Part No. 060365-00, Rev. A
January 2013
OmniSwitch 6850E Series
Hardware Users Guide
www.alcatel-lucent.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OmniSwitch 6850E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel-Lucent OmniSwitch 6850E Series

Summary of Contents for Alcatel-Lucent OmniSwitch 6850E Series

  • Page 1 Part No. 060365-00, Rev. A January 2013 OmniSwitch 6850E Series Hardware Users Guide www.alcatel-lucent.com...
  • Page 2 6.4.5.R02 Release. The specifications described in this guide are subject to change without notice. Copyright © 2013 by Alcatel-Lucent. All rights reserved. This document may not be reproduced in whole or in part without the express written permission of Alcatel-Lucent.

  • Page 3: Table Of Contents

    Technical Support ......................xiii Chapter 1 OmniSwitch 6850E Series ..................1-1 Availability Features ....................... 1-2 Chapter 2 OmniSwitch 6850E Series Chassis and Hardware Components ....2-1 OmniSwitch 6850E-24..................... 2-3 OS6850E-24 Specifications ..................2-4 OmniSwitch 6850E-P24....................2-6 OS6850E-P24 Specifications ................... 2-7 OmniSwitch 6850E-24X ....................
  • Page 4 Syslog Message ......................2-48 Link OAM PDU ..................... 2-49 Chapter 3 OmniSwitch 6850E Series Power Supplies ............3-1 OmniSwitch 6850E Series Power Supplies ..............3-2 Connecting a Power Supply Directly to the Chassis ..........3-9 Connecting a Power Supply with a Cable .............. 3-10 DC Power Supply Considerations ................
  • Page 5 Enabling Priority Disconnect ................... 5-9 Monitoring Power over Ethernet via CLI ..............5-12 Chapter 6 Managing OmniSwitch 6850E Series Stacks ............6-1 In This Chapter ........................6-2 OmniSwitch 6850E Series Stacking Specifications ............6-3 OmniSwitch 6850E Series Stack Overview ..............6-4 Roles Within the Stack ....................
  • Page 6 Leer “información importante de seguridad” ..........A-14 Advertencia de acceso restringido ..............A-14 Advertencia de pulsera antiestática ..............A-14 Clase de seguridad ..................A-14 Advertencia de fuentes de poder ..............A-14 Index ..........................Index-1 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 7: About This Guide

    About This Guide This OmniSwitch 6850E Series Hardware Users Guide describes your switch hardware components and basic switch hardware procedures. Supported Platforms This information in this guide applies to the following products: • OmniSwitch 6850E-24/P24/24X/P24X • OmniSwitch 6850E-48/P48/48X/P48X • OmniSwitch 6850E-U24X...
  • Page 8 • OmniSwitch (original version with no numeric model name) • OmniSwitch 6600 Family • OmniSwitch 6800 Series • OmniSwitch 6850 Series • OmniSwitch 7700 • OmniSwitch 7800 • OmniSwitch 8800 • OmniSwitch 9000 Series • OmniStack • OmniAccess page viii OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 9: Who Should Read This Manual

    The audience for this users guide is network administrators and IT support personnel who need to config- ure, maintain, and monitor switches and routers in a live network. However, anyone wishing to gain knowledge on the OmniSwitch 6850E Series hardware will benefit from the material in this guide. When Should I Read this Manual? Read this guide as soon as you are ready to familiarize yourself with your switch hardware components.

  • Page 10: How Is The Information Organized

    Pertinent Documentation: OmniSwitch 6850E Series Getting Started Guide Release Notes The OmniSwitch 6850E Series Getting Started Guide provides all the information you need to get your switch up and running the first time. This guide provides information on unpacking the switch, rack mounting the switch, installing stacking cables, installing backup power supplies, unlocking access control, setting the switch’s IP address, setting up a password, and setting up stacks.
  • Page 11 CLI-to-MIB variable mapping information for all CLI commands supported by the switch. This guide can be consulted anytime during the configuration process to find detailed and specific information on each CLI command. OmniSwitch 6850E Series Hardware Users Guide page xi January 2013...

  • Page 12: Related Documentation

    About This Guide Related Documentation The following are the titles and descriptions of all the OmniSwitch 6850E Series user manuals: • OmniSwitch 6850E Series Getting Started Guide Describes the hardware and software procedures for getting an OmniSwitch 6850E Series switch up and running.

  • Page 13: Published / Latest Product Documentation

    Published / Latest Product Documentation Published / Latest Product Documentation All user guides are included on the Alcatel-Lucent public website. This website also includes user guides for other Alcatel-Lucent Enterprise products. The latest user guides can be found on our website at: http://enterprise.alcatel-lucent.com/?dept=UserGuides&page=Portal...
  • Page 14 Technical Support About This Guide page xiv OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 15: Omniswitch 6850E Series

    1 OmniSwitch 6850E Series The OmniSwitch 6850E Series are an advanced fixed configuration family of stackable Ethernet switches. These switches provide wire rate layer-2 forwarding and layer-3 routing with advanced services, effective availability, resiliency, and security features and are ideal for the following network applications: •...

  • Page 16: Availability Features

    Backup power supplies operate in active standby mode. If the primary power supply fails unexpectedly, the backup power supply automatically takes up the full power load without disrupting the switch. page 1-2 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 17: Hot Swapping

    LEDs, which provide visual status information, are provided on the chassis front panel. LEDs are used to indicate conditions such as hardware and software status, temperature errors, link integrity, data flow, etc. For detailed LED descriptions, refer to Chapter 2, “OmniSwitch 6850E Series Chassis and Hardware Components.” User-Driven Monitoring User-driven hardware monitoring refers to CLI commands that are entered by the user in order to access the current status of hardware components.
  • Page 18 Availability Features OmniSwitch 6850E Series page 1-4 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 19: Chapter 2 Omniswitch 6850E Series Chassis And Hardware Components

    “OmniSwitch 6850E-P48” on page 2-17) • OmniSwitch 6850E-48X (see “OmniSwitch 6850E-48X” on page 2-20) • OmniSwitch 6850E-P48X (see “OmniSwitch 6850E-P48X” on page 2-23) • OmniSwitch 6850E-U24X (see “OmniSwitch 6850E-U24X” on page 2-26) OmniSwitch 6850E Series Hardware Users Guide page 2-1 January 2013...

  • Page 20: Omniswitch 6850E-24

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-24 O mni S witch 6850E-C24 CLASS 1 LASER PRODUCT R ear C onsole R ear OS6850E-24 Front Panel Item Description LED Indicator Seven segment LED provides stack element ID. USB Port High speed USB port.
  • Page 21 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-24 Rear Panel OS6850E-24 Rear Panel Item Description Grounding Block Type LCD8-10A-L grounding lug Redundant Power Supply Connector DB-25 connector for optional external redundant power supply. Primary Power Supply Connector DB-25 connector for required external primary power supply.

  • Page 22: Os6850E-24 Specifications

    Per stack - 16 (Note: All used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.

  • Page 23: Omniswitch 6850E-P24

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-P24 O mni S witch 6850E-P24 CLASS 1 LASER PRODUCT R ear C onsole R ear OS6850E-P24 Front Panel Item Description LED Indicator Seven segment LED provides stack element ID. USB Port High speed USB port.
  • Page 24 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-P24 Rear Panel OS6850E-P24 Rear Panel Item Description Redundant Power Supply Connector DB-25 connector for optional external redundant power supply. Grounding Block Type LCD8-10A-L grounding lug Redundant Power Supply Connector DB-25 connector for optional redundant power supply.

  • Page 25: Os6850E-P24 Specifications

    Per stack - 16 (Note: All used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.

  • Page 26: Omniswitch 6850E-24X

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-24X O mni S witch 6850E-C24X CLASS 1 LASER CLASS 1 LASER PRODUCT PRODUCT R ear C onsole R ear OS6850E-24X Front Panel Item Description LED Indicator Seven segment LED provides stack element ID.
  • Page 27 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-24X Rear Panel OS6850E-24X Rear Panel Item Description Grounding Block Type LCD8-10A-L grounding lug Redundant Power Supply Connector DB-25 connector for optional external redundant power supply. Primary Power Supply Connector DB-25 connector for required external primary power supply.

  • Page 28: Os6850E-24X Specifications

    Per stack - 32 (Note: 16 used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.

  • Page 29: Omniswitch 6850E-P24X

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-P24X O mni S witch 6850E-P24X CLASS 1 LASER CLASS 1 LASER PRODUCT PRODUCT R ear C onsole R ear OS6850E-P24X Front Panel Item Description LED Indicator Seven segment LED provides stack element ID.
  • Page 30 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-P24X Rear Panel OS6850E-P24X Rear Panel Item Description Redundant Power Supply Connector DB-25 connector for optional external redundant power supply. Grounding Block Type LCD8-10A-L grounding lug Redundant Power Supply Connector DB-25 connector for optional external redundant power supply.

  • Page 31: Os6850E-P24X Specifications

    Per stack - 32 (Note: 16 used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.

  • Page 32: Omniswitch 6850E-48

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-48 O mni S witch 6850E-C48 R ear CLASS 1 LASER PRODUCT C onsole R ear OS6850E-48 Front Panel Item Description LED Indicator Seven segment LED provides stack element ID. USB Port High speed USB port.
  • Page 33 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-48 Rear Panel Note. The figure shows a pre-production version of the chassis without product, safety, and compliance information labels. All production versions of the chassis have these labels. OS6850E-48 Rear Panel...

  • Page 34: Os6850E-48 Specifications

    Per stack - 16 (Note: All used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.

  • Page 35: Omniswitch 6850E-P48

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-P48 O mni S witch 6850E-P48 R ear CLASS 1 LASER PRODUCT C onsole R ear OS6850E-P48 Front Panel Item Description LED Indicator Seven segment LED provides stack element ID. USB Port High speed USB port.
  • Page 36 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-P48 Rear Panel OS6850E-P48 Rear Panel Item Description Redundant Power Supply Connector DB-25 connector for optional external redundant power supply. Grounding Block Type LCD8-10A-L grounding lug Redundant Power Supply Connector DB-25 connector for optional external redundant power supply.

  • Page 37: Os6850E-P48 Specifications

    Per stack - 16 (Note: All used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.

  • Page 38: Omniswitch 6850E-48X

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-48X O mni S witch 6850E-48X CLASS 1 LASER PRODUCT R ear C onsole R ear OS6850E-48X Front Panel Item Description LED Indicator Seven segment LED provides stack element ID. USB Port High speed USB port.
  • Page 39 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-48X Rear Panel OS6850E-48X Rear Panel Item Description Grounding Block Type LCD8-10A-L grounding lug Redundant Power Supply Connector DB-25 connector for optional external redundant power supply. Primary Power Supply Connector DB-25 connector for required external primary power supply.

  • Page 40: Os6850E-48X Specifications

    Per stack - 32 (Note: 16 used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.

  • Page 41: Omniswitch 6850E-P48X

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-P48X O mni S witch 6850E-P48X CLASS 1 LASER PRODUCT R ear C onsole R ear OS6850E-P48X Front Panel Item Description LED Indicator Seven segment LED provides stack element ID. USB Port High speed USB port.
  • Page 42 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-P48X Rear Panel OS6850E-P48X Rear Panel Item Description Redundant Power Supply Connector DB-25 connector for optional external redundant power supply. Grounding Block Type LCD8-10A-L grounding lug Redundant Power Supply Connector DB-25 connector for optional external redundant power supply.

  • Page 43: Os6850E-P48X Specifications

    Per stack - 32 (Note: 16 used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.

  • Page 44: Omniswitch 6850E-U24X

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-U24X OS6850E-U24X Front Panel Item Description LED Indicator Seven segment LED provides stack element ID. USB Port High speed USB port. System Status LEDs Provides status on hardware, software, primary and redundant power.
  • Page 45 OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E-U24X Rear Panel OS6850E-U24X Rear Panel Item Description Grounding Block Type LCD8-10A-L grounding lug Redundant Power Supply Connector DB-25 connector for optional external redundant power supply. Primary Power Supply Connector DB-25 connector for required external primary power supply.

  • Page 46: Os6850E-U24X Specifications

    Per stack - 32 (Note: 16 used for stacking) Maximum CX4 stacking ports Per switch - 2 Per stack - 16 Power “OmniSwitch 6850E Series Power Supplies” on page 3-2 Flash memory size 128 MB RAM memory size 512 MB SDRAM Width 17.32 in.
  • Page 47 OmniSwitch 6850E Series Chassis and Hardware Components OS6-XNI-U2 Module Stack B/X2 Stack A/X1 OS6-XNI-U2 Module Item Description SFP+ Ports and LEDs Two SFP+ connectors for various supported SFP+ transceivers. Refer to “OmniSwitch 6850E LED Status Indicators” on page 2-31 for LED status information.

  • Page 48: Omniswitch 6850E Port Numbering

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E Port Numbering The table below lists the port numbering for the OmniSwitch 6850E Series switches. Non-Combo Combo Ports Non-Combo Stacking/Uplink Ports SFP+ Ports Ports 1-20 21-24 25-26 OS6850E-24 OS6850E-P24 1-20 21-24...

  • Page 49: Omniswitch 6850E Led Status Indicators

    OmniSwitch 6850E Series Chassis and Hardware Components OmniSwitch 6850E LED Status Indicators OmniSwitch 6850E LED Status Indicators State Description Solid Green System software is operational. Solid Amber Hardware or System failure. Blinking Green Normal Diagnostics. Blinking Amber Switch operational but auto- configuration not successful.

  • Page 50: Mounting The Switch

    Mounting the Switch OmniSwitch 6850E Series Chassis and Hardware Components Mounting the Switch If you are relocating the switch, be sure to power it down and remove all network, stacking, and Note. power cables before moving. Airflow Considerations Be sure that your switch is placed in a well-ventilated, static-free environment. Always allow adequate clearance at the front, rear, and sides of the switch.

  • Page 51: Chassis Airflow

    OmniSwitch 6850E Series Chassis and Hardware Components Mounting the Switch Chassis Airflow The fans pull air from the air intake vent located on the left-hand side of the chassis. The air is directed horizontally through the chassis and past the circuit board. Airflow is then exhausted through the fan vents at the right-hand side of the chassis.

  • Page 52: Blank Cover Panels

    Mounting the Switch OmniSwitch 6850E Series Chassis and Hardware Components Blank Cover Panels Blank cover panels are provided with your switch and are used to cover empty backup power supply bays and 10 Gigabit uplink bays. These cover panels play an important role in chassis airflow and temperature management.

  • Page 53: Installing The Switch On A Tabletop Or Bench

    OmniSwitch 6850E Series Chassis and Hardware Components Mounting the Switch Installation Options The OmniSwitches can be installed in two ways: • Tabletop installation • Rack-mount installation Installing the Switch on a Tabletop or Bench OmniSwitches switches can be installed freestanding as tabletop units. Place your switch on a stable, flat, and static-free surface.

  • Page 54: Rack-Mounting The Switch

    19-inch rack-mount installations. These flanges must be attached to the chassis before the switch can be rack mounted. If you are installing the switch in a 23-inch-wide rack, Alcatel-Lucent offers optional 23-inch rack- Note. mounting hardware. For more information, contact your Alcatel-Lucent representative.

  • Page 55: Installing And Removing Combo Port Sfps

    OmniSwitch 6850E Series Chassis and Hardware Components Mounting the Switch 3 After the rack-mount flanges are secured to the chassis, mark the holes on the rack where the switch is to be installed. 4 Lift and position the switch until the rack-mount flanges are flush with the rack post.

  • Page 56: Setting Up A Stacked Configuration

    Setting Up a Stacked Configuration OmniSwitch 6850E Series Chassis and Hardware Components Setting Up a Stacked Configuration Rack Mounting Stacked Configurations To rack mount a stacked configuration, install all switches that are to be included in the stacked configura- tion as described on pages 2-36 through 2-37.
  • Page 57 OmniSwitch 6850E Series Chassis and Hardware Components Setting Up a Stacked Configuration 3 Insert the other end of the stacking cable into the stacking port of the switch immediately below. Once again, the stacking port (A or B) depends on the preferred cabling pattern.
  • Page 58 Setting Up a Stacked Configuration OmniSwitch 6850E Series Chassis and Hardware Components 5 To provide added resiliency and redundancy, you must install the redundant stacking cable to connect the top switch in the stack to the bottom switch. Connect the redundant cable now. Refer to the diagram...

  • Page 59: Booting Omniswitch 6850E Series Switches

    If any of the LED state differs from the states shown in the table above, refer to page 2-53 for more infor- mation. Contact Alcatel-Lucent Customer Support if the LED state persists. For information on logging in and configuring your OmniSwitch, refer to the Getting Started Guide and Switch Management Guide.

  • Page 60: Booting Stacked Configurations

    If any of the LED state differs from the states shown in the table above, refer to page 2-53 for more infor- mation. Contact Alcatel-Lucent Customer Support if the LED state persists. For information on logging in and configuring your OmniSwitch stack, refer to the Getting Started Guide and OmniSwitch Switch Management Guide.

  • Page 61: Power Cords

    OmniSwitch 6850E Series Chassis and Hardware Components Power Cords Power Cords Since the power cord is the switch’s only disconnect device, it should be plugged into an easily accessible outlet. In the event that your power cord is lost or damaged, refer to the specifications below.

  • Page 62: Console Port

    Console Port OmniSwitch 6850E Series Chassis and Hardware Components Console Port The console port, located on the chassis front panel, provides a console connection to the switch and is required when logging into the switch for the first time. By default, this RJ-45 connector provides a DTE console connection.
  • Page 63 OmniSwitch 6850E Series Chassis and Hardware Components Console Port 5 To change the stop bits value, enter boot serialstopbits, followed by the number of stop bits. Options include 1 (default) and 2. For example: Boot > boot serialstopbits 2 6 Verify your current changes by entering show at the boot prompt: Boot >...

  • Page 64: 10/100 Ethernet Port - Rj-45 Pinout (Non-Poe)

    Console Port OmniSwitch 6850E Series Chassis and Hardware Components Console Port Pinouts 10/100 Ethernet Port – RJ-45 Pinout (non-PoE) Pin Number Description not used not used not used not used Gigabit Ethernet Port – RJ-45 Pinout Pin Number Description BI_DB+...

  • Page 65: Rj-45 Console Port - Connector Pinout

    OmniSwitch 6850E Series Chassis and Hardware Components Console Port RJ-45 Console Port – Connector Pinout Pin Number Signals as DTE Console Port Ground Ground OmniSwitch 6850E Series Hardware Users Guide page 2-47 January 2013...

  • Page 66: Dying Gasp

    Dying Gasp OmniSwitch 6850E Series Chassis and Hardware Components Dying Gasp If the switch loses all power it will maintain power long enough to send a Dying Gasp message before completely shutting down. An SNMP trap, Syslog message and Link OAM PDUs will be generated.

  • Page 67: Link Oam Pdu

    OmniSwitch 6850E Series Chassis and Hardware Components Dying Gasp Link OAM PDU As soon as the power failure is detected an 802.3ah OAM Information PDU is sent to all ports for which link OAM is enabled and the LinkOAM port status is operational. The PDU will have the Dying Gasp bit set.
  • Page 68 Dying Gasp OmniSwitch 6850E Series Chassis and Hardware Components page 2-50 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 69: Omniswitch 6850E Series Power Supplies

    3 OmniSwitch 6850E Series Power Supplies OmniSwitch 6850E Series switches various Power over Ethernet (PoE) and non-PoE AC and DC Power supplies. This chapter includes detailed information on these power supply types. Topics include: • Power suppy technical specifications • Power supply chassis support •...
  • Page 70 OmniSwitch 6850E Series Power Supplies OmniSwitch 6850E Series Power Supplies OmniSwitch 6850E Series Power Supplies OmniSwitch 6850E Series switches support the following power supplies: • PS-900W-AC power supply (see “PS-900AC-P Power Supply” on page 3-4) • PS-510W-AC power supply (see “PS-510W-AC-E Power Supply”...

  • Page 71: Power Supply Shelf

    OmniSwitch 6850E Series Power Supplies Power Supply Shelf Alcatel-Lucent requires the use of power supply shelf when the power supply is used in a 1U (i.e, 1.5 inches/3.8 cm) configuration. In a 2U (i.e., 3 inches/7.6 cm) configuration you can mount the power supply tray directly to a rack.
  • Page 72 Maximum PoE Output Power 780 W Maximum System Output Power 126 W PoE Output Voltage -54.5 VDC PoE Output Current 14.3 A Sytem Output Voltage 12.0 VDC Sytem Output Current 10.5 A page 3-4 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 73 410 W Maximum System Output Power 120 W PoE Output Voltage -54.5 VDC PoE Output Current 7.53 A (maximum) Sytem Output Voltage 12.2 VDC (typical) Sytem Output Current 10.0 A (maximum) OmniSwitch 6850E Series Hardware Users Guide page 3-5 January 2013...
  • Page 74 230 W Maximum System Output Power 130 W PoE Output Voltage -54.5 VDC PoE Output Current 4.22 A (maximum) Sytem Output Voltage 12.0 VDC (typical) Sytem Output Current 10.8 A (maximum) page 3-6 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 75 System and PoE For Input Voltage Range 90 to 264 VAC Rated Frequency 50 to 60 Hz Maximum Output Power 126 W Output Voltage 12.0 VDC (typical) Output Current 10.5 A (maximum) OmniSwitch 6850E Series Hardware Users Guide page 3-7 January 2013...
  • Page 76 Input Voltage Range 36 to 72 VDC (24V Nominal Input) Input Current 3.3A @ 48VDC Maximum Output Power 120 W Output Voltage 12.0 VDC (typical) Output Current 10.0 A (maximum) page 3-8 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 77: Connecting A Power Supply Directly To The Chassis

    Carefully slide the power shelf so that it is flush against the back of the chassis. b Tighten the two captive screws located on the left and right sides of the power shelf. OmniSwitch 6850E Series Hardware Users Guide page 3-9...

  • Page 78: Connecting A Power Supply With A Cable

    Be sure to tighten each of the screws firmly using a Phillips screwdriver. Attaching a Rack-Mount Flange page 3-10 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 79 Tighten both screws until they are secure. Attaching the Power Shelf to the Rack Note. Be sure to install the screws in the bottom hole of each flange, as shown, before proceeding. OmniSwitch 6850E Series Hardware Users Guide page 3-11 January 2013...

  • Page 80: Connecting The Power Supply Cable

    Note. The diagrams below show examples of mounting the switch and power supplies in both a 2U and 3U scenario. Depending on the switch model, power supplies, and rack mounting options the actual mounting options will vary. page 3-12 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 81 1 3 . 5 i n c h e Redundant Small Power Supplies (i.e 126W) 1 3 . 5 i n c h e Redundant Large Power Supplies (i.e. 510W) OmniSwitch 6850E Series Hardware Users Guide page 3-13 January 2013...

  • Page 82: Dc Power Supply Considerations

    Twisted pair wire (red and black) for a DC power supply Note. Refer to the wiring diagram for information on connecting the DC power supply to a DC power source. page 3-14 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 83: Connecting A Dc Power Source

    The DC power supply on your switch contains a power connector with three (3) square slots for connect- ing the positive, negative, and ground wires from a DC power source. DC Power Connectors Side Screws for Connector Removal OmniSwitch DC Power Supply Connector OmniSwitch 6850E Series Hardware Users Guide page 3-15 January 2013...

  • Page 84: Installing Dc Power Source Wire Leads

    Push the wire in far enough such that it reaches the back wall of the connector, about a half inch inside. Ground Wire Attaching the Ground Wire page 3-16 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 85 (-) wire of the sourcing equipment must be connected to the negative (-) terminal of the OmniSwitch DC power supply." 5 Repeat Steps 2 through 4 for the remaining positive and negative wire leads. OS6850E Power Sup- DC Power Source Correct Polarity Connections OmniSwitch 6850E Series Hardware Users Guide page 3-17 January 2013...

  • Page 86: Viewing The Power Supply Status

    The primary (i.e., factory-installed) power supply is listed as PS-1 in the show power command output. The backup power supply is listed as PS-2. In the example above, there is no backup power supply installed. page 3-18 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 87: Monitoring The Chassis

    = 57, Temperature Range = UNDER THRESHOLD, Temperature Danger Threshold (deg C) = 72 For a complete list of output definitions for this command, refer to the OmniSwitch CLI Reference Guide. OmniSwitch 6850E Series Hardware Users Guide page 3-19 January 2013...

  • Page 88: Checking The Fan Status

    Displays the basic status information for individual modules. If the switch is a standalone, information for the standalone switch displays. page 3-20 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 89: Omniswitch Backup Power Shelf/System (Bps)

    4 OmniSwitch Backup Power Shelf/System (BPS) The OmniSwitch Backup Power Shelf/System (BPS) is a stackable power shelf that provides primary and backup system and PoE power to stacks of up to eight OS6850E switches. A maximum of two system power supplies and three POE power supplies can be installed in a single OS-BPS chassis.

  • Page 90: Chassis Details

    Chassis Details OmniSwitch Backup Power Shelf/System (BPS) Chassis Details OmniSwitch Backup Power Shelf/System (BPS) Front Panel Item Description A - C PoE Power Supply Bays D and E System Power Supply Bays Removable Mounting Plate OmniSwitch Backup Power Shelf/System (BPS) Rear Panel OmniSwitch BPS Item Description...

  • Page 91: Specifications

    OmniSwitch Backup Power Shelf/System (BPS) Specifications Specifications OmniSwitch Backup Power Shelf/System (BPS) Chassis Specifications Chassis Width (with brackets) 48.2 cm (19 inches) Chassis Width (without brackets) 43.3 cm (17.05 inches) Chassis Height 4.4 cm (1.73 inches or 1RU) Overall Unit Height with Factory-Attached Mounting Plate 6.67 cm (2.625 inches or 1.5RU) Overall Chassis Depth 46.04 cm (18.125 inches)

  • Page 92: Considerations If Os-Bps Is The Only Power Source In A Stack

    Chassis Status LEDs OmniSwitch Backup Power Shelf/System (BPS) Power Supply Redundancy Power supplies installed in the same OS-BPS chassis may operate in a redundant or backup configuration by sharing the same electrical load with another power supply. Hot Swapping OS-BPS power supplies are hot swappable. If redundant power supplies are operating in the chassis, a power supply can be removed or replaced without adversely affecting normal operation.
  • Page 93 OmniSwitch Backup Power Shelf/System (BPS) Chassis Status LEDs OS-BPS Connector Priority If the total available PoE or system power drops below the minimum budget required for the current configuration, the OS-BPS automatically powers off switches according to priority until the configuration falls within the available power budget.

  • Page 94: Mounting The Chassis

    Mounting the Chassis OmniSwitch Backup Power Shelf/System (BPS) Mounting the Chassis General Mounting Recommendations Elevated Operating Ambient Temperature. If installed in a closed or multi-rack assembly, the operating ambient temperature of the rack environment may be greater than the room’s ambient temperature. Therefore, consideration should be given to the maximum rated ambient temperature (Tmra) specified on page 4-3.

  • Page 95: Omniswitch Bps Airflow

    OmniSwitch Backup Power Shelf/System (BPS) Mounting the Chassis OmniSwitch BPS Airflow The OmniSwitch Backup Power Shelf/System (BPS) power supplies are installed in power supply bays located at the front of the chassis. Each power supply draws air through intake vents at the front of the power supply.
  • Page 96 Mounting the Chassis OmniSwitch Backup Power Shelf/System (BPS) Blank Cover Panels Blank cover panels are provided with your chassis and are used to cover empty slots. These cover panels play an important role in chassis airflow and temperature management. If your chassis is not fully populated and blank cover panels are not installed over empty slot locations, airflow is affected.

  • Page 97: Rack-Mounting

    • The chassis has rack-mount flanges that support standard 19-inch rack mount installations. • Alcatel-Lucent does not provide rack-mount screws. Use the screws supplied by the rack vendor. • To prevent a rack from becoming top heavy, it is recommended that you install the chassis at the bottom of the rack whenever possible.
  • Page 98 Rack-Mounting OmniSwitch Backup Power Shelf/System (BPS) 5 Insert the remaining rack-mount screws through the empty holes in the flange and tighten. 6 Next, secure the back of the chassis to the rear rack posts. With the flanges facing out, insert the slide- in braces into the slot rails until they meet the rear rack posts.
  • Page 99 OmniSwitch Backup Power Shelf/System (BPS) Rack-Mounting Mid-Mounting the Chassis In the Rack The chassis may also be installed in the rack using mid-mount flanges. To mid-mount the chassis in a rack, follow the steps below. 1 If applicable, remove the factory-installed front mounting plate and slot rails from the side of the chassis by loosening and removing the attachment screws.
  • Page 100 Rack-Mounting OmniSwitch Backup Power Shelf/System (BPS) 6 Once the holes are aligned, the second person should insert a screw through the bottom hole on each flange. Tighten both screws until they are secure. 7 Once the flanges are aligned, install the remaining screws. Be sure that all screws are securely tightened.

  • Page 101: Power Supplies

    OmniSwitch Backup Power Shelf/System (BPS) Power Supplies Power Supplies OmniSwitch Backup Power Shelf/System (BPS) power supplies are located at the front of the chassis. Refer to page 4-2 for more information on component locations. Two system power supply bays and three PoE power supply bays are provided.

  • Page 102: Ac Power Supply Led States

    Power Supplies OmniSwitch Backup Power Shelf/System (BPS) AC Power Supply LED States LED State Description Solid Green The power supply is operating normally and providing power to the chassis Flashing Green The power supply is on standby and can provide power to the chassis if power supply failover should occur Flashing Red No AC power is being provided to this power supply...
  • Page 103 OmniSwitch Backup Power Shelf/System (BPS) Power Supplies OmniSwitch BPS PoE Power Supply PoE Power Supply Front Panel Model OS-BPS-P (CP2000AC54TEP-AL) Input Voltage Range 100-132VAC; 180-264VAC Nominal Voltage 115 VAC; 230 VAC Max. Power 1200W (115 VAC); 2000W (230 VAC) Input Current 15 (100VAC);...

  • Page 104: Omniswitch Bps Poe Power Supply Led States

    Power Supplies OmniSwitch Backup Power Shelf/System (BPS) OmniSwitch BPS PoE Power Supply LED States Description On: Input OK Blinking: Input out of limits On: Output OK Blinking: Power supply overload On: Over-temp warning Blinking: Service ON: Fault page 4-16 OmniSwitch Backup Power Shelf/System (BPS) January 2013...

  • Page 105: Omniswitch Bps Power Connections

    OmniSwitch Backup Power Shelf/System (BPS) OmniSwitch BPS Power Connections OmniSwitch BPS Power Connections Connecting the OmniSwitch BPS to OS6850E Switches System and PoE power are provided to each OS6850E through a single one meter DB25 connector cable. Up to eight switches may be connected to the OmniSwitch BPS chassis. To connect a switch to the OS-BPS chassis, follow the steps below.
  • Page 106 OmniSwitch BPS Power Connections OmniSwitch Backup Power Shelf/System (BPS) Installing and Connecting System Power 1 Orient the power supply so that the power cord socket is situated at the right of the power supply. Also, for the power supply to seat properly, make sure that the handle is in the vertical position. 2 Slide the power supply back until it is securely seated in the chassis backplane.When the connector is fully seated, the lock tab will click and hold the power supply in place.
  • Page 107 OmniSwitch Backup Power Shelf/System (BPS) OmniSwitch BPS Power Connections Installing PoE Power Supplies 1 Orient the power supply so that the lever locking tab is situated at the right of the power supply with the lever open. 2 Slide the power supply back until the left side of the lever catches the sheet metal tab at the inside top of the chassis.
  • Page 108 OmniSwitch BPS Power Connections OmniSwitch Backup Power Shelf/System (BPS) Connecting PoE Power 1 Insert the power cord connector into the socket at the rear of the chassis. 2 Use the retainer clip to secure the power cord to the connector. Note.

  • Page 109: Grounding The Chassis

    OmniSwitch Backup Power Shelf/System (BPS) Grounding the Chassis Grounding the Chassis The chassis has a grounding lug located on the rear of the chassis. This lug uses 10-32 screws and is surrounded by a small paint-free area, which provides metal-to-metal contact for a ground connection. Use this connector to supplement the ground provided by the AC power cord.

  • Page 110: Disconnecting A Chassis From The Os-Bps

    Disconnecting a Chassis from the OS-BPS OmniSwitch Backup Power Shelf/System (BPS) Disconnecting a Chassis from the OS-BPS When disconnecting an OS6850E switch from the OS-BPS, first disconnect the DB25 connector cable between the OS-BPS and the switch, then disconnect the primary power supply for the OS6850E.
  • Page 111 OmniSwitch Backup Power Shelf/System (BPS) Disconnecting a Chassis from the OS-BPS Removing PoE Power Cords from the OS-BPS Chassis 1 Swing the retainer clip away from the power cord connector. 2 Pull the cord straight out of the connector socket. OmniSwitch Backup Power Shelf/System (BPS) page 4-23 January 2013...
  • Page 112 Disconnecting a Chassis from the OS-BPS OmniSwitch Backup Power Shelf/System (BPS) Removing PoE Power Supplies 1 When removing a power supply, first disconnect the power cord from the power source. Once the power cord is disconnected, pull the power cord out of the power supply housing. 2 Pressing the lock tab toward the right, as shown, will free the lever.

  • Page 113: Monitoring Omniswitch Bps Components

    OmniSwitch Backup Power Shelf/System (BPS) Monitoring OmniSwitch BPS Components Monitoring OmniSwitch BPS Components The following commands have been added or modified for OmniSwitch BPS support on OS6850E switches. Viewing General Power Supply Information To display all system power supplies, including those installed in the OmniSwitch BPS chassis, enter the following command: ->...

  • Page 114: Omniswitch Bps Operation

    OmniSwitch BPS Operation OmniSwitch Backup Power Shelf/System (BPS) OmniSwitch BPS Operation The amount of power supplied by the OS-BPS depends on the number of system and/or PoE power supplies installed as noted in the table below: Can support up to 4 OS6850E primary power supply failures. 1 System P/S (450W) Can support up to 8 OS6850E primary power supply failures.

  • Page 115: Supported Configurations

    OmniSwitch Backup Power Shelf/System (BPS) OmniSwitch BPS Operation OmniSwitch BPS Configurations The OmniSwitch BPS can be used to provide redundancy to the OmniSwitch 6850E in multiple configurations as described below: Supported Configurations • Single stack (from 1 to 8 switches) •...

  • Page 116: System Power Scenarios

    OmniSwitch BPS Operation OmniSwitch Backup Power Shelf/System (BPS) OmniSwitch BPS Scenarios The tables below describe scenarios that can be seen when using the OS-BPS and what the expected behavior will be based on the mode of the OS-BPS. System Power Scenarios System P/S Scenario Single (N+1) Mode Full (N+N) Mode...

  • Page 117: Managing Power Over Ethernet (Poe)

    As the switches fully support 10/100/1000 Ethernet connectivity, you may also attach non-PD equipment, such as computer workstations, printers, servers, etc. to the PoE ports. Important. Alcatel-Lucent recommends that PoE-enabled switches with attached IP telephones should have operational power supply redundancy at all times for 911 emergency requirements. In addition, both the switch and the power supply should be plugged into an Uninterruptible Power Source (UPS).

  • Page 118: In This Chapter

    Note. You can also monitor all chassis components and manage many chassis features, including Power over Ethernet, with WebView, Alcatel-Lucent’s embedded web-based device management application. WebView is an interactive and easy-to-use GUI that can be launched from the OmniVista or a web browser.

  • Page 119: Power Over Ethernet Specifications

    Managing Power over Ethernet (PoE) Power over Ethernet Specifications Power over Ethernet Specifications The table below lists general specifications for Alcatel-Lucent’s Power over Ethernet support. For more detailed power supply and Power Source Equipment (PSE) specifications, refer to Chapter 3, “OmniSwitch 6850E Series Power Supplies.”...

  • Page 120: Viewing Poe Power Supply Status

    Location ----+----+---------+------+-----------+---------- External External External The backup power supply will always display as “PS-2”. For detailed information on the show power command output, refer to the CLI Command Reference Guide. page 5-4 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 121: Configuring Power Over Ethernet Parameters

    Current (mA) Class Description Classification (Watts) Default 0.44-30.00 Unimplemented Optional 9-12 0.44-3.84 Very Low Power Optional 17-20 3.84-6.49 Low Power Optional 26-30 6.49-12.95 Mid Power Optional 36-44 12.95- 30.00 High Power OmniSwitch 6850E Series Hardware Users Guide page 5-5 January 2013...

  • Page 122: Setting The Poe Operational Status

    3 port 12 to 3000 milliwatts. This new value is now the maximum amount of power the port can use to power any attached device (until the value is modified by the user). page 5-6 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 123: Configuring The Total Power Available To A Slot

    For example, the syntax -> lanpower 8/22 priority critical OmniSwitch 6850E Series Hardware Users Guide page 5-7 January 2013...

  • Page 124: Setting The Capacitor Detection Method

    Note. The capacitive detection method should only be enabled to support legacy IP phones. This feature is not compatible with IEEE specifications. Please contact your Alcatel-Lucent sales engineer or Customer Support representative to find out which Alcatel-Lucent IP phones models need capacitive detection enabled.

  • Page 125: Understanding Priority Disconnect

    To enable priority disconnect, use the lanpower priority-disconnect command. Be sure to specify the slot number in the command line. For example, the syntax -> lanpower 8 priority-disconnect enable enables priority disconnect on slot 8. OmniSwitch 6850E Series Hardware Users Guide page 5-9 January 2013...
  • Page 126 When a PD is being connected to a port with a lower priority level than all other in the slot, the incoming PD will be denied power, regardless of its physical port number. Devices connected to other higher-prior- ity will continue operating without interruption. page 5-10 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 127: Priority Disconnect Is Disabled

    When priority disconnect is disabled, power will be denied to any incoming PD, regardless of its port priority status (i.e., low, high, and critical) or physical port number (i.e., 1–24). OmniSwitch 6850E Series Hardware Users Guide page 5-11 January 2013...

  • Page 128: Monitoring Power Over Ethernet Via Cli

    30000 Undefined 30000 Undefined Slot 3 Max Watts 150 1 Power Supplies Available Note. For detailed information on show lanpower command output, refer to the OmniSwitch CLI Refer- ence Guide. page 5-12 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 129: Chapter 6 Managing Omniswitch 6850E Series Stacks

    With stacks, users can easily expand their switching capacity simply by adding additional switches to the stack. In addition, stacks provide enhanced resiliency and redundancy features. OmniSwitch 6850E Series Hardware Users Guide page 6-1 January 2013...

  • Page 130: In This Chapter

    6-38. Note. You can also manage and monitor stacks through WebView, Alcatel-Lucent’s embedded web-based device management application. WebView is an interactive and easy-to-use GUI that can be launched from OmniVista or a web browser. Please refer to WebView’s online documentation for more informa- tion.

  • Page 131: Omniswitch 6850E Series Stacking Specifications

    -> interfaces 1/25 mode stacking WED JUL 01 18:08:29 : HSM-CHASSIS (101) info message: +++ Ni 1 Port 25,26 are set to stackable for next boot:OK -> reload working no rollback-timeout OmniSwitch 6850E Series Hardware Users Guide page 6-3 January 2013...

  • Page 132: Omniswitch 6850E Series Stack Overview

    Diagrams showing the management module failover sequence for stacks of three or more switches and stacks of two switches are provided on pages and 6-6, respectively. page 6-4 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 133 In other Primary words, it will act essentially as an NI module in the virtual Secondary chassis, passing traffic via its Ethernet. Idle Redundant Management Module Failover (Three or More Switches) OmniSwitch 6850E Series Hardware Users Guide page 6-5 January 2013...
  • Page 134 If the switch that previously failed or was taken offline Secondary comes back online, it will assume the secondary role in the stack. Primary Redundant Management Module Failover (Two Switches) page 6-6 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 135: Primary Management Module Selection

    As with the primary switch, these slot numbers are saved to the boot.slot.cfg file, located in the /flash file directory of each switch. For more information on dynamic slot number assignment, refer to “Slot Numbering” on page 6-20. OmniSwitch 6850E Series Hardware Users Guide page 6-7 January 2013...
  • Page 136 Slot 4 assigned slot 3 has the lowest slot number in the stack and becomes the primary management module. Primary: Slot 3 Primary Management Module Selection Using Saved Slot Information page 6-8 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 137 Primary Management Module Selection Using Switch Uptime OmniSwitch 6850E Series Hardware Users Guide page 6-9 January 2013...

  • Page 138: Secondary Management Module Selection

    Secondary Management Module Selection Using the Stacking Connection to the Primary Switch Note. For information on dynamic slot numbering for idle elements within the stack, refer to “Idle Module Role” on page 6-12 “Slot Numbering” on page 6-20. page 6-10 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 139 Reminder. Each element in a stack should always be assigned a unique slot number. Do not assign duplicate slot numbers to elements in a stack. Otherwise, one or more switches will be forced into pass-through mode. For more information on pass-through mode, refer to page 6-13. OmniSwitch 6850E Series Hardware Users Guide page 6-11 January 2013...

  • Page 140: Idle Module Role

    In the event of a primary-to-secondary failover, the idle module with the next-lowest slot number in the stack will assume the secondary—or backup—management role. Secondary Management Module Selection Using Saved Slot Information page 6-12 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 141 MAC address will be given the secondary manage- ment role. The slot with the higher MAC address will be forced into the pass-through mode. OmniSwitch 6850E Series Hardware Users Guide page 6-13...

  • Page 142: Recovering From Pass-Through Mode (Duplicate Slot Numbers)

    This can be further verified by looking down the saved slot column in the table. Note that slot 2, operating in the secondary management role, has a saved slot value of 2. Slot 1001, operating in pass-through, also has a saved slot value of 2. page 6-14 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 143 Saved Link A Remote Remote Link B Remote Remote Slot State Port State Port ----+-----------+--------+------+-------+-------+-------+-------+-------+------- 1 PRIMARY RUNNING StackA StackA 2 SECONDARY RUNNING StackB StackB 3 IDLE RUNNING StackA StackB OmniSwitch 6850E Series Hardware Users Guide page 6-15 January 2013...
  • Page 144 3 IDLE RUNNING StackB StackA 4 IDLE RUNNING StackB StackA 5 IDLE RUNNING StackB StackA 6 IDLE RUNNING StackB StackA 7 IDLE RUNNING StackB StackA 8 IDLE RUNNING StackB StackA page 6-16 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 145: Stack Cabling

    Note that a redundant stacking cable connection exists between the top and bottom switches. Again, this connection is required for effective redundancy across the stack. Examples of Stacking Cable Patterns (Chassis Rear Panels Shown) OmniSwitch 6850E Series Hardware Users Guide page 6-17 January 2013...
  • Page 146 1 and slot 4), data is immediately Slot 3 passed to slot 4, then quickly traverses slot 3 and exits slot 2 to its destination. Slot 4 Stacking Cable Redundancy: Recovery Following a Stacking Link Failure page 6-18 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 147: Checking Redundant Stacking Cable Status

    Redundant cable status : present Tokens used : 12 Tokens available : 20 In this example, a redundant stacking cable connection is present between the top-most and bottom-most switches in the stack. OmniSwitch 6850E Series Hardware Users Guide page 6-19 January 2013...

  • Page 148: Slot Numbering

    There are two ways stacking modules are assigned slot numbers: • Dynamic slot number assignment by the system software • Manual slot number assignment by the user page 6-20 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 149: Dynamic Slot Number Assignment

    Slot 5 - Idle reached, the slot numbering sequence resumes at the top of the stack, as shown. This helps ensure a more ordered and manageable stack topology. Dynamic Slot Numbering Example 1 OmniSwitch 6850E Series Hardware Users Guide page 6-21 January 2013...
  • Page 150 3 is assigned the slot number 4, and Slot 1 - Primary so on. This default procedure ensures the most ordered and manageable stack topology out of the box. Dynamic Slot Numbering Example 2 page 6-22 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 151: Manual Slot Number Assignment

    Instead, new slot number information is first saved to each boot.slot.cfg file across the stack. The reboot is saved for last in order to avoid duplicate slot numbers within the stack, which would cause unwanted pass-though mode conditions (see page 6-13). OmniSwitch 6850E Series Hardware Users Guide page 6-23 January 2013...

  • Page 152: Reverting To The Dynamic Slot Numbering Model

    Because the system software no longer has preassigned slot infor- mation to read during the boot process, the stack uses the dynamic slot number assignment method described on page 6-21. page 6-24 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 153: Hot-Swapping Modules In A Stack

    Note. If it is preferable to add a switch with an existing boot.slot.cfg file to a stack, be sure that the saved slot number of the incoming switch is not already assigned to a switch operating in the stack. OmniSwitch 6850E Series Hardware Users Guide page 6-25...

  • Page 154: Merging Stacks

    For information on stack cabling, refer to page 6-17. 5 Power on all incoming modules. Note. No more than eight switches can operate in a single stacked configuration at any time. page 6-26 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 155: Reloading Switches

    When the rebooted switch comes back up, it assumes an idle role Primary - Slot 2 within the stack. Secondary - Slot 3 Idle - Slot 4 Reloading the Primary Management Module In a Stack of Three or More OmniSwitch 6850E Series Hardware Users Guide page 6-27 January 2013...
  • Page 156 When the rebooted switch comes back up, it assumes the secondary Secondary - Slot 1 management role within the stack. Primary - Slot 2 Reloading the Primary Management Module In a Stack of Two page 6-28 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 157: Reloading The Secondary Management Module

    When the rebooted switch comes back up, it assumes an idle role Idle - Slot 2 within the stack. Secondary - Slot 3 Idle - Slot 4 Reloading the Secondary Management Module In a Stack of Three or More OmniSwitch 6850E Series Hardware Users Guide page 6-29 January 2013...
  • Page 158 When the rebooted switch comes back up, it assumes the secondary Primary - Slot 1 management role within the stack. Secondary - Slot 2 Reloading the Secondary Management Module In a Stack of Two page 6-30 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 159: Reloading Switches With Idle Roles

    Otherwise, the switch is likely to come up again in pass-through mode. For detailed information, including steps used to recover from pass-through, refer to page 6-13. OmniSwitch 6850E Series Hardware Users Guide page 6-31 January 2013...

  • Page 160: Software Synchronization During A Full Reload

    All other switches will be assigned to idle roles. An illustrated example of this method for assigning slot numbers and management roles is provided on pages 6-23 and 6-24. page 6-32 OmniSwitch 6850E Series Hardware Users Guide January 2013...
  • Page 161 To check the current saved slot information across the stack, use the show stack topology command. For detailed information on pass-through mode, refer to “Pass-Through Mode” on page 6-13. OmniSwitch 6850E Series Hardware Users Guide page 6-33 January 2013...

  • Page 162: Avoiding Split Stacks

    For more information on the redundant stacking cable connection, refer to page 6-18. page 6-34 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 163: Changing The Secondary Module To Primary

    When the former primary switch comes back up, it assumes an idle Primary - Slot 2 role within the stack. Secondary - Slot 3 Idle - Slot 4 Takeover Behavior In a Stack of Three or More OmniSwitch 6850E Series Hardware Users Guide page 6-35 January 2013...
  • Page 164 When the former primary switch comes back up, it assumes the Secondary - Slot 1 secondary management role within the stack. Primary - Slot 2 Takeover Behavior In a Stack of Two page 6-36 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 165: Synchronizing Switches In A Stack

    “Reloading All Switches in a Stack” on page 6-32. Note. For more information on management module synchronization and managing the /flash/working and /flash/certified directories, refer to the “Managing CMM Directory Content” chapter in the Switch Management Guide. OmniSwitch 6850E Series Hardware Users Guide page 6-37 January 2013...

  • Page 166: Monitoring The Stack

    Users can also monitor many stack operations by viewing the front panel LEDs on all elements in the stack. Refer to “Status LEDs” on page 2-53 for detailed information on LEDs and stack status. page 6-38 OmniSwitch 6850E Series Hardware Users Guide January 2013...

  • Page 167: Appendix A Regulatory Compliance And Safety Information

    A Regulatory Compliance and Safety Information This appendix provides information on regulatory agency compliance and safety for OmniSwitch 6850E Series switches. Declaration of Conformity: CE Mark This equipment is in compliance with the essential requirements and other provisions of Directive 2004/108/EC (EMC), 2006/95/EC (LVD), 91/263/EEC (Telecom Terminal Equipment, if applicable), 1999/5/EC (R&TTE, if applicable).

  • Page 168: China Rohs: Hazardous Substance Table

    对销售之日的所售产品, 本表显示, 阿尔卡特朗讯公司供应链的电子信息产品可能包含这些物质。注意: 在所售产 品中可能会也可能不会含有所有所列的部件。 This table shows where these substances may be found in the supply chain of Alcatel-Lucent electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
  • Page 169 Regulatory Compliance and Safety Information China RoHS: Hazardous Substance Table Products are packaged using one or more of the following packaging materials: Corrugated Cardboard Corrugated Fiberboard Low-Density Polyethylene OmniSwitch 6850E Hardware Users Guide page A-3 January 2013...

  • Page 170: Standards Compliance

    Standards Compliance Regulatory Compliance and Safety Information Standards Compliance The product bears the CE mark. In addition it is in compliance with the following other safety and EMC standards: All hardware switching modules used in an OmniSwitch 6850/6850E switch comply with Class A standards.

  • Page 171: Nebs Compliance Statements

    Regulatory Compliance and Safety Information NEBS Compliance Statements Environmental Standards • ETS 300 019 Storage Class 1.1 • ETS 300 019 Transportation Class 2.3 • ETS 300 019 Stationary Use Class 3.1 NEBS Compliance Statements The following statements apply to OS6850E non-PoE models OS6850E-24, OS6850E-24X, OS6850E-48, OS6850E-48X and OS6850E-U24X.

  • Page 172: Canada Class A Statement

    NEBS Compliance Statements Regulatory Compliance and Safety Information FCC Class A, Part 15 This equipment has been tested and found to comply with the limits for Class A digital device pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions in this guide, may cause interference to radio communications.Operation of this equipment in a residential...

  • Page 173: Class A Warning For Taiwan And Other Chinese Markets

    Regulatory Compliance and Safety Information NEBS Compliance Statements VCCI This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise.

  • Page 174: Translated Safety Warnings

    Translated Safety Warnings Regulatory Compliance and Safety Information Translated Safety Warnings Chassis Lifting Warning Two people are required when lifting the chassis. Due to its weight, lifting the chassis unassisted can cause personal injury. Also be sure to bend your knees and keep your back straight when assisting with the lifting of the chassis.

  • Page 175: Installation Warning

    Regulatory Compliance and Safety Information Translated Safety Warnings Installation Warning Only personnel knowledgeable in basic electrical and mechanical procedures should install or maintain this equipment. Français: Toute installation ou remplacement de l'appareil doit être réalisée par du personnel qualifié et compétent.

  • Page 176: Power Disconnection Warning

    Translated Safety Warnings Regulatory Compliance and Safety Information Power Disconnection Warning Your switch is equipped with multiple power supplies. To reduce the risk of electrical shock, be sure to disconnect all power connections before servicing or moving the unit. Français: Il se peut que cette unité soit équipée de plusieurs raccordements d'alimentation. Pour supprimer tout courant électrique de l'unité, tous les cordons d'alimentation doivent être débranchés.

  • Page 177: Dc Power Supply Connection Warning

    Regulatory Compliance and Safety Information DC Power Supply Connection Warning DC Power Supply Connection Warning For EMC/EMI, each DC/DC power supply requires that the ground wire is connected from each DC/DC power supply to Common Earth Ground. Français: Pour EMC/EMI, pour chaque alimentation DC/DC, il est impératif que le fil de terre soit branché...

  • Page 178: Wrist Strap Warning

    Français: L'électricité statique (ESD) peut endommager les composants du commutateur. Pour cette raison Alcatel-Lucent joint à l'envoi du châssis un bracelet antistatique à brancher sur la prise mise à la terre située en bas à droite du commutateur. Vous devrez mettre ce bracelet avant toute intervention hardware.

  • Page 179: Instrucciones De Seguridad En Español

    Deseche las baterías usadas según las instrucciones del fabricante. Las instrucciones del fabricante son como sigue: Devuelva el módulo con la batería del litio a Alcatel-Lucent. La batería del litio será substituida en la fábrica de Alcatel-Lucent.

  • Page 180: Advertencia Sobre Una Apropiada Conexión A Tierra

    Para este propósito, Alcatel-Lucent proporciona una pulsera antiestática y un terminal que pone a tierra situados cerca de la parte superior derecha del chasis. Para que la pulsera antiestática sea eficaz en la eliminación de ESD, las fuentes de alimentación se deben instalar en el chasis y enchufar en las salidas de CA con descarga a...

  • Page 181: Index

    4-21 exit command 2-45 pass-through modules 6-13 reloading 6-31 pinouts 2-46 hardware monitoring 1-3, 3-19, 6-38 automatic defaults LEDs 1-3, 2-42 monitoring 5-4, 5-12 user-driven priority disconnect OmniSwitch 6850E Series Hardware Users Guide Index-1 January 2013...
  • Page 182 6-20 software rollback software synchronization 6-37 specifications power cord 2-43 stack clear slot command 6-24 stack set slot command 6-14 stacks booting 2-42 cabling 2-38, 6-17 idle modules 6-12 Index-2 OmniSwitch 6850E Series Hardware Users Guide January 2013...

Table of Contents

Save PDF
