MAMBO2-B6 H
M
ARDWARE
ANUAL
PIN
NAME
5
MIC +
6
USB_DP
7
NC
8
VCC_12V
9
GND
10
GND
Table 6:
This confidential document is a property of FALCOM and may not be copied or circulated without previous permission.
The pinout of the 10pin mini-USB Female connector
DESCRIPTION
Microphone
USB Data +
Not connected
Vmax. +12 V DC for quick charg
Audio Ground
USB Ground
V
1.0.4
ERSION
Page 22 of 28
