Spare Parts List
Item Description
1 MAIN COVER ASSEMBLY AT1
2 CONTROLS LID AT1 SP
3 DIFFUSER ASSEMBLY SV1
4 LED LIGHT MODULE
5 LED MODULE DIFFUSER
6 TAPTITE SCREW 'S' PH THD M4x10
7 TAPTITE 'P' M4x10
8 BASE SV1
9 LIMITS CONTROL ASSEMBLY SV1
10 RUBBER STOP GUIDE SV1
11 HELICAL GEAR 34209
12 DRIVE SHAFT 16_170 XFP
13 CHOPPER WHEEL SV1
14 SPLIT LIMIT NUT M10x0.75
15 CHOPPER CLIP
16 MINATURE MICROSWITCH AV
17 TERMINAL BLOCK SHIELD
18 TERMINAL BLOCK 500/02DS 2POS
19 CAPACITOR MOTOR 20.0UF
20 CAPACITOR POLYFILM 0.01UF
21 PAN HEAD SCREW 'P' M3x14
22 TAPTIE SCREW 'S' M3x8
23 CORD GROMMET SBR5-2
24 HARNESS ASSEMBLY SV1
25 LED HARNESS SV1
26 CONTROL BOARD ASSY ACB01-B
27 BOARD HOUSING SUB-ASSY AT1
28 TAPTITE SCREW 'P' M4x8
29 POWER CORD ASSEMBLY SV1
30 HEX SPACER 8A Fx10 M5
31 RUBBER STOP D19x15
32 AC MOTOR 370W FM62509
33 WORM 2520x50-2S
34 BALL BEARING R8ZZ
35 SELFLOCK PIN SPRING ACP M4x20
36 GEARBOX LID SV1
37 GEARBOX BASE SV1
38 BUSH ID 12x18
39 BUSH 10x10
32 SecuraLift® Rhino
Order
Code#
71113
72173
71456
71215
72313
10504
10570
72001
71650
72165
04941
72065
72168
72438
04960
09280
14055
05421
14403
07575
10361
10531
05605
71825
71821
71291
71455
10580
05666
11192
72166
14428
72212
03916
02590
72202
72201
04262
04290
Installation Instructions & Owner's Manual
Item Description
40 SENSOR ASSY SV1
41 TRACK BRACKET VP2
42 EXTRUSION 1050 END VP2
43 CRAIL 1050 VP1ASSY
44 EXTRUSION 3150 VP2
45 TENSION SUPPORT ASSY
46 CHAIN IDLER
47 TENSION BRACKET
48 HEX SHAFT 10-40
49 SHOULDER SCREW M8x65
50 CLAMPING BRACKET VP1
51 SHUTTLE VP2 ASSY
52 PULLEY SUPPORT
53 FLANGE 16-10
54 SPROCKET 8T SPL
55 CHAIN INDEX V3
56 CHAIN CLIP IM
57 CHAIN 1/2"x1/8" (487 LINKS) 2CL
58 CHAIN JOINT LINK
59 LOCATION LABEL
60 STRING HANDLE ASSEMBLY VP2
61 PIN
62 WALL BRACKET
63 PIN SNAP SSP 8 ZNU 31080
64 BENT ARM
65 STRAIGHT ARM
66 CLEVIS PIN 0829
67 HEX HEAD SCREW M8x25
68 HEX SERRATION FLANGE NUT M8
69 DOOR BRACKET
70 DOOR BRACKET LOCATOR
71 TB-4 4 BUTTON TRANSMITTER OGPP
72 TRANSMITTER TB-4 OG
73 LITHIUM BATTERY 3V CR2032
74 WALL TRANSMITTER WTB-4 WG PAC
75 WALL TRANSMITTER WTB-4 WG
76 PLASTIC WALL PLUG PACK
77 TAPTITE SCREW 'S' M4x10
78 TRANSMITTER TB-4 PP
Order
Code
01689
04590
72252
72251
72250
04594
02963
04590
03985
10602
04591
00274
04597
04313
72210
02941
72169
03005
02950
72854
71421
05790
02521
10720
02800
02790
02551
10110
10148
02511
02515
70242
71312
13021
70232
71304
01479
10497
71313
