Owner's manual OBK170M
CAUTION: 1. Weight on this product should not exceed 150kg
2 Exercise of
Should not be undertaken without first consulting
No specific health claims are made or implied as they relate to the equipment.
Measurements made by the equipment are believed to be accurate, but only the
measurements of your physician should be relied upon.
IMPORTANT: Read all instruction carefully before using this product. Retain this product owner's
manual for future reference.
OBK170M
strenuous nature, as is customarily done on this equipment,
a
• Warranty
• Assembly
• Parts
a
physician.
Advertisement
Table of Contents
Related Manuals for Orbit OBK170M
Summary of Contents for Orbit OBK170M
- Page 1 OBK170M • Warranty • Assembly • Parts Owner's manual OBK170M CAUTION: 1. Weight on this product should not exceed 150kg 2 Exercise of strenuous nature, as is customarily done on this equipment, Should not be undertaken without first consulting physician.
- Page 2 Assembly PRECAUTIONS WARNING: This bicycle has been designed and constructed to provide maximum safety. Nevertheless, certain precautions should be taken when using exercise equipment. Read the whole manual before assembling and using the bicycle. The following safety precautions should also be observed: 1.
-
Page 3: Hardware Chart
Hardware chart AB170 K-2: Spring Washer for 8 14*2T(4) K - 7 : k n o b ( 1 ) K - 3 : F lat Washer 8* 19*2T (4) K-1: Allen bolt M8*P1.25*55L(4) K-10:Allen Key(1) 5mm K-9: Screw(2) K-4: Screwdricer(1) K-5:Allen Key(1) 6mm K - 6 : B o x S p a n n e r ( 1 ) K-8: Screw(4) -
Page 4: Part List
Part list Item Description Q'ty Computer Screw for computer HBR Post assembly Handlebar post Cable for post Screw for bracket cover Handlebar assembly Handlebar Hand grip Hand pulse set Cable for handlebar End cap for handlebar Screw for handpulse Frame assembly set Main frame Hex bolt Belt pulley... - Page 5 Item Description Q'ty D-11 Side cover - L D-12 Side cover - R D-13 Screw M4 D-14 Screw M5 D-15 Wave washer D-16 Flat washer D-17 C clip D-18 Crank - R D-19 Crank - L D-20 Bearing 6203 D-21 Sensor holder D-22 Flat washer...
- Page 6 Item Description Q'ty Bearing 6003 Flat washer Single bearing Bearing 6203 Flywheel axle Pulley F-10 Bearing 6000 F-11 Flat washer F-12 N u t F-13 Star washer Front stabilizer set Front foot Transportation wheel Screw Flat washer Nylon nut Adjusting pad End cap for front stabilizer Rear stabilizer set Rear foot...
- Page 7 Item Description Q'ty End cap for slider set Screw Belt Idle set Belt idle Idle wheel Wave washer Screw Nylon nut Flat washer Flat washer Screw Hardware kit Screw Spring washer Flat washer Screw driver Allen key 6mm Box spanner Knob for handlebar Screw Screw...
- Page 8 Item Description Q'ty Low cover for front post Side cover for HBR-L Side cover for HBR-R Cover for front foot Cover for rear foot Cover for crank Screw...
- Page 9 Drawing for assembly...
-
Page 10: Explosion Drawing
Explosion drawing... - Page 11 STEP 1 STEP 1 STEP 1 STEP 1 # K - 5 # K - 1 # K - 2 # K - 3 STEP STEP STEP STEP 2 2 2 2 # K - 4 # K - 8...
- Page 12 STEP 3 STEP 3 STEP 3 STEP 3 # K - 4 STEP 4 # K - 6...
- Page 13 Step 5 # K - 1 0...
- Page 14 Step 6...
- Page 15 Step 7 # K - 4 # K - 9 # B - 3...
- Page 16 INSTRUCTION MANUAL OF SM1590-71 DISPLAY FUNCTIONS ITEM DESCRIPTION TIME Count up - No preset target, Time will count up from 00:00 to maximum 99:59 with each increment is 1 minute. Count down - If training with preset Time, Time will count down from preset to 00:00. Each preset increment or decrement is 1 minute between 00:00 to 99:00.
-
