2.6 Setting up Your EnduraCUT 2 In LXI
1: Turn plotter on and connect USB port to your PC.
2: Then Open LXI software, draw a box or add text to the screen and click the Cut/Plot
Icon, or click File/Cut-Plot to open the LXI Cut/Plot Window. When Production Manager
opens, click Setup. Then from the drop-down menu, click Add Setup (Fig 2-14)
Figure 2-14
3: In the Add Setup window, you will be prompted to "choose a device" (Fig 2-15).
First you must choose a brand, then choose the model of your plotter. Click the top bar
to open the Brand drop-down menu. If you are going to use the USB
connection, click to select Vinyl Express as the brand
From the model drop-down list, click to select EnduraCUT 2S (Fig 2-16).
Figure 2-15
Figure 2-16
