Determine the Door Type
Step 4 - Determine Door Type
Determine which type of garage door you have as
illustrated below. (Fig. 08 to 10).
For a sectional (panel) door on tracks (Fig. 08)
proceed with the installation from Step 5.
For a one-piece door on tracks (Fig. 09)
proceed with the installation from Step 5.
For a one-piece door without tracks (on springs) (Fig. 10)
proceed with the installation from Step 9.
Door
Sectional door with track
One piece door with
track
GDO-9v2 SecuraLift ®
Owner Installation Instructions
Track
fi g 08
fi g 09
Door
fi g 10
One piece door
without track
