Determine the Door Type
Step 4 - Determine the Door Type
Determine which type of garage door you have as
illustrated in (Fig. 09) to (Fig. 11).
For a sectional (panel) door on tracks (Fig. 09)
proceed with the installation from Step 5.
For a one piece door on tracks (Fig. 10)
proceed with the installation from Step 5.
For a one piece door without tracks (on springs) (Fig. 11)
proceed with the installation from Step 9.
Proceed from Step 5
Door
Sectional door with track
Proceed from Step 5
One piece door with track
Proceed from Step 9
One piece door without track
Installation Instructions & Owner's Manual
Track
Fig 09
Track
Door
Fig 10
Door
Fig 11
SecuraLift® Rhino 13
