Martin MAC III Profile User Manual page 53

Menu level 1 Menu level 2
FANS
DIMMING CURVE
FOCUS
TRACKING
PERSONALITY
(continued)
FOLLOWSPOT
MODE
AUTOMATIC
LAMP ON
DMX LAMP OFF
DMX RESET
Menu level 3 Menu level 4
50%
LAMP COOLING
80%
Off
FAN CLEAN Auto
Forced
Always on
FAN MODE
Follow lamp off
Optical linear
VRMS linear
Square law
Inv.sq.law
Disabled
Near
Medium
Far distance
FOLLOWSPOT
Off / On
MODE
LOCK/UNLOCK
PAN & TILT
LOCK PAN Off / On
LOCK TILT Off / On
Off
On
DMX
Off
On
Off
On
Table 2: Control menus
Control panel menus
Notes (Default settings in bold print)
Sets lamp cooling fans to 50% capacity
(color temperature of light output from the
lamp is different at different thermal lamp
temperatures)
Sets lamp cooling fans to 80% capacity
Sets all cooling fans to no cleaning
Fan cleaning mode activated
automatically if fan error reported
Sets all cooling fans to run at 100%
Cooling fans operate constantly
Cooling fans stop when lamp is powered
off
Optically linear dimming curve
S-curve (fixture emulates incandescent
lamp voltage linear RMS dimming curve)
Square law dimming curve
Inverse square law dimming curve
Disables zoom focus linking
Enables zoom focus linking, optimized for
short-throw projection (5 - 10 m)
Enables zoom focus linking, optimized
for medium-throw projection (10 - 20 m)
Enables zoom focus linking, optimized for
long-throw projection (20+ m)
Enables/disables followspot mode (see
"Followspot mode" on page 24). In
followspot mode DMX control of pan and
tilt is disabled and the pan and tilt motors
are disengaged so the head can be freely
moved using a followspot handle.
Engages or disengages both the pan and
tilt motors acting as a brake on head
movement. DMX control over pan is still
disabled and this is only available when
followspot mode is on.
Will engage (ON) the pan motor to acts as
a brake on head movement, or disengage
(OFF) it so the head can be freely panned
using a followspot handle. DMX control
over pan is still disabled and this command
is only available when followspot mode is
on.
Will engage (ON) the tilt motor to acts as a
brake on head movement, or disengage
(OFF) it so the head can be freely tilted
using a followspot handle. DMX control
over tilt is still disabled and this command
is only available when followspot mode is
on.
Automatic lamp striking disabled
Lamp strikes automatically within 90
seconds of fixture being powered on
Lamp strikes automatically when the
fixture receives a DMX signal
Lamp cannot be powered off via DMX (can
be overridden: see DMX protocol)
Lamp can be powered off via DMX
Fixture cannot be reset via DMX (can be
overridden: see DMX protocol)
Fixture can be reset via DMX
53
