SignWarehouse.com enduraCUT 2 User Manual page 28

3.4 Menu Items Cont'd
Menu or Key Function
Save Parameter To save pattern(s) of cutting parameters for later use.
There are 4 sets of parameters saved in the panel. Use Page Up and
Page Down keys to select the set of parameters you wish to adjust,
press "Enter" to confirm (the number shown on the upper left
corner will change accordingly). Each set of parameters includes
Speed, Force, Offset, Up Speed, Quality and Scaling, although the
latter three will not be displayed in this section. To adjust or check
individual parameters, go back to the responding keys on the panel
and press "Enter" to confirm.
Auto Unrolled To avoid paper jam and motor crash by automatically unroll media
Media (50cm and up) before cutting while enabled.
* Auto-unroll is only active on roll or edge media settings.
* Using Single mode to size media will disable this function auto-
matically.
* If the length of the rolled media is less than 2 meters or the roll
weight is light, it is recommended to disable this feature.
Rear Paper To detect if the rear paper sensor is covered to determine the
Sensor following process; when it is enabled, the cutter will detect if the
material has covered the rear paper sensor under the Roll and Edge
mode; when disabled, the rear paper sensor will not function.
Note: Rear paper sensor only functions under "Roll" and "Edge"
media settings.
Vacuum To help improve tracking and cutting accuracy by turning on the
fans. If you turn off the vacuum system, the fans will remain inac-
tive during cutting or plotting.
Paper Saving To save media by four different modes:
Mode 1. Length expanded mode 2. Width expanded mode
3. Both expanded mode
Set Communi- To speed up the communication between host computer and cutter.
cation Baud Rate determines the speed of data transmission. Data Bits
refers to the size of one block of data.
Parity is used to check if data was revived correctly or not.
9600, n, 7, 1, p
9600, o, 7, 1, p
9600, e, 7, 1, p
9600, n, 8, 1, p
9600, o, 8, 1, p
9600, e, 8, 1, p
19200, n, 7, 1, p
19200, o, 7, 1, p
[ MISC ]
4. Both unexpanded mode
9600pbs, 7 Bits with NO Parity
9600pbs, 7 Bits with ODD Parity
9600pbs, 7 Bits with EVEN Parity
9600pbs, 8 Bits with NO Parity
9600pbs, 8 Bits with ODD Parity
9600pbs, 8 Bits with EVEN Parity
19200pbs, 7 Bits with NO Parity
19200pbs, 7 Bits with ODD Parity...
Continued Next Page...
2614 Texoma Drive Denison, TX 75020 • 980 Contract St. Suite 110 Lexington, KY
Phone: 903-462-7700 or toll free 800-899-5655 • Fax: 800-966-6834
28
User Manual
Setting Default
Disable
Enable Enable
Disable
Enable
Both
unexpanded
mode
