Owner's manual OBR170M
CAUTION: 1. Weight on this product should not exceed 150kg
2 Exercise of
Should not be undertaken without first consulting
No specific health claims are made or implied as they relate to the equipment.
Measurements made by the equipment are believed to be accurate, but only the
measurements of your physician should be relied upon.
IMPORTANT: Read all instruction carefully before using this product. Retain this product owner's
manual for future reference.
OBR170M
strenuous nature, as is customarily done on this equipment,
a
• Warranty
• Assembly
• Parts
a
physician.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OBR170M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Orbit OBR170M

Summary of Contents for Orbit OBR170M

  • Page 1 OBR170M • Warranty • Assembly • Parts Owner's manual OBR170M CAUTION: 1. Weight on this product should not exceed 150kg 2 Exercise of strenuous nature, as is customarily done on this equipment, Should not be undertaken without first consulting physician.
  • Page 2 Assembly PRECAUTIONS WARNING: This bicycle has been designed and constructed to provide maximum safety. Nevertheless, certain precautions should be taken when using exercise equipment. Read the whole manual before assembling and using the bicycle. The following safety precautions should also be observed: 1.
  • Page 3 Hardware chart AR170 φ φ φ φ T - 5 : S C R E W M 4 * 3 0 L ( 1 ) T - 9 S c r e w d r i v e r ( 1 ) T-10 Allen Key(1) Checking List AR170...

  • Page 4: Part List

    Part list I t e m D e s c r i p t i o n Q ' t y C o m p u t e r S e t S E T A - 1 C o m p u t e r P C S A - 2 S c r e w M 5...
  • Page 5 I t e m D e s c r i p t i o n Q ' t y E - 7 W i r e 2 0 0 m m P C S E - 8 S c r e w M 4 P C S E - 9 S e n s o r h o l d e r...
  • Page 6 I t e m D e s c r i p t i o n Q ' t y E - 3 3 a d a p t e r P C S F l y w h e e l s e t S E T F - 1 F l y w h e e l...
  • Page 7 I t e m D e s c r i p t i o n Q ' t y I - 3 W a v e w a s h e r P C S I - 4 H e x s c r e w P C S I - 5 N y l o n n u t...
  • Page 8 I t e m D e s c r i p t i o n Q ' t y L - 1 S u p p o r t f o r b a c k p a d P C S L - 2 C a p P C S...
  • Page 9 I t e m D e s c r i p t i o n Q ' t y R - 1 S e a t P C S R - 2 P e d a l P C S R - 3 C o v e r f o r f r o n t s u p p o r t P C S...
  • Page 10 Drawing for assembly...
  • Page 11 Explosion drawing...
  • Page 12 STEP 1 STEP 1 STEP 1 STEP 1 # T - 1 # T - 2 # T - 3 # T - 1 0 STEP STEP 2 2 2 2 STEP STEP # T - 9 # T - 4...
  • Page 13 STEP 3 STEP 3 STEP 3 STEP 3 # B - 4 # B - 5 # T - 1 0 # B - 6 STEP 4 # T - 8 # T - 3 # T - 1 0...
  • Page 14 Step 5 # T - 8 # T - 7 # T - 6 # T - 3 # T - 1 0 Step 6 # T - 6 # T - 3 # T - 1 0...
  • Page 15 Step 7 # A - 2 # T - 9 Step 8 # T - 9 # T - 4 # T - 5...
  • Page 16 INSTRUCTION MANUAL OF SM1590-71 DISPLAY FUNCTIONS ITEM DESCRIPTION TIME Count up - No preset target, Time will count up from 00:00 to maximum 99:59 with each increment is 1 minute. Count down - If training with preset Time, Time will count down from preset to 00:00. Each preset increment or decrement is 1 minute between 00:00 to 99:00.
  • Page 17 OPERATION: POWER ON Plug in power supply, computer will power on and display all segments on LCD for 2 seconds (Drawing 1). Drawing 1 WORKOUT SELECTION Use UP or DOWN (Encoder) to select workout Manual (Drawing 2) Beginner(Drawing 3) Advance (Drawing 4) Sporty(Drawing Cardio(Drawing 6) Watt(Drawing 7).
  • Page 18 4. Press START/STOP keys to pause workout. Press RESET to reverse to main menu. Drawing 8 Drawing 9 Drawing 10 Drawing 11 Drawing 12 Beginner Mode Use UP or DOWN (Encoder) to select workout program, choose Beginner mode and press MODE / ENTER to get into.
  • Page 19 Sporty Mode Use UP or DOWN (Encoder) to select workout program, choose Sporty mode and press MODE / ENTER to get into. Use UP or DOWN (Encoder) to select Sporty program 1~4 (Drawing 15) and press MODE / ENTER to get into.
  • Page 20 RECOVERY After exercising for a period, keep holding on hand grips or wearing chest strap and press RECOVERY key. All function display will stop except “TIME” starts counting down from 00:60 to 00:00 (Drawing 19). Screen will display your heart rate recovery status with the F1, …...
  • Page 21 1. This console can connect APP on the smart device by Bluetooth. 2. Once console is connect to smart device via Bluetooth, the console will power off. Custom Mode: Users can put the fuctions’ icon on the APP front page as they ☆...
