3.4 Menu Items

The Table below desribes the fucnctions of EnduraCUT 2 Menu Commands
Menu or Key Function
Roll To measure media width.
Edge To measure media width and pull the media back untill the front
paper sensor is uncovered.
Single To measure media width and length.
To indicate the power status.
1. To move the tool carriage position on X or Y axis.
2. To select functions or change values of settings.
1. The displayed parameters will be saved automatically.
2. To set a new origin at the present tool carriage position.
In "offline" mode, moving the tool carriage to desired position by
[Arrow Keys], then press [ENTER] key to set a new origin. While
moving with the parameters of XY-axes displayed, pressing [MISC]
key will enable fine-tune movement; pressing [MISC] key again
will disable the function.
To temporarily halt the cutting process.
To resume the process, press [Pause/Resume] key again.
1. To switch between online mode and offline mode.
2. To stop the cutting job or abort the change of setting.
Once this key is pressed, the cutting job will be halted immediately
and cannot be resumed.
To set or modify the distance between the blade tip and the center
axis.
To set or modify the amount of cutting force.
--- MEDIA SIZING ---
--- POWER ---
[ARROW KEYS]
[ENTER]
[Pause/Resume]
[ONLINE / OFFLINE]
[OFFSET]
[FORCE]
Continued Next Page...
2614 Texoma Drive Denison, TX 75020 • 980 Contract St. Suite 110 Lexington, KY
Phone: 903-462-7700 or toll free 800-899-5655 • Fax: 800-966-6834
25
User Manual
Setting Default
Maximum Tracking 150
meters
Maximum Tracking 150
meters
Maximum Tracking 10
meters
0.000~1.000mm 0.275mm
5~400gram; 5 gram/ 80 gram
per step
