5.3.3

Connecting the MAMBO2-B6 to a PC USB port

After charging the internal battery has been completed, to be able to transfer data from/to the
MAMBO2-B6 device you have to power on the device and connect it to a Laptop or PC using the
included mini-USB-to-USB cable.
1. First turn on the MAMBO2-B6 and wait until the device is completely started and the first
screen on the display is shown.
2. If the inserted SIM card is protected by a PIN code, you will be requested to enter it, after
turning on the device. To enter it use the 5-way navigation key and confirm it with OK.
3. After the first overview screen on the MAMBO2 display is shown, plug in the USB connector of
the cable to a free USB port on your Laptop or PC and then plug the other site of this cable to
the mini-USB port of the MAMBO2-B6, as shown in the figure below.
4. When you connect the MAMBO2-B6 device to a PC for the first time, Windows
that unknown hardware has been found and start a procedure to find the corresponding driver
files and install them.
5. If the USB driver is still not downloaded from the FALCOM's website (go to: www.falcom.de >
Support > Drivers & Firmware and then select MAMBO2 from the selection box after Login),
download it. Browse the hardware assistant to the directory where the driver was stored (e.g.
D:\Driver). This will help Windows correctly install the USB driver.
6. When the device is properly installed, the windows device manager will look as shown
below:
* For Vista users, log on using the account of the Administrator, otherwise you will not be able to install the USB driver.
For Linux users, refer to the related documents
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
ANUAL
Figure 7: Configuring the device with the help of a Laptop or PC
Figure 7: COM port assigned in Device Manager
