Power consumption for MAMBO2-B6 without options

Device Modes by PFAL commands
PFAL,Sys.Power.Mode=auto,30
PFAL,Cnf.Set,DISP.SAVER=1,1
PFAL,Cnf.Set,DISP.SAVER=2,1
PFAL,Sys.Device.Shutdown
PFAL,Sys.Device.Sleep=Ign+Ring+Motion+Timer=1:20:00
PFAL,Sys.GSM.Disable
PFAL,Sys.GSM.PowerMode=enable
PFAL,Sys.GPS.Disable
PFAL,Sys.GPS.Sleep
Full operational
HN = Hibernate; TP = TricklePower; SLEEP = Device remains registered on the network and reachable.
Note: The values in the table above are measured at FALCOM's laboratory and can vary depending upon Hardware/Software
configurations and environmental conditions. Therefore, there is no guarantee that the avarage values given above will be the same
in your scenario.
Table 2: MAMBO2-B6 power consumption in different operation modes
4.1.2

Operating temperatures

Parameter
Storage temperature
Operating temperature*
Charging temperature
* Recommended discharging temperature range is 0-40°C, beyond which it will result in decadence of the battery performance and shortness
of its life.

4.1.3 Battery Technical Data (1650 mAh)

Electrical characteristics and operating conditions:
•
Nominal voltage (V)
•
Typical capacity 20°C (mA/h)
•
Charging method
•
Charging voltage
•
Charging Time
•
Charging current
•
Charging temperature range
•
Max. discharge current
•
Discharge temperature range
