Before You Start Thank you for purchasing this Elliptical Bike! For your safety and benefit, read this manual carefully before using the machine. Prior to assembly, remove components from the box and verify that all the listed parts were supplied. Assembly instructions are described in the following steps and illustrations. IMPORTANT SAFETY NOTICE PRECAUTIONS BE SURE TO READ THE ENTIRE MANUAL BEFORE YOU ASSEMBLE OR... -
Page 3: Exploded Diagram
EXPLODED DIAGRAM - 2 -... -
Page 4: Parts List
PARTS LIST Description Description Mainframe Protective guard Rear end cap Phillips pan head screw Rear bottom tube Arc washer Allen bolt M8×90 Waved washer Flat washer D10×Φ20×2 Carriage bolt M8×45 Nylon nut M10 Hexagon bolt M8×45 Plastic bushing Φ28×16×Φ16.1 Hexagon bolt M10×55 Alloy bushing Φ18×Φ10×11 39L/R L/R pedal tube joint 1 each... - Page 5 ASSEMBLY INSTRUCTIONS NOTE: Most of the listed assembly hardware has been packaged separately, but some hardware items have been preinstalled in the identified assembly parts. In these instances, simply remove and reinstall the hardware as assembly is required. Please reference the individual assembly steps and make note of all preinstalled hardware. PREPARATION: Before assembling, make sure that you will have enough space around the item;...
- Page 6 metal bracket of Lower tension cable (52) as shown; 3. Tighten the Handlebar post (46) to the Mainframe (1) with Allen bolts (45), Spring M8x16 washers (44), and Flat washers (12); Then slide down the Mast cover (49) in position. STEP 3: 1.Pass the Pulse wire (43) through out of the Computer bracket on top of Handlebar post (46) as show;...
- Page 7 STEP 4: 1.Fit the L/R Swing tube (24L/R) to the Long axle (61) on the Handlebar post (46) with Allen bolt (10), Spring washer (11), D-Shape washer (9), and Waved washers (35); M10x20 2.Attach the L/R Pedal tube Joint (39L/R) to the L/R Crank (56L/R) with Allen bolt (10), M10x20 Spring washer (11), Flat washer(62),D-Shape washer (9), and Waved washers (35) as...
- Page 8 STEP 5: Tighten the L/R Pedal (14L/R) to the L/R Pedal support (15L/R) with Hexagon bolts M8×45 (37), Flat washers (12) and Nylon nuts (13) as shown. Note: The pedal has been labeled L for Left & R for Right. - 7 -...
- Page 9 STEP 6: 1.Cover the Joint part of L/R Handlebar (28L/R) and L/R Swing tube (24L/R) with Protective guard (26a/b) & (55a/b), then fix them with Tapping screws (27); 2.Fix the Protective guard (17L/R) & (54a/b) to the L/R Pedal support (15L/R) & L/R pedal tube joint (39L/R) respectively with Tapping screws (59) &...
-
Page 10: Warm-Up And Cool-Down
WARM-UP and COOL-DOWN A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week. WARM-UP The purpose of warming up is to prepare your body for exercise and to minimize injuries. -
Page 11: Specifications
OPERATION GUIDE SPECIFICATIONS: TIME ………………………………………………….…. 00:00-99:59 SPEED(SPD) ..………………………………………..0.0-99.9KM/H (ML/H) DISTANCE ……………………………………………..0.00-9999KM (ML) CALORIES ……………………………………………..0.0-9999KCAL ODOMETER(ODO) …………………………..…….….. 0.0-9999KM (ML) PULSE(PUL) ……............0-240BPM KEY FUNCTIONS: 1. MODE: This key is to select and lock on to a particular function you want. 2. - Page 12 4. CALORIE: Press the MODE key until pointer lock on to CALORIE. The calorie burned will be displayed when starting exercise. 5. ODOMETER(if have): Press the MODE key until the pointer advance to ODOMETER. The total accumulated distance will be shown. 6.
