Martin MAC III Profile User Manual page 47

Basic 16-bit
16-bit Extended
Mode Mode DMX Value
21 - 39
41 - 59
61 - 79
81 - 99
101 - 119
121 - 139
141 - 159
7 8
161 - 164
165 - 168
169 - 172
173 - 176
177 - 180
181 - 184
185 - 188
189 - 192
193 - 214
215 - 221
222 - 243
244 - 247
248 - 251
252 - 255
10 - 14
15 - 19
20 - 24
25 - 29
30 - 34
35 - 39
40 - 44
45 - 49
8 9
50 - 54
55 - 59
60 - 89
90 - 119
120 - 149
150 - 179
180 - 209
210 - 232
233 - 255
Percent Function
Color Wheel
Continuous Scroll
0 0 Open
Open → Slot 1 - Blue
1 - 19 1 - 7
20 8 Slot 1
Slot 1 → Slot 2 - Green
9 - 15
40 16 Slot 2
Slot 2 → Slot 3 - Orange
17 - 23
60 24 Slot 3
Slot 3 → Slot 4 - Minus green
25 - 31
80 32 Slot 4
Slot 4 → Slot 5 - Yellow
33 - 39
100 40 Slot 5
Slot 5 → Slot 6 - Congo (deep blue)
41 - 47
120 48 Slot 6
Slot 6 → Slot 7 - Red
49 - 55
140 56 Slot 7
Slot 7 → Open
57 - 63
160 64 Open
Stepped Scroll (snap to full color positions)
65 - 66 Slot 7 - Red
67 - 68 Slot 6 - Congo (deep blue)
69 - 70 Slot 5 - Yellow
71 - 72 Slot 4 - Minus green
73 - 74 Slot 3 - Orange
75 - 76 Slot 2 - Green
77 - 78 Slot 1 - Blue
79 - 80 Open
Continuous Rotation
CW, Fast → Slow
81 - 86
87 - 88 Stop (This will stop wherever the wheel is at the time)
CCW, Slow → Fast
89 - 94
Random color
95 - 96 Fast
97 - 98 Medium
99 - 100 Slow
Gobo wheel 1: gobo selection, indexing, shake, rotation
Indexed gobo: set indexed angle on channel 9 (16-bit) or 10 (16-bit ext.)
0 - 9 0 - 4 Open
4 - 5 Gobo 1 - 4-D cone
5 - 8 Gobo 2 - 5 circles in line
8 - 10 Gobo 3 - Snow storm
10 - 12 Gobo 4 - Spikes
12 - 14 Gobo 5 - Pin wheel
Continuous gobo rotation: set gobo rotation speed on channel 9 (16-bit) or 10
(16-bit ext.)
14 - 16 Gobo 1 - 4-D cone
16 - 18 Gobo 2 - 5 circles in line
18 - 20 Gobo 3 - Snow storm
20 - 22 Gobo 4 - Spikes
22 - 24 Gobo 5 - Pin wheel
Gobo shake centered on indexed position: set indexed angle on channel 9
(16-bit) or 10 (16-bit ext.). Shake angle increments in following steps:
10°, 15°, 30°, 45°, 60°, 90°, 135°, 180°, 270° and 360°
Gobo 1 - 4-D cone, 360° slow → 10° fast
24 - 34
Gobo 2 - 5 circles in line, 360° slow → 10° fast
35 - 45
Gobo 3 - Snow storm, 360° slow → 10° fast
46 - 56
Gobo 4 - Spikes, 360° slow → 10° fast
57 - 67
Gobo 5 - Pin wheel, 360° slow → 10° fast
68 - 78
Continuous gobo wheel scroll with continuous gobo rotation: set gobo rotation
speed on channel 9 (16-bit) or 10 (16-bit extended)
CW scroll, fast → slow
79 - 89
CCW scroll, slow → fast
90 - 100
MAC III Profile DMX protocol 47
