Function parts of device

Figure 3:
The pinout of the 10pin mini-USB Female connector on the MAMBO2-B6 device:
Figure 4: 10pin mini-USB female connector
PIN NAME
1 SPK-RE
2 VCC_USB
3 SPK_LI
4 USB_DM
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Parts of the MAMBO2-B6
DESCRIPTION
Speaker right (+)
+ 5 VDC for normal charge
Speaker left (-)
USB Data -
V 1.0.4
ERSION
Page 21 of 28
