4.2 NMEA & FALCOM data message
MAMBO2-B6 delivers data in the NMEA-0183 format. Table 4 lists each of the NMEA and FALCOM
output messages supported by the MAMBO2-B6 terminal and a brief description.
description about NMEA, see related documents
The firmware offers the possibility to switch on or off each protocol listed below for local use. With
the help of PFAL commands supported by this firmware these protocols can also be transferred via
SMS, TCP, Data call and e-mail.
NMEA Description
GGA Time, position and fix type data.
GLL Latitude, longitude, UTC time of position fix and status.
GSA GPS receiver operating mode, satellites used in the position solution and DOP values.
VTG The number of GPS satellites in view satellite ID numbers, elevation, azimuth and SNR values.
GSV The number of GPS satellites in view satellite ID numbers, elevation, azimuth and SNR values.
RMC Time, date, position, course and speed data.
FALCOM Description
IOP The voltage level of the internal battery.
GSM The GSM operator, reception, registration status, GSM field strength, area code and cell ID.
AREA The state of 32 areas.
3DP The state of the Motion Sensor.
BIN User protocol including time, date, position, course and speed data.
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
Table 5: NMEA Output Messages
[1].
