SignWarehouse.com enduraCUT 2 User Manual page 43

7.1 EnduraCUT 2 Specifications
Operational Method
Max. Cutting Width
Max. Cutting Length
Max. Tracking
Max. Media Loading Width
Min. Media Loading Width
Acceptable Material Thickness
Number of Pinch Rollers
Motor Drive
Cutting Force
Max. Cutting Speed
Offset
Mechanical Resolution
Software Resolution
Distance Accuracy
Repeatability
Memory Buffer
Interfaces
Type of Command
Control Panel
Dimension (HxWxD) mm
Net Weight
Stand
Power Supply
Power Consumption
Environment Temperature
Environment Humidity
• Compatible with Windows 2000/ XP/ Vista/ 7/ 8 and MAC OS X 10.4-10.7.
• The specification and data sheet may vary with different materials used. In order to obtain the best output
quality, please maintain the machine regularly and properly.
• SignWarehouse Inc. reserves the right to change the specifications at any time without notice.
• The above listed specification values are effective only when operated with media certified by
SignWarehouse or commonly used in the production of vinyl graphics and sign industry applications.
Roller-Type
23.6in (600mm)
164ft (50m)
10ft (3.05m)
28.3in(719mm)
2.76in (50mm)
30 mil (0.8mm)
2
DC Servo Control
400 g
Up to 23.62 ips (600 mm /sec)
0~1.0 mm (with an increase of 0.025 mm)
0.009 mm (0.00035in)
0.025 mm (0.00098in)
±0.254 mm or ±0.1% of move, whichever is greater
±0.1mm up to 5 meters (* certified media)
4MB
USB 2.0 (Full Speed) and Serial (RS-232C)
HP-GL, HP-GL/2
LCD (20 digits x 2 lines), 14 Keys, 1 Power LED
8.67 x34.61x10.16in (220x 879x258mm)
28.6lb (13kg)
Optional
AC 100-240V, 50~60 Hz (auto switching)
Max.110watts
15℃~30℃ / 60℃~86℃ (operating)
25%~ 75% relative humidity (operating)
