Parts List - Automatic Technology SecuraLift GDO-7V1 Owner's Installation Instructions Manual

Spare parts list
When ordering spare parts please quote the order
code Number to your installer/dealer
Item/description
1 Base plate sub assembly
2 Bush 127id 18
3 Ac motor it 0.24Kw
4 Sel-lock pin spring acp m4x20
5 Label thermally protected
6 Cover protection
7 Hex nut w/int tooth washer m5
8 Label 240v 60 watt gdo-2
9 Motor bracket gdo-7
10 Bush 127 17-10
11 Bush id 10x10
12 Worm 2520 2s-st
13 Chopper wheel gdo-7
14 Chopper clip
15 Board housing sub assy
16 Control board cb-18 v1
17 Board shield
18 Taptite screw 'p' m4x8
19 Power cord 1.5M w 2pin+1 ring
20 Easy access transmitter pack
21 Controls lid
22 Cord grip grommet sbr5-2
23 Lamp holder ls 204-1
24 Terminal block 500/02ds 2 pos
25 Harness assy cb-7 (not shown)
26 Cap polyfilm 0.1 Uf k x2 275 vac
27 Terminal block shield
28 Drive shaft q-c
29 Helical gear 34209
30 Sprocket 8t octagonal
31 Cap motor 15.0 Uf 44o vac 3k hr
32 Chain idle wheel
33 Snap pin ssp 8 znu 31080
34 Snap pin ssp 12 znu 31120
35 Cable clamp acc-15 (3/16")
36 Globe 250v 60w
37 Pan head screw w/washer m5x10
30 GDO-7V1 SecuraLift®
order code
02152
04261
14423
02590
13620
13790
10881
13630
13776
04271
04290
04932
04951
04960
01586
01020
14053
10580
14150
01236
05108
05605
05761
05421
14441
07575
14056
04542
04941
04685
14402
02962
10720
10730
11750
14120
10281
Owner Installation Instructions
Item/description
38 Pan serration head screw m4x12
39 Pan head screw w/washer m4x10
40 Pan head screw m3x14
41 Internal tooth lock washer i.D.3
42 Cover assy gdo-7
43 Light diffuser
44 Taptite screw 'p' black m3.5X6
45 Pan head screw w/washer m4x8
46 Chain joint link
47 Shuttle assembly
48 Secura ptx-4 & wall switch pack
49 Transmitter grey buttons ptx-4
50 Transmitter red buttons ptx-4
51 Ptx holder
52 Alkaline battery a23 12v
53 Plastic wall plug pack
54 Clevis pin diameter 8
55 Pin
56 Hex head screw m8x25
57 Hex serration flange nut m8
58 Wall bracket
59 Door bracket
60 Door bracket locator
61 Support pipe cx assembly
62 Chain 1/2"x1/8" (499 links) w/2 cl
63 Tube 338605
64 Index tube 338605
65 Tube-insert 2970
66 Bent arm
67 Straight arm
68 Ratchet timing assembly
69 Sensor assembly
70 Taptite screw 'p' m3x12
71 Vibration isolator
72 Pan head screw w/washer m4x10
73 Shoulder screw 5-m4x9l
74 Grommet 5.2X8.0X4.5
order code
10380
10340
10360
11150
01599
13902
10542
10320
02950
00273
01220
01210
01211
05196
13030
01479
02550
05790
10110
10148
02521
02511
02515
00292
03000
13801
13811
13830
02800
02790
01737
01689
10553
02530
10340
10601
05604
