Owner's manual OBKB01
CAUTION: 1. Weight on this product should not exceed 150kg
2 Exercise of a strenuous nature, as is customarily done on this equipment,
Should not be undertaken without first consulting
No specific health claims are made or implied as they relate to the equipment.
Measurements made by the equipment are believed to be accurate, but only the
measurements of your physician should be relied upon.
IMPORTANT: Read all instruction carefully before using this product. Retain this product owner's
manual for future reference.
OBKB01
• Warranty
• Assembly
• Parts
a
physician.
Advertisement
Related Manuals for Orbit OBKB01
Summary of Contents for Orbit OBKB01
- Page 1 OBKB01 • Warranty • Assembly • Parts Owner's manual OBKB01 CAUTION: 1. Weight on this product should not exceed 150kg 2 Exercise of a strenuous nature, as is customarily done on this equipment, Should not be undertaken without first consulting physician.
- Page 2 Drawing for Assembly M - 2 L - 1 0 L - 2 H - 1 L - 3 L - 6 E - 3 L - 7...
- Page 3 Exploded drawing G - 1 1 G - 1 3 F - 1 F - 2 F - 5 F - 3 F - 4...
-
Page 4: Parts List
Parts List Part No. Description Spec. Computer 1PCS Screw 4PCS Axle assembly 1SET Hex. Bolt 3PCS Drive pulley 1PCS Sleeve 1PCS Axle set 1PCS Flywheel assembly 1SET Flywheel 1PCS Star washer 2PCS 3PCS Flat washer 1PCS Bearing 1PCS Bearing 1PCS One-way bearing set 1PCS Bearing... - Page 5 Main frame 1PCS Resistant screws 2PCS Adjustable knob 1PCS Screw M4x10L 1PCS 1PCS Wave washer φ17.5xφ25x0.3t 1PCS Flat washer φ17.5xφ25x0.3t C-ring 1PCS Crank (Left) 1PCS Crank (Right) 1PCS G-10 Sleeve for seat post 1PCS G-11 Bearing 2PCS 1PCS ODφ16xφ2.0x35T G-12 Idler spring G-13 Sensor box...
- Page 6 Drilling screws 4PCS Seat post 1SET Seat slider assembly 1SET Screw M5xP0.8x12L 2PCS Cover for seat slider(R) 1PCS Seat slider 1PCS Cap for seat slider 1PCS Fixing screw bracket 7/16"-14 1PCS Flat washer 1PCS φ14.3xφ25x2.0t Knob for seat slider 1PCS Cover for seat slider (L) 1PCS Self-tapping screw...
- Page 7 Assembly Stage #1 G - 1 J - 7 I - 5 M8*16L 8*2T 1. Attach the front Stabilizer (J-7) to the main Frame (G-1) using two screws (N-1) and flat washers (N-2). 2. Attach the rear Stabilizer (I-5) to the main Frame (G-1) using two screws (N-1) and flat washers (N-2).
- Page 8 Assembly Stage #2 G - 1 G - 2 4 G - 2 4 G - 8 1. Assemble the two pedals (G-24 R+L) onto the Crank (G-8, G-9) with a screw driver. Remarks: Screw the left pedal’s spindle counter-clockwise and the right pedal’s spindle clockwise.
- Page 9 Assembly Stage #3 G - 1 1. Assemble the seat (L-10) to the seat slider. The Slider can be adjusted in different angles. Tighten the two Nuts under the Seat using a screwdriver. In addition, the Slider can be adjusted in horizontal level by loosening the Knob. 2.
- Page 10 Assembly Stage #4 H - 1 E - 3 8 * 2 T 8 * 2 T M 8 * 1 6 L 1. Put the cover (G-23) into the Handlebar post (H-1). Connect the sensor wires Upper & lower (H-2, G-25). 2.
- Page 11 Assembly Stage #5 M - 2 M - 5 H - 1 1. Assembly the handlebar (M-2) onto the handlebar post (H-1). 2. Put the cover (N-7) and tighten the T-knob (N-6).
- Page 12 Assembly Stage #6 M - 5 Plug the wire (H-2 & M-5) and assemble the computer (A) with 4 screws (A-1) by wrench.
- Page 13 Assembly Stage #7 Plug the adapter (G-22) into socket as picture above.
- Page 14 FGTOOLS & PARTS DB01R N - 6 T - s h a p e k n o b M 8 * 6 5 L ( 1 ) N - 2 R e g u l a r W a s h e r N - 1 A l l e n B o l t φ...
- Page 15 INSTRUCTION MANUAL OF SM2705 BUTTON FUNCTION: In stop mode, confirm all exercise data setting(Time, DST,CAL, Pulse, etc), and MODE/ENTER enter into program. RESET Press it in the STOP mode, return to the main menu. Press the mode 2s at any time, buzzer sound 1s and LCD display 2s then return to the main menu as “TOTAL RESET”.
- Page 16 SLEEP MODE No signal(SENSOR, KEYBOARD, PULSE value display) input over 4 minutes, system will enter SLEEP MODE. All set and calculated value will be saved. When power on and start next time, it will go on with the calculated value. FUNCTION TIME Display range 0:00~99:99 ;...
