 - 33 Store current pan position as upper pan limit
90-94 34 - 35 No function: reserved for future use
95-99 36 - 37 Store current tilt position as lower tilt limit
38 - 39 Store current tilt position as upper tilt limit
40 - 41 No function: reserved for future use
42 - 43 Reset pan and tilt limits
44 - 47 No function: reserved for future use
48 - 49 Store dimmer calibration
50 - 51 Store cyan calibration
52 - 53 Store magenta calibration
54 - 55 Store yellow calibration
56 - 57 Store CTC calibration
58 - 59 Store CMYC calibration
60 - 61 Store gobo wheel 1 slots 1 – 5 index calibration
62 - 63 No function: reserved for future use
64 - 65 No function: reserved for future use
66 - 67 No function: reserved for future use
68 - 69 No function: reserved for future use
70 - 71 Store gobo wheel 2 slots 1 – 5 index calibration
72 - 73 No function: reserved for future use
74 - 75 No function: reserved for future use
76 - 77 No function: reserved for future use
78 - 79 No function: reserved for future use
80 - 81 Store gobo animation wheel index calibration
82 - 83 Store beam effect (prism) index calibration
84 - 85 Store iris calibration
86 - 87 Store focus calibration
88 - 89 Store zoom calibration
90 - 91 Store pan calibration
92 - 93 Store tilt calibration
94 - 95 No function: reserved for future use
96 - 97 Reset all calibrations to factory default
98 - 100 No function: reserved for future use
(3)
(4)
MAC III Profile DMX protocol
(4)
(4)
(3)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
To activate:
Value must be held for 5 seconds
The CMY channels (3, 4 and 5 in 16-bit mode or 4, 5 and 6 in 16-bit
extended mode) must all be set to DMX value 232
The beam effect channel (17 in 16-bit mode or 18 in 16-bit extended
mode) must be set to DMX value 30.
To activate:
Value must be held for 5 seconds
Channel 14 in 16-bit/15 in 16-bit ext. must be set to DMX value 5 - 10
Channel 26 in 16-bit/29 in 16-bit ext. must be set to 55 - 59.
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
