3.4 Menu Items Cont'd
Menu or Key Function
19200, e, 7, 1, p
19200, n, 8, 1, p
19200, o, 8, 1, p
19200, e, 8, 1, p
Firmware To display the version number of Firmware and FPGA code.
Version
Select Language To select displayed languages on LCM panel in English, Spanish,
Italian, Deutsch, Japanese, Portuguese, Polish, Turkish or French.
Select Units Provide four-unit systems for user convenience.
Image Scale To adjust the image scale of media length and width that may be
Length caused by the thickness of the media.
The Numerator is the ideal length, and the Denominator is the
actual length measured from the result.
For example, cutting a line with 500.0 mm length. The procedure as
Image Scale
follows:
Width
1. Press the [LEFT ARROW] to choose the Numerator and
select 500.0 mm,
2. Cut the length by sending a graph file,
3. Measure the length then use the [RIGHT ARROW] key to
choose the Denominator, then
4. Press [UP ARROW /DOWN ARROW] to change the values of
the actual length.
Scale Length Fixed scaling, for maintenance only.
Scale Width
[ MISC ]
19200pbs, 7 Bits with EVEN Parity
19200pbs, 8 Bits with NO Parity
19200pbs, 8 Bits with ODD Parity
19200pbs, 8 Bits with EVEN Parity
2614 Texoma Drive Denison, TX 75020 • 980 Contract St. Suite 110 Lexington, KY
Phone: 903-462-7700 or toll free 800-899-5655 • Fax: 800-966-6834
29
User Manual
Setting Default
English
cm/gram; inch/oz; Metric
cm/oz; inch/gram
500/500 mm
